Intel Atom Z530

Intel Z530

El Intel Atom Z530 es un procesador energéticamente eficiente para netbooks / MID de un nucleo. Comparado con el Atom N270, el Z530 soporta virtualización por Hardware y tiene los Estados de Reposo y las funciones de Intercambio Basadas en la Demanda (Idle States y Demand Based Switching Functions).

El nucleo Atom se diseño para un consumo bajo y una producción barata. Lo malo es el relativamente bajo rendimiento por vatio (debido a la ejecución in-order) comparado con procesadores Celeron a velocidad similar. Aunque la tecnologia Hyperthreading (el sistema operativo ve la CPU como una CPU de doble nucleo) minimiza un poco la penalización de la ejecución in-order.

El rendimiento del Z530 solo es comparable a un Celeron a 1.2 GHz y por tanto solo es suficiente para aplicaciones no exigentes como Office o navegación web. Videos en HD, edición avanzada de fotografiaso edicion de video podrían no funcionar de forma fluida.

SerieIntel Atom
Nombre códigoSilverthorne

Serie: Atom Silverthorne

Intel Atom Z5602.13 GHz1 / 2 cores
Intel Atom Z5502 GHz1 / 2 cores
Intel Atom Z5401.83 GHz1 / 2 cores
Intel Atom 2301.6 GHz1 / 2 cores
Intel Atom Z530 « 1.6 GHz1 / 2 cores
Intel Atom Z5201.33 GHz1 / 2 cores
Intel Atom Z5101.1 GHz1 / 1 cores
Intel Atom Z5000.8 GHz1 / 1 cores
Velocidad de reloj1600 MHz
Bus Frontal533
Caché de Nivel 2512 KB
Número de Núcleos/Subprocesos1 / 2
Consumo de Corriente (TDP = Thermal Design Power)2 Watt
Conteo de Transistores47 Millón
Recursos45 nm, 0.75-1.1V
Tamaño de Matriz26 mm2
Temperatura Máx.90 °C
ConectorPBGA441
RecursosMMX, SSE, SSE2, SSE3, SSSE3, Hyperthreading, Virtualization Technology (VT-x), Idle States, Enhanced Speedstep, Demand Based Switching, Ex Bit
Architecturex86
Fecha de anuncio03/01/2008
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 531     de promedio: 537     mediana: 537 (3%)     max: 541 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 805     de promedio: 817     mediana: 817.5 (1%)     max: 827 puntos
wPrime 2.10 - wPrime 2.0 1024m *
min: 3887     de promedio: 3995     mediana: 3928 (46%)     max: 4170 s
wPrime 2.10 - wPrime 2.0 32m *
min: 121.8     de promedio: 125.9     mediana: 123 (25%)     max: 133 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 440     de promedio: 458.5     mediana: 458.5 (1%)     max: 477 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 93     de promedio: 99.3     mediana: 98 (21%)     max: 108 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 209     de promedio: 217.7     mediana: 218 (9%)     max: 226 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 4671     de promedio: 4751     mediana: 4777 (21%)     max: 4804 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 3953     de promedio: 3994     mediana: 3994 (2%)     max: 4035 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 3302     de promedio: 3334     mediana: 3334 (3%)     max: 3366 MFLOPS
PCMark 05 - PCMark 05 - Standard
min: 820     de promedio: 1019     mediana: 1018.5 (2%)     max: 1217 Points
Windows 7 Experience Index - Win7 CPU
2.2 Points (28%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
