Intel Core i7-920XM

Intel 920XM

El Intel Core i7 920XM Extreme Edition es actualmente (2009) el procesador para portatiles más rapido. Presenta 4 nucleos (CPU quad core) y Hypertrheading. Por tanto, pueden funcionar 8 hilos de forma simultanea.

Debido al Modo Turbo la CPU tiene una velocidad de reloj de hasta 3.2 GHz y por tanto rápida para aplicaciones de un solo nucleo.

La linea Core i7 9xx tiene un controlador de memoria integrado para modulos DDR3 (1066o 1333). Por tanto, el rendimiento de memoria es muy bueno (comparado con CPUs más viejas con controladores de memoria externos). Esto lleva a mayores TDP en ele chip completo.

La arqutectura del nucleo es bastante similar a la usada en las CPUs Core 2.

El consumo de corriente de hasta 55 vatios (TDP) es muy alto para una CPU portatil y debido al Modo Turbo, el consumo de corriente debería llegar a valores altos.

Con un precio inicial de 1054$ (al comprar 1000 CPUs a Intel) el precio es bastante elevado.

SeriesIntel Core i7
CodenameClarksfield
Clock Rate2000 - 3200 MHz
Front Side Bus2500 MHz
Level 1 Cache256 KB
Level 2 Cache1024 KB
Level 3 Cache8196 KB
Number of Cores / Threads4 / 8
Max. Power Consumption (TDP = Thermal Design Power)55 Watt
Transistor Count774 Millón
Manufacturing Technology45 nm
Die Size296 mm2
Max. Temperature100 °C
SocketRPGA989
Features2.5 GT/s DMI, Virtualization Technology, Execute Disable Bit, Enahnced Speedstep Technology, Enhanced Halt State (C1E), 64, Turbo Boost, Hyper-Threading, Trusted Execution Technology
64 Bit64 Bit support
Hardware VirtualizationVt
Starting Price $1054 U.S.
Announcement Date09/23/2009
Product Link (external)Intel Core i7 920XM

CPU Benchmarks

3DMark 06 - CPU:
0% 100%
min: 3591     avg: 3815.8 (43.73%)     max: 4078 Points
Super Pi mod 1.5 XS 1M:
0% 100%
min: 13     avg: 13 (99.12%)     max: 13 Seconds*
Super Pi mod 1.5 XS 2M:
0% 100%
min: 31     avg: 31 (99.57%)     max: 31 Seconds*
Super Pi Mod 1.5 XS 32M:
0% 100%
min: 719     avg: 719 (96.86%)     max: 719 Seconds*
SiSoft Sandra Dhrystone (MIPS):
0% 100%
min: 48000     avg: 48000 (22.78%)     max: 48000 MIPS
SiSoft Sandra Whetstone (MFLOPS):
0% 100%
min: 43210     avg: 43210 (33.15%)     max: 43210 MFLOPS
PCMark Vantage: Result 1024x768
0% 100%
min: 7408     avg: 8970.7 (38.19%)     max: 10654 Points
Cinebench R10: Rendering Single 32Bit
0% 100%
min: 4310     avg: 4322 (77.53%)     max: 4334 Points
Cinebench R10: Rendering Multiple CPUs 32Bit
0% 100%
min: 11792     avg: 11916 (43.66%)     max: 12040 Points
Cinebench R10: Rendering Multiple CPUs 64Bit
0% 100%
min: 13235     avg: 13312.5 (40.63%)     max: 13390 Points
Cinebench R10: Rendering Single CPUs 64Bit
0% 100%
min: 4197     avg: 4258.5 (61.07%)     max: 4320 Points
3DMark Vantage: P CPU no PhysX 1280x1024
0% 100%
min: 11552     avg: 13318.3 (36.01%)     max: 14253 Points
wPrime 2.0x: 32m
0% 100%
min: 9.7     avg: 24.7 (95.96%)     max: 39.78 seconds*
wPrime 2.0x: 1024m
0% 100%
min: 312     avg: 790.7 (92.07%)     max: 1269.324 seconds*
Windows 7 Experience Index: Processor
0% 100%
min: 7.2     avg: 7.3 (91.53%)     max: 7.3 points
Cinebench R11.5: CPU Multi 64Bit
0% 100%
min: 3.41     avg: 3.7 (29.89%)     max: 3.9 Points
- Range of benchmarks for this CPU
- Average benchmark score

Cinebench R10 in comparison
Intel Atom Z670 (min)
691
...
Intel Core i5 (Desktop) 750
11048
Intel Core i7 940XM
11391
11415.2
Intel Core i7 920XM
11916
Intel Core i7 2635QM
13521.4
Intel Core i7 2630QM
13690.8
Intel Core i7 (Desktop) 940
13888
...
Intel Core i7 (Desktop) 3960X (max)
27189.5
