Intel Atom Z3740D

Intel Z3740D

El Intel Atom Z3740D es un SoC quad-core energéticamente eficiente para tablets Windows y Android. Tiene una frecuencia de 1,33 - 1,8 GHz y es parte de la plataforma Bay Trail-T. Gracias al proceso especialmente optimizado para baja energía de 22 nm (P1271) con transistores Tri-Gate, el rendimiento y la eficiencia de la energía fueron significantemente mejorados en comparación con su antecesor. En contraste con el Z3740, el Z3740D ofrece sólo un controlador de memoria single-channel y una resolución de pantalla más baja.

Arquitectura

Los núcleos del procesador se basan en la nueva arquitectura Silvermont, que es un diseño fuera de orden, por primera vez. El aumento de la utilización del pipeline y muchas otras mejoras (previsión de ramo optimizada, buffers aumentados, y decodificadores mejorados) aumentaron el rendimiento en cerca de 50 porciento. Al mismo tiempo, sin embargo, el recurso Hyper-Threading de la generación anterior fue removido. Otras adiciones importantes son el soporte para nuevas extensiones del conjunto de instrucciones como SSE 4.1 y 4.2, sí como AES-NI (dependiendo del modelo).

Rendimiento

Gracias a los 4 núcleos de la CPU y a la frecuencia mejorada por núcleo, el Z3740D es significantemente más veloz que anteriores Atoms de Intel, como el Z2760. Aparentemente, el Z3740D consigue competir con APUs Kabini como el AMD A4-5000. Para las tareas del día a día, como Internet o Escritorio, el rendimiento es adecuado, pero no para software muy complejo o juegos modernos.

Gráficos

La HD Graphics (Bay Trail) se basa en la arquitectura Gen7 de Intel, que soporta DirectX 11 y también es encontrada en la serie Ivy Bridge (por ejemplo, HD Graphics 4000). Con sólo 4 EUs (Execution Units) y una frecuencia relativamente baja de hasta 688 MHz, la GPU es aun más lenta que la HD Graphics (Ivy Bridge). Por tanto, sólo juegos de Windows antiguos y menos exigentes podrán ejecutarse fluentemente. Sin embargo, la aceleración de video y las resoluciones de pantallas de hasta 1920 x 1200 pixeles no son problema para el chip.

Consumo de Energía

Todo el SoC tiene un SDP de 2,2 - 2,4 W, que indica un TDP de menos de 4 W. Por eso el chip puede ser usado en tablets con enfriamiento pasivo.

SerieIntel Atom
Nombre códigoBay Trail-T

Serie: Atom Bay Trail-T

Intel Atom Z37951.59 - 2.39 GHz4 / 4 cores
Intel Atom Z37851.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37751.46 - 2.39 GHz4 / 4 cores
Intel Atom Z3775D1.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37701.46 - 2.4 GHz4 / 4 cores
Intel Atom Z3770D1.5 - 2.41 GHz4 / 4 cores
Intel Atom Z3736F1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z3736G1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z37451.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3745D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z37401.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3740D « 1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735E1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735F1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735G1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z36801.33 - 2 GHz2 / 2 cores
Intel Atom Z3680D1.33 - 2 GHz2 / 2 cores
Velocidad de reloj1330 - 1830 MHz
Caché de Nivel 1224 KB
Caché de Nivel 22 MB
Número de Núcleos/Subprocesos4 / 4
Consumo de Corriente (TDP = Thermal Design Power)<4 Watt
Tecnología de producción22 nm
ConectorUTFCBGA1380
RecursosIntel HD Graphics (Bay Trail, 313 - 688 MHz), Quick Sync, Wireless Display, Clear Video HD, Intel 64, SSE 4.1, SSE 4.2, AES-NI, Secure Key, Anti-Theft, Identify-Protection, max. 2 GB Single-Channel DDR3L-RS 1333, Quick Sync
GPUIntel HD Graphics (Bay Trail) (313 - 688 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$32 U.S.
Fecha de anuncio09/11/2013
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 685     de promedio: 895     mediana: 963 (6%)     max: 968 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 2442     de promedio: 3047     mediana: 3222.5 (2%)     max: 3301 puntos
wPrime 2.10 - wPrime 2.0 1024m *
1002 s (12%)
wPrime 2.10 - wPrime 2.0 32m *
31.9 s (6%)
WinRAR - WinRAR 4.0
min: 1378     de promedio: 1557     mediana: 1556.5 (2%)     max: 1735 puntos
X264 HD Benchmark 4.0 - x264 Pass 2
7.8 fps (3%)
X264 HD Benchmark 4.0 - x264 Pass 1
31.9 fps (7%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (3%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (3%)
TrueCrypt - TrueCrypt AES
0.7 GB/s (2%)
3DMark 06 - CPU - 3DMark 06 - CPU
1827 Points (4%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 45.14     de promedio: 45.6     mediana: 45.6 (10%)     max: 46.08 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 98.3     de promedio: 99.4     mediana: 99.4 (4%)     max: 100.5 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 2106     de promedio: 2122     mediana: 2122 (9%)     max: 2138 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
19790 MIPS (9%)
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
9280 MFLOPS (7%)
3DMark 11 - 3DM11 Performance Physics
min: 1049     de promedio: 1233     mediana: 1266.5 (3%)     max: 1350 Points
3DMark - 3DMark Ice Storm Physics
14993 Points (12%)
3DMark - 3DMark Ice Storm Unlimited Physics
12461 Points (10%)
3DMark - 3DMark Cloud Gate Physics
1269 Points (3%)
Geekbench 2 - 32 Bit - Geekbench Stream
2282 Points (18%)
Geekbench 2 - 32 Bit - Geekbench Memory
2068 Points (19%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
2602 Points (5%)
Geekbench 2 - 32 Bit - Geekbench Integer
2939 Points (6%)
Geekbench 2 - 32 Bit - Geekbench Total Score
2581 Points (7%)
Sunspider - Sunspider 1.0 Total Score *
min: 423.6     de promedio: 671     mediana: 586 (6%)     max: 1002 ms
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
