Intel Atom Z3740

Intel Z3740

El Intel Atom Z3740 es un SoC quad-core energéticamente eficiente para tablets Windows y Android. Tiene una frecuencia de 1,33 - 1,8 GHz y parte de la plataforma Bay Trail-T. Gracias al proceso especialmente optimizado para baja energía de 22 nanómetros (P1271) con transistores tri-gate, el rendimiento y la eficiencia de la energía fueron significantemente mejorados en comparación con su antecesor.

Arquitectura

Los núcleos del procesador se basan en la nueva arquitectura Silvermont, que es un diseño fuera de orden, por primera vez. El aumento de la utilización del pipeline y muchas otras mejoras (previsión de ramo optimizada, buffers aumentados, decodificadores mejorados) aumentaron el rendimiento en cerca de 50 porciento. Al mismo tiempo, sin embargo, el recurso Hyper-Threading de la generación anterior fue removido. Otros cambios importantes son el soporte para nuevas extensiones del conjunto de instrucciones como SSE 4.1 y 4.2, sí como AES-NI (dependiendo del modelo).

Rendimiento

Gracias a los 4 núcleos de la CPU y a la frecuencia mejorada por núcleo, el Z3770 es significantemente más veloz que anteriores Atoms de Intel, por ejemplo, el Z2760. Aparentemente, el Z3740 consigue competir con APUs Kabini como el AMD A4-5000. Para las tareas del día a día, como Internet o Escritorio, el rendimiento es adecuado, pero no para software muy complejo o juegos modernos.

Gráficos

La HD Graphics (Bay Trail) se basa en la arquitectura Gen7 de Intel, que soporta DirectX 11 y también es encontrada en la serie Ivy Bridge (por ejemplo, HD Graphics 4000). Con sólo 4 EUs (Execution Units) y una frecuencia relativamente baja de hasta 667 MHz, la GPU es aun más lenta que la HD Graphics (Ivy Bridge). Por tanto, sólo juegos de Windows antiguos y menos exigentes podrán ejecutarse fluentemente. Sin embargo, la aceleración de video y las resoluciones de pantallas de hasta 2560 x 1600 pixeles no son problema para el chip.

Consumo de Energía

Todo el SoC tiene un SDP de 2 watts, lo que indica un TDP de menos de 4 watts. Por eso el chip puede ser usado en tablets con enfriamiento pasivo.

SerieIntel Atom
Nombre códigoBay Trail-T

Serie: Atom Bay Trail-T

Intel Atom Z37951.59 - 2.39 GHz4 / 4 cores
Intel Atom Z37851.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37751.46 - 2.39 GHz4 / 4 cores
Intel Atom Z3775D1.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37701.46 - 2.4 GHz4 / 4 cores
Intel Atom Z3770D1.5 - 2.41 GHz4 / 4 cores
Intel Atom Z3736F1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z3736G1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z37451.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3745D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3740 « 1.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3740D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735E1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735F1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735G1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z36801.33 - 2 GHz2 / 2 cores
Intel Atom Z3680D1.33 - 2 GHz2 / 2 cores
Velocidad de reloj1330 - 1860 MHz
Caché de Nivel 1224 KB
Caché de Nivel 22 MB
Número de Núcleos/Subprocesos4 / 4
Consumo de Corriente (TDP = Thermal Design Power)<4 Watt
Tecnología de producción22 nm
ConectorUTFCBGA1380
RecursosIntel HD Graphics (Bay Trail, 311 - 667 MHz), Quick Sync, Wireless Display, Clear Video HD, Intel 64, SSE 4.1, SSE 4.2, AES-NI, Secure Key, Anti-Theft, Identify-Protection, max. 4 GB Dual-Channel LPDDR3-1067
GPUIntel HD Graphics (Bay Trail) (311 - 667 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$32 U.S.
Fecha de anuncio09/11/2013
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 940     de promedio: 957     mediana: 963 (6%)     max: 971 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 3334     de promedio: 3368     mediana: 3380 (2%)     max: 3390 puntos
wPrime 2.10 - wPrime 2.0 1024m *
909 s (11%)
wPrime 2.10 - wPrime 2.0 32m *
29 s (6%)
WinRAR - WinRAR 4.0
1569 puntos (2%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (3%)
TrueCrypt - TrueCrypt Twofish
min: 0.158     de promedio: 0.2     mediana: 0.2 (3%)     max: 0.159 GB/s
TrueCrypt - TrueCrypt AES
min: 0.724     de promedio: 0.7     mediana: 0.7 (2%)     max: 0.734 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 1763     de promedio: 1827     mediana: 1838 (4%)     max: 1880 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 22     de promedio: 24.5     mediana: 24.5 (5%)     max: 27 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 61     de promedio: 80     mediana: 80 (3%)     max: 99 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1566     de promedio: 1847     mediana: 1847 (8%)     max: 2128 s
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
4037 Points (4%)
3DMark 11 - 3DM11 Performance Physics
min: 1141     de promedio: 1234     mediana: 1234 (3%)     max: 1327 Points
3DMark - 3DMark Ice Storm Physics
min: 9768     de promedio: 14295     mediana: 15537 (13%)     max: 16336 Points
3DMark - 3DMark Cloud Gate Physics
min: 1176     de promedio: 1239     mediana: 1248 (3%)     max: 1283 Points
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
2617 puntos (5%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
792 puntos (15%)
Geekbench 2 - 32 Bit - Geekbench Stream
min: 2295     de promedio: 2304     mediana: 2302 (19%)     max: 2317 Points
Geekbench 2 - 32 Bit - Geekbench Memory
min: 2069     de promedio: 2082     mediana: 2077 (19%)     max: 2103 Points
Geekbench 2 - 32 Bit - Geekbench Floating Point
min: 2598     de promedio: 2610     mediana: 2609.5 (5%)     max: 2621 Points
Geekbench 2 - 32 Bit - Geekbench Integer
min: 2942     de promedio: 2956     mediana: 2950 (6%)     max: 2980 Points
Geekbench 2 - 32 Bit - Geekbench Total Score
min: 2586     de promedio: 2594     mediana: 2591.5 (7%)     max: 2607 Points
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
5745 ms (7%)
Sunspider - Sunspider 1.0 Total Score *
min: 394.7     de promedio: 504     mediana: 550 (6%)     max: 567 ms
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
