Intel Core i5-5350H

Intel 5350H

El Intel Core i5-5350H es un veloz procesador dual-core basado en la arquitectura Broadwell, que fue lanzado en junio del 2015. Además de dos núcleos de CPU con Hyper-Threading con velocidade de 3,0 - 3,5 GHz (2 Núcleos: también 3,5 GHz), el chip también integra una GPU iris Pro Graphics 6200 con eDRAM on-package y un controlador de memoria dual-channel LPDDR3-1866/DDR3L-1600. El Core i5 es producido en un proceso de 14 nm con transistores FinFET.

Arquitectura

Broadwell representa el "Tick" en el modelo Tick-Tock de Intel, lo que significa una reducción de su predecesor Haswell. El nuevo proceso de producción de 14 nm con transistores FinFET tridimensionales permite no solo mejorar la eficiencia de energía, sino también un tamaño de matriz significantemente más pequeño para paquetes y dispositivos más compactos.

Otras ventajas resultan de la micro arquitectura corregida de Broadwell. Debido a su predicción de ramas mejorado, tamaños de buffer más grandes (1500 en vez de 1000 entrada en el L2 TLB) y otros tweaks, el rendimiento ha sido mejorado por más de 5 por ciento sobre su predecesor. También hay algunas nuevas extensiones de conjuntos de instrucciones diseñados para aplicaciones criptográficas.

Rendimiento

Gracias a su arquitectura mejorada, el Core i5-5350H ofrece un rendimiento similar al del Core i7-4610M basado en Haswell (3,0 - 3,7 GHz). Por eso, la CPU tiene suficiente poder incluso para aplicaciones exigentes y multi tareas.

Gráficos

La Iris Pro Graphics 6200 (GT3e) integrada ofrece 48 Unidades de Ejecución (EUs) con velocidad de 300 - 1050 MHz, que pueden acceder a 128 MB de memoria eDRAM dedicada. Para una solución gráfica integrada, la Iris Pro Graphics 6200 alcanza niveles de rendimiento excepcionales y compite con tarjetas de vídeo de gama baja o media como la GeForce 940M. A pesar de todo, los juegos exigentes de 2015, solo serán jugables con configuraciones bajas o medias.

Broadwell es el primer chip Intel en soportar completamente el DirectX 11.2 así como OpenCL 1.3/2.0 y OpenGL 4.3. La salida de vídeo nativa es mediante DisplayPort 1.2 o HDMI 1.4a. Sin embargo, el nuevo estándar HDMI 2.0 no es soportado.

Consumo de Energía

El i5-5350H tiene un TDP de 47 W incluyendo la tarjeta de video, controlador de memoria y VRMs. Sin embargo, el consumo de energía en carga de trabajo solo-CPU será significantemente inferior. En general, la CPU es más adecuada para portátiles de 15 pulgadas o más grandes.

SerieIntel Core i5
Nombre códigoBroadwell

Serie: Core i5 Broadwell

Intel Core i5-5350H « 3 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-5287U2.9 - 3.3 GHz2 / 4 cores3 MB L3
Intel Core i5-5257U2.7 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i5-5300U2.3 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-5350U1.8 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-5200U2.2 - 2.7 GHz2 / 4 cores3 MB L3
Intel Core i5-5250U1.6 - 2.7 GHz2 / 4 cores3 MB L3
Velocidad de reloj3000 - 3500 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)47 Watt
Tecnología de producción14 nm
Temperatura Máx.105 °C
ConectorBGA1364
RecursosLPDDR3-1866/DDR3L-1600 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel Iris Pro Graphics 6200 (300 - 1050 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$289 U.S.
Fecha de anuncio06/02/2015
