Breve análisis del Asus F551MA-SX063H

Frugal. El F551MA no trae mucho rendimiento de procesado. Pero puntúa con un bajo consumo de energía y bajas emisiones. ¿Basta con eso para enfrentarse a la competencia del segmento de precios más bajos?
247
cd/m²
248
cd/m²
231
cd/m²
251
cd/m²
241
cd/m²
238
cd/m²
240
cd/m²
234
cd/m²
236
cd/m²
Temperatura del cuarto
ChiMei N156BGE-L21 tested with X-Rite i1Pro 2
Máximo: 251 cd/m² (Nits) Médio: 240.7 cd/m²
iluminación: 92 %
Brillo con batería: 244 cd/m²
Contraste: 301:1 (Negro: 0.8 cd/m²)
ΔE Color 4.7 | 0.5-29.43 Ø5
ΔE Greyscale 4.56 | 0.57-98 Ø5.3
56% AdobeRGB 1998 (Argyll 2.2.0 3D)
81.6% sRGB (Argyll 2.2.0 3D)
54.2% Display P3 (Argyll 2.2.0 3D)
Gamma: 2.84
Cinebench R11.5 CPU Single 64Bit
0.44 Points
Cinebench R11.5 CPU Multi 64Bit
1.75 Points
Cinebench R11.5 OpenGL 64Bit
6.53 fps
Cinebench R15 CPU Single 64Bit
38 Points
Cinebench R15 CPU Multi 64Bit
128 Points
Cinebench R15 OpenGL 64Bit
4.08 fps
Cinebench R15 Ref. Match 64Bit
97.8 %
ayuda
Cinebench R11.5 - CPU Single 64Bit (ordenar por valor)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
0.44 Points
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
0.23 Points -48%
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
0.38 Points -14%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
0.61 Points +39%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
1 Points +127%
Cinebench R11.5 - CPU Multi 64Bit (ordenar por valor)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
1.75 Points
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
0.46 Points -74%
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
1.47 Points -16%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
1.14 Points -35%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
1.94 Points +11%
PCMark 7 Score
1790 puntos
ayuda
PCMark 7 - Score (ordenar por valor)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
1790 Points
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
1051 Points -41%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
1484 Points -17%
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
1678 Points -6%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
2343 Points +31%
Western Digital Scorpio Blue WD5000LPVX
Sequential Read: 106.3 MB/s
Sequential Write: 104.1 MB/s
512K Read: 40.69 MB/s
512K Write: 57.1 MB/s
4K Read: 0.531 MB/s
4K Write: 1.593 MB/s
4K QD32 Read: 1.33 MB/s
4K QD32 Write: 1.605 MB/s
3DMark 11 Performance
261 puntos
3DMark Ice Storm Standard Score
20652 puntos
3DMark Cloud Gate Standard Score
1515 puntos
ayuda
3DMark 11 - 1280x720 Performance (ordenar por valor)
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
261 Points
Medion Akoya E6239T
HD Graphics (Bay Trail), N3510, Seagate Momentus SpinPoint M8 ST1000LM024 HN-M101MBB
240 Points -8%
HP Compaq 15-h024sg
Radeon HD 8210, E1-2100, Toshiba MQ01ABF050
369 Points +41%
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
390 Points +49%
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
480 Points +84%
bajo medio alto ultra
Dirt 3 (2011) 36.9 13.3
Counter-Strike: GO (2012) 46.6 23.9
Dishonored (2012) 14.3 11.2
Dead Space 3 (2013) 23.6 9.7
Tomb Raider (2013) 15.5 8.1
Battlefield 4 (2013) 7.3
Thief (2014) 5.1 3.3
The Elder Scrolls Online (2014) 25.2 9.2
Asus F551MA-SX063H
HD Graphics (Bay Trail), N3520, Western Digital Scorpio Blue WD5000LPVX
Acer Aspire E1-532
HD Graphics (Haswell), 2955U, Seagate Momentus Thin ST500LT0 12-9WS142
Lenovo G500s-59367693
HD Graphics (Ivy Bridge), 2020M, Seagate Momentus Thin ST500LT0 12-9WS142
Tomb Raider
86%
43%
1024x768 Low Preset
15.5
30.3
95%
23.1
49%
1366x768 Normal Preset AA:FX AF:4x
8.1
14.3
77%
11.1
37%

Ruido

Ocioso
30.4 / 30.4 / 30.4 dB(A)
HDD
30.6 dB(A)
DVD
36.3 / dB(A)
Carga
31.7 / 36.2 dB(A)
  red to green bar


