Intel Atom Z3770

Intel Z3770

El Intel Atom Z3770 es un SoC quad-core energéticamente eficiente para tablets Windows y Android. Tiene una frecuencia de 1,46 - 2,4 GHz y parte de la plataforma Bay Trail-T. Gracias al proceso especialmente optimizado para baja energía de 22 nanómetros (P1271) con transistores tri-gate, el rendimiento y la eficiencia de la energía fueron significantemente mejorados en comparación con su antecesor.

Arquitectura

Los núcleos del procesador se basan en la nueva arquitectura Silvermont, que es un diseño fuera de orden, por primera vez. El aumento de la utilización del pipeline y muchas otras mejoras (previsión de ramo optimizada, buffers aumentados, decodificadores mejorados) aumentaron el rendimiento en cerca de 50 porciento. Al mismo tiempo, sin embargo, el recurso Hyper-Threading de la generación anterior fue removido. Otros cambios importantes son el soporte para nuevas extensiones del conjunto de instrucciones como SSE 4.1 y 4.2, sí como AES-NI (dependiendo del modelo).

Rendimiento

Gracias a los 4 núcleos de la CPU y una frecuencia de 1,46 - 2,4 GHz, el Z3770 es significantemente más veloz que anteriores Atoms de Intel, por ejemplo, el Z2760. El Z3770 incluso supera algunas de las APUs Kabini como el AMD A4-5000, así como SoCs ARM, como el Tegra 4 y el Snapdragon 800. Para las tareas del día a día, como Internet o Escritorio, el rendimiento es adecuado, pero no para software muy complejo o juegos modernos. Un primer benchmark Cinebench R11.5 filtrado (infelizmente sólo 32 Bits) coloca el Z3770 en la prueba multi core en un nivel de un Celeron Ivy Bridge de 1,8 GHz.

Gráficos

La HD Graphics (Bay Trail) se basa en la arquitectura Gen7 de Intel, que soporta DirectX 11 y también es encontrada en la serie Ivy Bridge (por ejemplo, HD Graphics 4000). Con sólo 4 EUs (Execution Units) y una frecuencia relativamente baja de hasta 667 MHz, una GPU es aun más lenta que la HD Graphics (Ivy Bridge) y similar a la Qualcomm Adreno 320 (como fue observado en el Snapdragon 600). Por tanto, sólo juegos de Windows antiguos y menos exigentes podrán ejecutarse fluentemente. Sin embargo, la aceleración de video y las resoluciones de pantallas de hasta 2560 x 1600 pixeles no son problema para el chip.

Consumo de Energía

Todo el SoC tiene un SDP de 2 watts, lo que indica un TDP de menos de 4 watts. Por eso el chip puede ser usado en tablets con enfriamiento pasivo.

