Intel Core i5-2540M

Intel 2540M

El Intel Core i7-2540M es un veloz procesador dual core de lata capacidad el momento de la introducción el 1er trimestre de 2011. Se basa en la arquitectura Sandy Bridge y ofrece Hyperthreading para controlar 4 threads simultáneamente (para un mejor uso del pipeline). Comparado con el más veloz Core i7, el i5 ofrece un cache de 3MB de último nivel más pequeño. La frecuencia básica es 2,6 GHz, pero gracias al Turbo Boost puede alcanzar 3,1 GHz (2 núcleos activos) y 3,3 GHz (1 núcleo activo).

Sandy Bridge es la sucesora evolutiva de la arquitectura Arrandale. Las mejoras más notables son las nuevas instrucciones AVX de 265Bit, el Turbo Boost 2.0 mejorado y la integración de la tarjeta de video en el núcleo de 32nm del CPU.

El i5-2540M ofrece una tarjeta de video integrada (Intel HD Graphics 3000) la cual es claramente más veloz que la antigua Intel HD Graphics en los CPUs Arrandale. Como el nuevo GPU está incluido en el CPU, también es producido en 32nm y comparte el veloz cache de nivel 3 con los núcleos del CPU (usando un nuevo ring bus). En el 2540M tiene una frecuencia de 650-1300MHz (Turbo Boost).

Además, un controlador de memoria de dos canales DDR3 está incluida en el molde del CPU, y es utilizada por CPU y en parte por el GPU.

Gracias a la arquitectura mejorada y al nuevo Turbo Boost 2.0, el rendimiento promedio del Core i7-2540M es más alto que el de un Arrandale Core i5 con frecuencia similar. En los benchmarks sintéticos el rendimiento debe estar a al altura del antiguo Core i7-620M y, por tanto, apto incluso para tareas exigentes.

El TDP de 35W incluye el CPU integrado y controlador de memoria.

SeriesIntel Core i5
CodenameSandy Bridge
Clock Rate2600 - 3300 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache3072 KB
Number of Cores / Threads2 / 4
Max. Power Consumption (TDP = Thermal Design Power)35 Watt
Transistor Count624 Millón
Manufacturing Technology32 nm
Die Size149 mm2
Max. Temperature100 °C
SocketrPGA988B, BGA1023
FeaturesHD Graphics 3000 (650-1300MHz), DDR3-1066/1333 Memory Controller (max 8GB), HyperThreading, AVX, Quick Sync, Virtualization
64 Bit64 Bit support
Hardware VirtualizationVT-x, VT-d
Starting Price $266 U.S.
Announcement Date02/20/2011
Product Link (external)Intel Core i5 2540M

CPU Benchmarks

3DMark 06 - CPU:
0% 100%
min: 3334     avg: 3631.9 (41.5%)     max: 3701 Points
Super Pi mod 1.5 XS 1M:
0% 100%
min: 12     avg: 12.2 (99.29%)     max: 13 Seconds*
Super Pi mod 1.5 XS 2M:
0% 100%
min: 27     avg: 28.6 (99.67%)     max: 30 Seconds*
Super Pi Mod 1.5 XS 32M:
0% 100%
min: 644     avg: 667.8 (97.09%)     max: 699 Seconds*
SiSoft Sandra Dhrystone (MIPS):
0% 100%
min: 48900     avg: 53760 (25.51%)     max: 60510 MIPS
SiSoft Sandra Whetstone (MFLOPS):
0% 100%
min: 34400     avg: 36296.7 (27.84%)     max: 37650 MFLOPS
PCMark Vantage: Result 1024x768
0% 100%
min: 6144     avg: 8868.5 (37.71%)     max: 13934 Points
Cinebench R10: Rendering Single 32Bit
0% 100%
min: 3923     avg: 4135.4 (74.07%)     max: 4234 Points
Cinebench R10: Rendering Multiple CPUs 32Bit
0% 100%
min: 8386     avg: 8998.4 (32.97%)     max: 9259 Points
Cinebench R10: Rendering Multiple CPUs 64Bit
0% 100%
min: 10077     avg: 10797 (32.95%)     max: 11242 Points
Cinebench R10: Rendering Single CPUs 64Bit
0% 100%
min: 4816     avg: 5104.9 (73.22%)     max: 5276 Points
3DMark Vantage: P CPU no PhysX 1280x1024
0% 100%
min: 9338     avg: 9775 (26.43%)     max: 10023 Points
wPrime 2.0x: 32m
0% 100%
min: 16.16     avg: 17.4 (97.45%)     max: 19.159 seconds*
wPrime 2.0x: 1024m
0% 100%
min: 511     avg: 545.3 (95.01%)     max: 595.436 seconds*
Windows 7 Experience Index: Processor
0% 100%
min: 7.1     avg: 7.1 (88.89%)     max: 7.1 points
Cinebench R11.5: CPU Multi 64Bit
0% 100%
min: 2.77     avg: 2.9 (23.16%)     max: 2.98 Points
Cinebench R11.5: CPU Single 64Bit
0% 100%
min: 1.28     avg: 1.3 (71.43%)     max: 1.28 Points
WinRAR: Result
0% 100%
min: 2229     avg: 2229 (46.59%)     max: 2229 KB/s
TrueCrypt: AES Mean 100MB
0% 100%
min: 1.5     avg: 1.5 (28.16%)     max: 1.5 GB/s
TrueCrypt: Twofish Mean 100MB
0% 100%
min: 0.254     avg: 0.3 (26.67%)     max: 0.254 GB/s
TrueCrypt: Serpent Mean 100MB
0% 100%
min: 0.143     avg: 0.1 (7.32%)     max: 0.143 GB/s
- Range of benchmarks for this CPU
- Average benchmark score

Cinebench R10 in comparison
Intel Atom Z670 (min)
691
...
Intel Core i7 740QM
8865
Intel Core i5 3210M
8899.5
Intel Core i7 3537U
8990
Intel Core i5 2540M
8998.4
Intel Core i5 3230M
9025
Intel Core i7 2620M
9124.2
Intel Core i7 820QM
9174.4
...
Intel Core i7 (Desktop) 3960X (max)
27189.5