30 dB
silencioso
40 dB(A)
audible
50 dB(A)
ruidosamente alto

min: dark, med: mid, max: light   Voltcraft sl-320 (15 cm de distancia)
Inactivo
 32.7 °C28 °C27.7 °C
 31.8 °C28 °C27.2 °C
 30.9 °C29.1 °C30.6 °C
Máximo: 32.7 °C
Médio: 29.6 °C
28.8 °C28.5 °C33.6 °C
28.6 °C28 °C31.6 °C
30.7 °C27.7 °C30.2 °C
Máximo: 33.6 °C
Médio: 29.7 °C
Conector de corriente  38.2 °C | Temperatura del cuarto 23.7 °C | Voltcraft IR-360
(+) The average temperature for the upper side under maximal load is 28.1 °C / 83 F, compared to the average of 29.5 °C / 85 F for the devices in the class Office.
(+) The maximum temperature on the upper side is 33.2 °C / 92 F, compared to the average of 34.2 °C / 94 F, ranging from 21.2 to 62.5 °C for the class Office.
(+) The bottom heats up to a maximum of 30.6 °C / 87 F, compared to the average of 36.7 °C / 98 F
(+) In idle usage, the average temperature for the upper side is 29.6 °C / 85 F, compared to the device average of 29.5 °C / 85 F.
(+) The palmrests and touchpad are cooler than skin temperature with a maximum of 30.9 °C / 87.6 F and are therefore cool to the touch.
(-) The average temperature of the palmrest area of similar devices was 27.7 °C / 81.9 F (-3.2 °C / -5.7 F).
Consumo de corriente
Off / Standbydarklight 0 / 0.3 Watt
Ociosodarkmidlight 5 / 8 / 8.6 Watt
Carga midlight 16.5 / 21.6 Watt
 color bar
Clave: min: dark, med: mid, max: light        Voltcraft VC 940
Currently we use the Metrahit Energy, a professional single phase power quality and energy measurement digital multimeter, for our measurements. Find out more about it here. All of our test methods can be found here.
Tiempo de Ejecución de la Batería
Navegando con WLAN
4h 16min

Con el F551MA-SX063H, Asus ofrece un sencillo portátil de oficina que sólo es viable para las tareas sencillas. El portátil sólo necesita un poco de energía y siempre funciona en silencio. Además, la batería aguanta bien en nuestro test realista WLAN. El display nos sorprendió: es bastante brillante y los colores son buenos, pero su contraste es bajo y los ángulos de visión son exiguos.

Si el precio es un criterio importante, el Aspire E1-532 es la mejor alternativa: su rendimiento CPU es mejor en aplicaciones monohilo, y cuenta con una GPU más potente. Además, la duración de la batería es mayor y funciona tan en silencio como el F551MA. Lo que es más, el display es mate y la garantía dura dos años. El Acer está a la venta por unos 270 Euros. Si le añades el coste de una licencia de Windows 8.1, el precio del Aspire es de unos 350 Euros. Así, la relación precio-rendimiento del Aspire es significativamente mejor que la del Asus.

El Lenovo G500s es el portátil a elegir si buscas el rendimiento CPU más alto posible. Cuesta unos 300 Euros (sin SO Windows).

Ésta es una versión acortada del análisis original. Puedes leer el análisis completo en inglés aquí.

Please share our article, every link counts!

especificaciones del portátil

Asus F551MA-SX063H
Procesador
Intel Pentium N3520 4 x 2.2 - 2.4 GHz, Bay Trail-M
Adaptador gráfico
Intel HD Graphics (Bay Trail), Núcleo: 820 MHz, 10.18.10.3355
Memoría
4 GB
, DDR3, monocanal, soldada, sin ranuras RAM
pantalla
15.60 pulgadas 16:9, 1366 x 768 pixels, ChiMei N156BGE-L21, lustroso: si
Placa base
Bay Trail Host Bridge
Disco duro
Western Digital Scorpio Blue WD5000LPVX, 500 GB
, 5400 rpm, 408 GB libre
Tarjeta de sonido
Intel Valleyview SoC - HD Audio Controller
Conexiones
1 USB 2.0, 1 USB 3.0, 1 VGA, 1 HDMI, 1 Kensington Lock, Audio Conexiones: combinación audio, Card Reader: SD
Equipamento de red
Realtek RTL8102E Family PCI-E Fast Ethernet (10/100MBit/s), Realtek RTL8821AE 802.11ac (), Bluetooth 4.0
Unidad óptica
Matshita DVD-RAM UJ8E1
Tamaño
Alto x ancho x profundidad (en mm): 36.6 x 380 x 251
Battería
33 Wh Litio-Ion
Sistema Operativo
Microsoft Windows 8 64 Bit
Camera
Webcam: webcam HD
Características adicionales
Altavoces: Estéreo, Teclado: Chiclet, Luz de Teclado: no, AsusDVD, Microsoft Office 365 (prueba), Windows Essentials 2012, 12 Meses Garantía
Peso
2.15 kg, Suministro de Electricidad: 137 g
Precio
379 Euros



Portátiles similares de otros fabricantes

Portátiles similares de otros fabricantes y con otro CPU

Breve análisis del Lenovo B50-10 80QR0013GE
HD Graphics (Bay Trail), Pentium N3540
Breve análisis del Lenovo IdeaPad 100-15
HD Graphics (Bay Trail), Pentium N3540
Breve análisis del Acer Aspire E15 Start ES1-512-P1SM
HD Graphics (Bay Trail), Pentium N3540
Breve análisis del portátil Dell Inspiron 15-3531
HD Graphics (Bay Trail), Celeron N2830
Breve actualización del Acer Aspire E15 ES1-511-C50C
HD Graphics (Bay Trail), Celeron N2930
Breve análisis del HP 250 G3
HD Graphics (Bay Trail), Celeron N2830

Pro

+Funciona en silencio
+Bajo consumo de energía
+Relativamente fresco


Contra

-Sólo 12 meses de garantía
-Display de bajo contraste

Asus F551MA-SX063H - 05/01/2014 v4(old)
Sascha Mölck

Acabado
62 / 98 → 63%
Teclado
67%
Ratón
67%
Conectividad
60 / 80 → 75%
Peso
62 / 20-67 → 89%
Battería
84%
Pantalla
72%
Rendimiento de juegos
34 / 68 → 50%
Rendimiento de la Aplicación
53 / 92 → 58%
Temperatura
92%
Ruido
93%
Audio
50%
Cámara
35 / 85 → 41%
Médio
64%
72%
Office - media ponderada
Sascha Mölck, 2014-05-16 (Update: 2014-05-16)
