Intel Core i7-7567U

Intel i7-7567U

El Intel Core i7-7567U es un veloz SoC dual-core para portátiles, basado en la arquitectura Kaby Lake y fue anunciado en enero de 2017. La CPU tiene dos núcleos de procesador con velocidades de 3,5-4 GHz (dos núcleos hasta 3,9 GHz). El procesador puede ejecutar hasta cuatro threads simultáneamente gracias al Hyper Threading. También está equipado con una GPU Intel Iris Plus Graphics 650 con 64 MB de eDRAM, un controlador de memoria dual-channel (DDR4), y de- codificador de vídeos VP9 y H.265. El chip aun es producido en un proceso de 14 nm con transistores FinFET.

Comparado con el Core i7-7560, el 7567U tiene un TDP más alto de 28 vs. 15 Watts, así como velocidades superiores.

Arquitectura

Intel básicamente utiliza la misma micro arquitectura comparada con Skylake, por ellos, el rendimiento por-MHz no se diferencia. El fabricante solo reformuló la tecnología Speed Shift para ajustes dinámicos más veloces de voltajes y frecuencias, y el mejorado proceso de 14nm permite frecuencias mucho más altas, combinado con mejor eficiencia que antes.

Rendimiento

Gracias a las altas velocidades de hasta 4 GHz y 64 MB de eDRAM (también puede ser utilizada como cache L4 por la CPU), el Core i7-7567U es el dual-core más veloz para portátiles a principios del 2017. Compite con modelos quad-core de menos velocidad y puede convencer por su excelente rendimiento single-thread. Sin embargo, algunos juegos pueden requerir un verdadero quad-core y podrían no correr perfectamente en el dual-core, a pesar del Hyper Threading.

Gráficos

La Intel Iris Plus 650 Graphics integrada es el modelo GT3e de la GPU Kaby Lake (Intel Gen. 9,5). Posee 48 Unidades de Ejecución corriendo a 300-1100 MHz y el rendimiento es comparable al de una GeForce 920MX gracias al veloz cache eDRAM. Sin embargo, no existen mejorías significantes, en comparación con la antigua Iris Pro 550, por tanto, los juegos modernos, a menudo, no podrán ser jugados fluidamente o solo con las configuraciones más bajas o medianas, respectivamente.

Contrario a Skylake, Kaby Lake también soporta H.265/HEVC Main 10 con una profundidad de colores de 10-bits, así como el códec VP9 de Google. Los procesadores dual-core Kaby Lake, anunciados en enero, también deben soportar HDCP 2.2.

Consumo de Energía

El chip es producido en un proceso de 14nm mejorado, con transistores FinFET, que mejoran la eficiencia aun más. Intel especifica el TDP con 28 Watts, lo que puede ser reducido a 23 Watts (cTDP Down) dependiendo del escenario de uso. El TDP es bastante alto, en comparación con el habitual TDP de 15-Watts para procesadores dual-core, pero permite una mejor utilización del Turbo de la CPU y GPU.

