Intel Core i7-3920XM

Intel 3920XM

El Intel Core i7-3920XM es el más veloz procesador quad-core para portátiles, basado en la arquitectura Ivy Bridge en el momento de la introducción en abril de 2012. Gracias al Hyperthreading, los cuatro núcleos pueden soportar hasta ocho threads en paralelo haciendo un mejor uso del CPU. Cada núcleo ofrece una velocidad base de 2,9 GHz, pero puede aumentar la frecuencia dinámicamente con Turbo Boost, hasta 3,6 GHz (para 4 núcleos activos), 3,7 GHz (para 2 núcleos activos) y 3,8 GHz (para 1 núcleo activo). Además, los CPUs Extreme ofrecen un multiplicador desbloqueado para la fácil aceleración (overclocking).

Ivy Bridge es una matriz mejorada y reducida de la arquitectura Sandy Bridge con mejoras en el rendimiento del GPU y CPU. Los CPUs son producidos en 22nm (contra 32nm de los CPUs Sandy Bridge) y son los primeros en introducir transistores 3D para una mejor eficiencia energética al compararlo con procesadores Sandy Bridge con frecuencias similares. Otros nuevos recursos son el PCI Express 3.0 integrado y soporte para DDR3(L)-1600.

El rendimiento del Core i7-3920XM debe ser ligeramente superior que el de un procesador Sandy Bridge con frecuencia similar gracias a pequeñas alteraciones estructurales. Por tanto, y debido a la frecuencia superior, el Core i7-2960XM debe ser fácilmente superado por 10 a 15%.

El Intel HD Graphics 4000 integrado, ofrece 16 Unidades de Ejecución (EUs) con frecuencia de 650 MHz hasta 1300 MHz con Turbo Boost, lo cual lo hace la variante más veloz.

Los CPUs XM están clasificados con un TDP de 55 Watts incluyendo la tarjeta de video y controlador de memoria y, por lo tanto, 10 Watts más alto que los otros modelos quad-core.  Por tanto, el CPU es bien adecuado para portátiles de 17 pulgadas o más grandes.

SerieIntel Core i7
Nombre códigoIvy Bridge

Serie: Core i7 Ivy Bridge

Intel Core i7-3940XM3 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-3920XM « 2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 8 cores6 MB L3
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 8 cores6 MB L3
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 8 cores6 MB L3
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-3540M3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-3520M2.9 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-3687U2.1 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i7-3667U2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-3537U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i7-3517U1.9 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 4 cores4 MB L3
Velocidad de reloj2900 - 3800 MHz
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)55 Watt
Conteo de Transistores1400 Millón
Tecnología de producción22 nm
Tamaño de Matriz160 mm2
Temperatura Máx.105 °C
ConectorFCPGA988
RecursosHD Graphics 4000, DDR3(L)-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1300 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$1096 U.S.
Fecha de anuncio04/23/2012
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 6.89     de promedio: 7.1     mediana: 7.1 (9%)     max: 7.22 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.53     de promedio: 1.6     mediana: 1.6 (39%)     max: 1.58 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5045     de promedio: 5078     mediana: 5078 (31%)     max: 5111 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 19595     de promedio: 19653     mediana: 19652.5 (14%)     max: 19710 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 19756     de promedio: 23050     mediana: 24647 (17%)     max: 24748 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 5132     de promedio: 6011     mediana: 6416 (8%)     max: 6484 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 220.9     de promedio: 241.8     mediana: 241.8 (3%)     max: 262.7 s
wPrime 2.10 - wPrime 2.0 32m *
min: 7.412     de promedio: 7.5     mediana: 7.5 (2%)     max: 7.539 s
WinRAR - WinRAR 4.0
4570 puntos (7%)
X264 HD Benchmark 4.0 - x264 Pass 2
min: 37.1     de promedio: 38     mediana: 38 (13%)     max: 38.9 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 156.4     de promedio: 156.7     mediana: 156.7 (36%)     max: 157 fps
TrueCrypt - TrueCrypt Serpent
min: 0.366     de promedio: 0.4     mediana: 0.4 (0%)     max: 0.373 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.562     de promedio: 0.6     mediana: 0.6 (10%)     max: 0.633 GB/s
TrueCrypt - TrueCrypt AES
min: 3.5     de promedio: 3.6     mediana: 3.6 (9%)     max: 3.6 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 6793     de promedio: 6935     mediana: 6973 (15%)     max: 7039 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 9     de promedio: 9.4     mediana: 9 (2%)     max: 10.11 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 22     de promedio: 22.3     mediana: 22 (1%)     max: 22.98 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 531     de promedio: 534     mediana: 534 (2%)     max: 537 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 115400     de promedio: 129935     mediana: 129935 (62%)     max: 144470 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 83580     de promedio: 85345     mediana: 85345 (65%)     max: 87110 MFLOPS
Windows 7 Experience Index - Win7 CPU
7.7 Points (99%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 24085     de promedio: 24928     mediana: 25094 (22%)     max: 25605 Points
3DMark 11 - 3DM11 Performance Physics
9329 Points (25%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
