Intel Pentium N3710

Intel N3710

El Intel Pentium N3710 es un SoC quad-core para portátiles de nivel de entrada, que fue presentado a principios de 2016. Tiene una frecuencia de 1,1 - 2,56 GHz y parte de la plataforma Braswell. Gracias a su nuevo proceso de baja energía de 14 nanómetros (P1273) con transistores tri-gate, la eficiencia de la energía fue mejorada significativamente en comparación con su predecesor Bay Trail (por ejemplo, Pentium N3520). Además de los núcleos de CPU, el SoC ofrece una GPU con soporte para DirectX 11.2 así como un Controlador de Memoria DDR3L (2x 64 bits, 25,6 GB/s).

Es el sucesor del Pentium N3700 de 2016 y ofrece una velocidad Boost superior de 2,56 versus 2,4 GHz pero una velocidad base más baja de solo 1,1 versus 1,6 GHz. La GPU aun es la misma técnicamente, pero ahora con el nombre de Intel HD Graphics 405.

Arquitectura

Los núcleos del procesador se basan en la arquitectura Airmont, que es básicamente una modificación un poco reducida del anterior núcleo Silvermont. Aunque el rendimiento por núcleo no haya sido mejorado, en proceso más eficiente de 14 nm resulta en una mejor utilización del "Burst" de la CPU (alias Turbo Boost) y, por tanto un rendimiento un poco superior.

Rendimiento

En comparación con su predecesor el Pentium N3700, el N3710 puede ser más veloz si mantiene la velocidad Boost. Si el enfriamiento no es suficiente puede ser aun más lento. En nuestro primer modelo de prueba, el N3710 estaba a la par con un A6-5200 en el Cinebench R15 y, por tanto un poco más veloz que el N3700. Sin embargo, en la prueba física del 3DMark 11 fue igualmente veloz al N3700. Utilizando Windows, la CPU es adecuada para taras del día a día como la navegación por Internet o aplicaciones de oficina, pero podría sufrir con software más exigente.

Gráficos

La HD Graphics 405 (Braswell) se basa en la arquitectura Gen8 de Intel, que soporta DirectX 11,2 y también es encontrada en la serie Broadwell (por ejemplo, HD Graphics 5300). Con 16 EUs (Execution Units) y una velocidad de hasta 700 MHz, la GPU es casi el doble de veloz que la HD Graphics (Bay Trail) pero no suficientemente poderosa como manejar juegos exigentes del 2015: La GPU también soporta aceleración de vídeos 4K/H.265.

Consumo de Energía

Todo el SoC tiene un TDP de 6 watts (SDP 4 watts). Por eso el chip puede ser enfriado de forma pasiva, pero no en todos los dispositivos.