SerieIntel Kaby Lake
Nombre códigoKaby Lake

Serie: Kaby Lake Kaby Lake

Intel Core i7-7700K4.2 - 4.5 GHz4 / 8 cores8 MB L3
Intel Core i7-77003.6 - 4.2 GHz4 / 8 cores8 MB L3
Intel Xeon E3-1535M v63.1 - 4.2 GHz4 / 8 cores8 MB L3
Intel Core i7-7920HQ3.1 - 4.1 GHz4 / 8 cores8 MB L3
Intel Core i7-7700T2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i5-7600K3.8 - 4.2 GHz4 / 4 cores8 MB L3
Intel Xeon E3-1505M v63 - 4 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HQ2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HK2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7700HQ2.8 - 3.8 GHz4 / 8 cores6 MB L3
Intel Core i5-75003.4 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i5-7440HQ2.8 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i7-7567U « 3.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7660U2.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7600U2.8 - 3.9 GHz2 / 4 cores4 MB L3
Intel Core i5-7300HQ2.5 - 3.5 GHz4 / 4 cores6 MB L3
Intel Core i5-7500T2.7 - 3.3 GHz4 / 4 cores6 MB L3
Intel Core i5-7287U3.3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-7560U2.4 - 3.8 GHz2 / 4 cores4 MB L3
Intel Core i5-7267U3.1 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7360U2.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-7500U2.7 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7300U2.6 - 3.5 GHz2 / 4 cores3 MB L3
Intel Core i5-7260U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i5-7200U2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i3-7100H3 GHz2 / 4 cores3 MB L3
Intel Core i3-7167U2.8 GHz2 / 4 cores3 MB L3
Intel Core i7-7Y751.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y571.2 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y541.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i3-7100U2.4 GHz2 / 4 cores3 MB L3
Intel Core m3-7Y321 - 3 GHz2 / 4 cores4 MB L3
Intel Pentium Gold 4415U2.3 GHz2 / 4 cores2 MB L3
Intel Core m3-7Y301 - 2.6 GHz2 / 4 cores4 MB L3
Intel Celeron 3965U2.2 GHz2 / 2 cores2 MB L3
Intel Core i3-7020U2.3 GHz2 / 4 cores3 MB L3
Intel Celeron 3867U1.8 GHz2 / 2 cores2 MB L3
Intel Celeron 3865U1.8 GHz2 / 2 cores2 MB L3
Intel Pentium Gold 4425Y1.7 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4415Y1.6 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4410Y1.5 GHz2 / 4 cores2 MB L3
Intel Celeron 3965Y1.5 GHz2 / 2 cores2 MB L3
Velocidad de reloj3500 - 4000 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)28 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA1356
RecursosDual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel Iris Plus Graphics 650 (300 - 1100 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$415 U.S.
Fecha de anuncio01/03/2017
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
432 Points (3%)
31 -93%
...
Intel Core i5-7260U
373 -14%
382 -12%
Intel Core i5-7267U
383 -11%
390.8 -10%
400 -7%
403.5 -7%
416 -4%
422.5 -2%
429.8 -1%
Intel Core i7-7567U
432
437 1%
448 4%
461.6 7%
466.8 8%
471 9%
479 11%
AMD Ryzen 3 PRO 3300U
481 11%
501 16%
510 18%
...
5600 1196%
max:
15842 3567%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
159 Points (48%)
19 -88%
...
Intel Core i7-7700HQ
155.4 -2%
155.8 -2%
Intel Core i5-8260U
156.9 -1%
157 -1%
Intel Core i5-8305G
157 -1%
157.7 -1%
158 -1%
Intel Core i7-8709G
158 -1%
158.5 0%
Intel Core i7-7567U
159
159.3 0%
159.5 0%
159.5 0%
160.4 1%
160.9 1%
161 1%
162.7 2%
163 3%
163 3%
...
311 96%
max:
332 109%
0%
100%
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
8847 puntos (14%)
1079 -88%
...
7496 -15%
7529 -15%
7635 -14%
Intel Core i3-8145U
7690 -13%
7946 -10%
8128 -8%
Intel Core i5-7360U
8265 -7%
8312 -6%
8570 -3%
Intel Core i7-7567U
8847
9974 13%
10881 23%
11467 30%
11774 33%
12555 42%
12834 45%
12845 45%
AMD Ryzen 5 PRO 2500U
12956 46%
Intel Core i5-8265U
13021 47%
...
Intel Core i5-1230U
24369 175%
max:
63872 622%
0%
100%
Geekbench 3 - Geekbench 3 64 Bit Single-Core
4150 puntos (62%)
634 -85%
...
3878 -7%
3885 -6%
3898 -6%
Intel Core i5-8265U
3906 -6%
3949 -5%
3983 -4%
4074 -2%
4080 -2%
4112 -1%
Intel Core i7-7567U
4150
4162 0%
4202 1%
4224 2%
4278 3%
4291 3%
4294 3%
4309 4%
4432 7%
Intel Core i7-8559U
4494 8%
...
Intel Core i5-1230U
5835 41%
max:
6624 60%
0%
100%
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