SerieIntel Atom
Nombre códigoBay Trail-T

Serie: Atom Bay Trail-T

Intel Atom Z37951.59 - 2.39 GHz4 / 4 cores
Intel Atom Z37851.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37751.46 - 2.39 GHz4 / 4 cores
Intel Atom Z3775D1.49 - 2.41 GHz4 / 4 cores
Intel Atom Z3770 « 1.46 - 2.4 GHz4 / 4 cores
Intel Atom Z3770D1.5 - 2.41 GHz4 / 4 cores
Intel Atom Z3736F1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z3736G1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z37451.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3745D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z37401.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3740D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735E1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735F1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735G1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z36801.33 - 2 GHz2 / 2 cores
Intel Atom Z3680D1.33 - 2 GHz2 / 2 cores
Velocidad de reloj1460 - 2400 MHz
Caché de Nivel 1224 KB
Caché de Nivel 22 MB
Número de Núcleos/Subprocesos4 / 4
Consumo de Corriente (TDP = Thermal Design Power)<4 Watt
Tecnología de producción22 nm
ConectorUTFCBGA1380
RecursosIntel HD Graphics (Bay Trail, 311 - 667 MHz), Quick Sync, Wireless Display, Clear Video HD, Intel 64, SSE 4.1, SSE 4.2, AES-NI, Secure Key, Anti-Theft, Identify-Protection, max. 4 GB Dual-Channel LPDDR3-1067
GPUIntel HD Graphics (Bay Trail) (311 - 667 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$37 U.S.
Fecha de anuncio09/11/2013
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 997     de promedio: 1158     mediana: 1189 (7%)     max: 1230 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 2848     de promedio: 3691     mediana: 3961 (3%)     max: 4035 puntos
wPrime 2.10 - wPrime 2.0 1024m *
min: 837     de promedio: 922     mediana: 862.5 (10%)     max: 1126 s
wPrime 2.10 - wPrime 2.0 32m *
min: 24     de promedio: 25.9     mediana: 26.6 (5%)     max: 26.6 s
WinRAR - WinRAR 4.0
898 puntos (1%)
X264 HD Benchmark 4.0 - x264 Pass 2
min: 6.2     de promedio: 7.8     mediana: 7.7 (3%)     max: 9.5 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 31.5     de promedio: 39.3     mediana: 40.5 (9%)     max: 45.9 fps
TrueCrypt - TrueCrypt Serpent
min: 0.077     de promedio: 0.1     mediana: 0.1 (4%)     max: 0.123 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.12     de promedio: 0.2     mediana: 0.2 (3%)     max: 0.193 GB/s
TrueCrypt - TrueCrypt AES
min: 0.44     de promedio: 0.8     mediana: 0.9 (2%)     max: 0.886 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2203     de promedio: 2212     mediana: 2212 (5%)     max: 2221 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 27     de promedio: 33.3     mediana: 36 (8%)     max: 37 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 61     de promedio: 74     mediana: 80 (3%)     max: 81 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1566     de promedio: 1686     mediana: 1735 (8%)     max: 1756 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 15.66     de promedio: 7984     mediana: 7984.3 (4%)     max: 15953 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 7.38     de promedio: 3731     mediana: 3730.7 (3%)     max: 7454 MFLOPS
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 3379     de promedio: 4057     mediana: 4056.5 (4%)     max: 4734 Points
3DMark 11 - 3DM11 Performance Physics
min: 1199     de promedio: 1353     mediana: 1330 (4%)     max: 1512 Points
3DMark - 3DMark Ice Storm Physics
min: 11561     de promedio: 16054     mediana: 17754 (14%)     max: 18706 Points
3DMark - 3DMark Ice Storm Extreme Physics
min: 17931     de promedio: 18729     mediana: 18754 (15%)     max: 19503 Points
3DMark - 3DMark Cloud Gate Physics
min: 956     de promedio: 1316     mediana: 1471 (4%)     max: 1555 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 1348     de promedio: 1748     mediana: 1748 (3%)     max: 2148 Points
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 2998     de promedio: 3035     mediana: 3035 (5%)     max: 3072 puntos
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 977     de promedio: 981     mediana: 980.5 (19%)     max: 984 puntos
Geekbench 2 - 32 Bit - Geekbench Stream
min: 2472     de promedio: 2523     mediana: 2522.5 (20%)     max: 2573 Points
Geekbench 2 - 32 Bit - Geekbench Memory
min: 2278     de promedio: 2358     mediana: 2357.5 (21%)     max: 2437 Points
Geekbench 2 - 32 Bit - Geekbench Floating Point
min: 3092     de promedio: 3110     mediana: 3110 (6%)     max: 3128 Points
Geekbench 2 - 32 Bit - Geekbench Integer
min: 3617     de promedio: 3637     mediana: 3637 (7%)     max: 3657 Points
Geekbench 2 - 32 Bit - Geekbench Total Score
min: 3063     de promedio: 3085     mediana: 3084.5 (8%)     max: 3106 Points
Linpack Android / IOS - Linpack Multi Thread
717 MFLOPS (24%)
Linpack Android / IOS - Linpack Single Thread
265 MFLOPS (26%)
Sunspider - Sunspider 1.0 Total Score *
567 ms (6%)
Sunspider - Sunspider 0.9.1 Total Score *
577 ms (5%)
Quadrant Standard Edition 2.0 - Quadrant Standard 2.0 Total Score
22792 points (53%)
AnTuTu v4 - AnTuTu v4 Total Score
36357 Points (85%)
AndEBench - AndEBench Java
428 Iter./s (13%)
AndEBench - AndEBench Native
21235 Iter./s (70%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