SerieIntel Pentium
Nombre códigoBraswell

Serie: Pentium Braswell

Intel Pentium N3710 « 1.6 - 2.56 GHz4 / 4 cores
Intel Pentium N37001.6 - 2.4 GHz4 / 4 cores
Velocidad de reloj1600 - 2560 MHz
Caché de Nivel 22 MB
Número de Núcleos/Subprocesos4 / 4
Consumo de Corriente (TDP = Thermal Design Power)6 Watt
Tecnología de producción14 nm
Temperatura Máx.90 °C
ConectorFCBGA1170
RecursosIntel HD Graphics 405 (Braswell, 400 - 700 MHz), Wireless Display, Quick Sync, AES-NI, max. 8 GB Dual-Channel DDR3L-1600 (25,6 GB/s), 5x USB 3.0, 4x PCIe 2.0, 2x SATA 6.0 Gbit/s
GPUIntel HD Graphics 405 (Braswell) (400 - 700 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$161 U.S.
Fecha de anuncio04/01/2016
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 105     de promedio: 139.7     mediana: 145 (1%)     max: 152 Points
31 -78%
...
133 -5%
133 -5%
134 -4%
Intel Atom x5-Z8550
134 -4%
AMD A4-6210
134.5 -4%
136 -3%
Intel Pentium N3700
138.4 -1%
AMD A6-7310
139 -1%
139.3 0%
Intel Pentium N3710
139.7
AMD E2-7110
140 0%
Intel Celeron 3865U
142 2%
145.8 4%
146.8 5%
Intel Core M-5Y51
149.7 7%
152 9%
152 9%
152 9%
153 10%
...
5600 3909%
max:
15842 11240%
0%
100%
0102030405060708090100110120130140Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 39     de promedio: 40.7     mediana: 41 (12%)     max: 42 Points
19 -53%
...
37.5 -8%
37.57 -8%
37.75 -7%
38.33 -6%
Intel Celeron N2840
38.67 -5%
38.7 -5%
38.9 -4%
39 -4%
39.5 -3%
Intel Pentium N3710
40.67
Intel Atom x7-E3950
41 1%
41.88 3%
42.45 4%
44 8%
44.03 8%
AMD A6-7310
44.5 9%
45.71 12%
AMD A4-7210
46 13%
47 16%
...
311 665%
max:
332 716%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.39     de promedio: 1.6     mediana: 1.6 (2%)     max: 1.89 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.48     de promedio: 0.5     mediana: 0.5 (12%)     max: 0.5 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 1238     de promedio: 1307     mediana: 1323.5 (8%)     max: 1344 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 3417     de promedio: 4370     mediana: 4653 (3%)     max: 4755 puntos
wPrime 2.10 - wPrime 2.0 1024m *
min: 718     de promedio: 725     mediana: 725 (9%)     max: 732 s
wPrime 2.10 - wPrime 2.0 32m *
min: 22.93     de promedio: 23.3     mediana: 23.3 (5%)     max: 23.59 s
WinRAR - WinRAR 4.0
1004 puntos (2%)
X264 HD Benchmark 4.0 - x264 Pass 2
10.7 fps (4%)
X264 HD Benchmark 4.0 - x264 Pass 1
52.8 fps (12%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (0%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (4%)
TrueCrypt - TrueCrypt AES
1 GB/s (3%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2362     de promedio: 2474     mediana: 2473.5 (5%)     max: 2585 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 34.16     de promedio: 35     mediana: 35 (8%)     max: 35.74 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 75.2     de promedio: 77     mediana: 77 (3%)     max: 78.7 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1626     de promedio: 1666     mediana: 1666 (7%)     max: 1706 s
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
5320 Points (5%)
3DMark 11 - 3DM11 Performance Physics
min: 1574     de promedio: 1751     mediana: 1742.5 (5%)     max: 1949 Points
3DMark - 3DMark Ice Storm Physics
min: 17238     de promedio: 18208     mediana: 18207.5 (15%)     max: 19177 Points
3DMark - 3DMark Ice Storm Extreme Physics
min: 12409     de promedio: 15741     mediana: 15740.5 (13%)     max: 19072 Points
3DMark - 3DMark Ice Storm Unlimited Physics
19869 Points (17%)
3DMark - 3DMark Cloud Gate Physics
min: 1400     de promedio: 1512     mediana: 1552 (4%)     max: 1584 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 1957     de promedio: 2158     mediana: 2157.5 (4%)     max: 2358 Points
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
1179 puntos (16%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
3433 puntos (8%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 3382     de promedio: 3472     mediana: 3480 (6%)     max: 3553 puntos
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 1012     de promedio: 1018     mediana: 1019 (20%)     max: 1023 puntos
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
3581 puntos (6%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
1068 puntos (16%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 4425     de promedio: 4564     mediana: 4564 (5%)     max: 4703 ms
Sunspider - Sunspider 1.0 Total Score *
361 ms (4%)
Octane V2 - Octane V2 Total Score
min: 7623     de promedio: 8328     mediana: 8327.5 (7%)     max: 9032 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
