Intel Core i7-2920XM

Intel 2920XM

El Intel Core i7-2920XM es le procesador quad-core más veloz para portátiles el 1er trimestre de 2011. Gracias a la marca Extreme Edition, el CPU debe ser fácilmente acelerado (multiplicador desbloqueado). Se basa en la arquitectura Sandy Bridge y ofrece Hyperthreading para controlar 8 threads simultáneamente (para un mejor uso del pipeline). Comparado con los anteriores quad-cores Clarksdale, el i7-2920XM ahora es producido por en 32nm, ofrece una tarjeta de video integrada y funciones AES. Comparado con el 2820QM de menos frecuencia, el 2920XM está especificado un TDP más alto.

Sandy Bridge es la sucesora evolutiva de la arquitectura Arrandale. Las mejoras más notables son las nuevas instrucciones AVX de 265Bit, el Turbo Boost mejorado y la integración de la tarjeta de video en el núcleo de 32nm del CPU. Además, el controlador de memoria integrado fue mejorado y soporta hasta 8 GB DDR3-1333.

El Core i7-2920XM ofrece una tarjeta de video integrada (Intel HD Graphics 3000) la cual demostró ser claramente más veloz que la antigua Intel HD Graphics en los CPUs Arrandale y a la altura de tarjeta de video dedicada de nivel básico como la GeForce 310M. La HD Graphics 3000 también soporta Turbo Boost y funciona con una frecuencia entre 650 MHz y 1300 MHz. Como la tarjeta de video comparte el veloz cache de último nivel, el procesador es un poco más lento con GPU activo.

Debido al alto Turbo Boost y Hyperthreading, el rendimiento del Core i5-2920XM puede alcanzar niveles del veloz procesador Core i5-2500K para desktop. Comparado con la anterior generación, el i7-2920XM es hasta 42% más veloz que el antiguo procesador Core i7-940XM. Por tanto, el rendimiento debe ser el suficiente incluso para las tareas más exigentes como la edición de videos HD o juegos 3D. Se pude encontrar extensos benchmarks detallados al final de esta página y en nuestro análisis de los nuevos procesadores quad core Sandy Bridge.

El alto índice TDP del 2920XM permite el uso del quad core sólo en portátiles grandes y pesados (normalmente 15" a arriba). Sin embargo, comparado con la anterior generación de quad-cores el TDP ha mejorado,ya que ahora está incluido el GPU.

SeriesIntel Core i7
CodenameSandy Bridge
Clock Rate2500 - 3500 MHz
Level 1 Cache256 KB
Level 2 Cache1024 KB
Level 3 Cache8192 KB
Number of Cores / Threads4 / 8
Max. Power Consumption (TDP = Thermal Design Power)55 Watt
Transistor Count995 Millón
Manufacturing Technology32 nm
Die Size216 mm2
Max. Temperature100 °C
SocketFCPGA988
FeaturesHD Graphics 3000 (650-1300MHz), DDR3-1066/1333/1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
64 Bit64 Bit support
Hardware VirtualizationVT-x, VT-d
Starting Price $1096 U.S.
Announcement Date01/06/2011
Product Link (external)Intel Core i7 2920XM

CPU Benchmarks

3DMark 06 - CPU:
0% 100%
min: 5944     avg: 6100 (72%)     max: 6206 Points
Super Pi 1M:
0% 100%
min: 10     avg: 10.5 (2%)     max: 11.7 Seconds
Super Pi 2M:
0% 100%
min: 24     avg: 24.6 (1%)     max: 25.9 Seconds
Super Pi 32M:
0% 100%
min: 580     avg: 599.9 (3%)     max: 620 Seconds
SiSoft Sandra Dhrystone (MIPS):
0% 100%
min: 118300     avg: 121716.7 (58%)     max: 125070 MIPS
SiSoft Sandra Whetstone (MFLOPS):
0% 100%
min: 71200     avg: 74190 (57%)     max: 75690 MFLOPS
PCMark Vantage: Result 1024x768
0% 100%
min: 9438     avg: 15729 (77%)     max: 19136 Points
Cinebench R10: Rendering Single 32Bit
0% 100%
min: 4282     avg: 4386.5 (71%)     max: 4507 Points
Cinebench R10: Rendering Multiple CPUs 32Bit
0% 100%
min: 16067     avg: 16949.3 (62%)     max: 17355 Points
Cinebench R10: Rendering Multiple CPUs 64Bit
0% 100%
min: 19727     avg: 20763 (63%)     max: 21407 Points
Cinebench R10: Rendering Single CPUs 64Bit
0% 100%
min: 5343     avg: 5525.3 (86%)     max: 5628 Points
3DMark Vantage: P CPU no PhysX 1280x1024
0% 100%
min: 20540     avg: 21107 (49%)     max: 21592 Points
wPrime 2.0x: 32m
0% 100%
min: 8.29     avg: 8.5 (2%)     max: 8.9 seconds
wPrime 2.0x: 1024m
0% 100%
min: 264.9     avg: 276.8 (3%)     max: 295 seconds
Windows 7 Experience Index: Processor
0% 100%
min: 7.5     avg: 7.6 (97%)     max: 7.6 points
Cinebench R11.5: CPU 64Bit
0% 100%
min: 5.7     avg: 6 (57%)     max: 6.2 Points
WinRAR: Result
0% 100%
min: 3296     avg: 3923 (85%)     max: 4550 KB/s
X264 HD Benchmark 4.0: Pass 1
0% 100%
min: 129.4     avg: 131.4 (76%)     max: 133.4 fps
X264 HD Benchmark 4.0: Pass 2
0% 100%
min: 30.4     avg: 30.8 (56%)     max: 31.2 fps
TrueCrypt: AES Mean 100MB
0% 100%
min: 2.8     avg: 3 (57%)     max: 3.1 GB/s
TrueCrypt: Twofish Mean 100MB
0% 100%
min: 0.508     avg: 0.5 (59%)     max: 0.521 GB/s
TrueCrypt: Serpent Mean 100MB
0% 100%
min: 0.293     avg: 0.3 (60%)     max: 0.296 GB/s
- Range of benchmarks for this CPU
- Average benchmark score

Cinebench R10 in comparison
Intel Atom Z670 (min)
691
...
Intel Core i5 (Desktop) 2500K
15956
Intel Core i7 (Desktop) 975
16628
Intel Core i7 2860QM
16809.5
Intel Core i7 2920XM
16949.3
Intel Core i7 3610QM
17213
Intel Core i7 3720QM
18223.2
Intel Core i7 2960XM
18300
...
Intel Core i7 (Desktop) 3960X (max)
27189.5
