Intel Core i7-820QM

Intel 820QM

El Intel Core i7 820QM es una CPU quad core de gama alta en 2009. Presneta 4 nucleos (CPU quead core) y Hyperthreading. Por tanto puede ejecutar 8 hilos de forma simultanea.

Debido al Modo Turbo, la CPU tiene una velocidad de reloj de hasta 3.06 GHz y por tanto es rapida para aplicaciones de un solo nucleo como juegos viejos.

La linea Core i7 9xx tiene un controlador de memoria integrado para modulos DDR3 (1066 a 1333). Por tanto, el rendimiento de la memoria

La linea Core i7 9xx tiene un controlador de memoria integrado para modulos DDR3 (1066 o 1333). Por tanto el rendimiento de la memoria es muy bueno (comparado con CPUs viejas con controladores de memoria externos). Esto lleva a un mayor TDP en el chip.

La arquitectura Core es muy similar a la usada en CPUs Core 2.

El consumo de corriente de hasta 45 vatios (TDP) es muy alta para una CPU portatil y debido al modo Turbo, el consumo de corriente debería llegar a estos valores altos. Por tanto la CPU solo es adecuada para portatiles grandes.

SerieIntel Core i7
Nombre códigoClarksfield

Serie: Core i7 Clarksfield

Intel Core i7-940XM2.13 - 3.33 GHz4 / 8 cores8 MB L3
Intel Core i7-920XM2 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-840QM1.86 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-820QM « 1.73 - 3.06 GHz4 / 8 cores8 MB L3
Intel Core i7-740QM1.73 - 2.93 GHz4 / 8 cores6 MB L3
Intel Core i7-720QM1.6 - 2.8 GHz4 / 8 cores6 MB L3
Velocidad de reloj1730 - 3060 MHz
Bus Frontal2500
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)45 Watt
Conteo de Transistores774 Millón
Tecnología de producción45 nm
Tamaño de Matriz296 mm2
Temperatura Máx.100 °C
ConectorRPGA989
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$546 U.S.
Fecha de anuncio09/23/2009
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 2.95     de promedio: 3.1     mediana: 3 (4%)     max: 3.44 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 3075     de promedio: 3457     mediana: 3271.5 (20%)     max: 4185 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 8341     de promedio: 9174     mediana: 8559 (6%)     max: 11966 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 10222     de promedio: 10498     mediana: 10317 (7%)     max: 11311 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 3709     de promedio: 3952     mediana: 3987 (5%)     max: 4101 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 424     de promedio: 1140     mediana: 1361.5 (16%)     max: 1412 s
wPrime 2.10 - wPrime 2.0 32m *
min: 13.73     de promedio: 35.2     mediana: 42 (8%)     max: 43 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3053     de promedio: 3226     mediana: 3149 (7%)     max: 3629 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
14 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 31     de promedio: 31.7     mediana: 32 (1%)     max: 32 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 765     de promedio: 787     mediana: 780 (3%)     max: 817 s
PCMark 05 - PCMark 05 - Standard
7734 Points (16%)
Windows 7 Experience Index - Win7 CPU
min: 7.1     de promedio: 7.2     mediana: 7.2 (92%)     max: 7.2 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 10851     de promedio: 11570     mediana: 11251.5 (10%)     max: 12631 Points
3DMark 11 - 3DM11 Performance Physics
4002 Points (11%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
