Intel Core i3-7100H

Intel i3-7100H

El Intel Core i3-7100H es un veloz procesador dual-core para portátiles, basado en la arquitectura Kaby Lake y fue anunciado en enero de 2017. Probablemente se basa en la matriz quad-core de los otros procesadores de la serie H, con dos núcleos desactivados, considerando el TDP y la HD Graphics 630 integrada. Los dos núcleos de CPU corren a 3GHZ sin un Turbo, y el procesador puede ejecutar hasta cuatro threads simultáneamente gracias al Hyper Threading. También está equipado con una GPU Intel HD Graphics 630, un controlador de memoria dual-channel (DDR4), y de- codificador de vídeos VP9 y H.265. El chip aun es producido en un proceso de 14 nm con transistores FinFET.

Arquitectura

Intel básicamente utiliza la misma micro arquitectura comparada con Skylake, por ellos, el rendimiento por-MHz no se diferencia. El fabricante solo reformuló la tecnología Speed Shift para ajustes dinámicos más veloces de voltajes y frecuencias, y el mejorado proceso de 14nm permite frecuencias mucho más altas, combinado con mejor eficiencia que antes.

Rendimiento

Comparado con el Core i3-7100U (2.4 GHz, TDP de 15-Watts) de marca similar, pero mucho más eficiente, el i3-7100H posee velocidades mucho más altas y el rendimiento está casi al mismo nivel del Core i5-7200U (2,5-3,1 GHz).

Gráficos

La Intel HD Graphics 630 integrada tiene 24 Unidades de Ejecución (similar a la anterior HD Graphics 530) corriendo a 350 - 950 MHz en este caso. El rendimiento depende mucho de la configuración de la memoria. Comparada con las GPUs HD 620, el TDP más alto podría resultar en un rendimiento mejor sustentado.

Contrario a Skylake, Kaby Lake ahora soporta decodificación por hardware para H.265/HEVC Main 10 con una profundidad de colores de 10-bits, así como el codec VP9 de Google. Los procesadores dual-core Kaby Lake, que fueron anunciados en enero, también deben soportar HDCP 2.2.

Consumo de Energía

El chip es producido en un proceso de 14nm mejorado, con transistores FinFET, que mejoran la eficiencia aun más. El TDP es bastante alto para un procesador dual-core a 35 Watts, por tanto, la CPU no es apta para portátiles delgados y livianos (donde el i3-7100U entra en el juego).

SerieIntel Kaby Lake
Nombre códigoKaby Lake

Serie: Kaby Lake Kaby Lake

Intel Core i7-7700K4.2 - 4.5 GHz4 / 8 cores8 MB L3
Intel Core i7-77003.6 - 4.2 GHz4 / 8 cores8 MB L3
Intel Xeon E3-1535M v63.1 - 4.2 GHz4 / 8 cores8 MB L3
Intel Core i7-7920HQ3.1 - 4.1 GHz4 / 8 cores8 MB L3
Intel Core i7-7700T2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i5-7600K3.8 - 4.2 GHz4 / 4 cores8 MB L3
Intel Xeon E3-1505M v63 - 4 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HQ2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HK2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7700HQ2.8 - 3.8 GHz4 / 8 cores6 MB L3
Intel Core i5-75003.4 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i5-7440HQ2.8 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i7-7567U3.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7660U2.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7600U2.8 - 3.9 GHz2 / 4 cores4 MB L3
Intel Core i5-7300HQ2.5 - 3.5 GHz4 / 4 cores6 MB L3
Intel Core i5-7500T2.7 - 3.3 GHz4 / 4 cores6 MB L3
Intel Core i5-7287U3.3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-7560U2.4 - 3.8 GHz2 / 4 cores4 MB L3
Intel Core i5-7267U3.1 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7360U2.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-7500U2.7 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7300U2.6 - 3.5 GHz2 / 4 cores3 MB L3
Intel Core i5-7260U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i5-7200U2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i3-7100H « 3 GHz2 / 4 cores3 MB L3
Intel Core i3-7167U2.8 GHz2 / 4 cores3 MB L3
Intel Core i7-7Y751.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y571.2 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y541.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i3-7100U2.4 GHz2 / 4 cores3 MB L3
Intel Core m3-7Y321 - 3 GHz2 / 4 cores4 MB L3
Intel Pentium Gold 4415U2.3 GHz2 / 4 cores2 MB L3
Intel Core m3-7Y301 - 2.6 GHz2 / 4 cores4 MB L3
Intel Celeron 3965U2.2 GHz2 / 2 cores2 MB L3
Intel Core i3-7020U2.3 GHz2 / 4 cores3 MB L3
Intel Celeron 3867U1.8 GHz2 / 2 cores2 MB L3
Intel Celeron 3865U1.8 GHz2 / 2 cores2 MB L3
Intel Pentium Gold 4425Y1.7 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4415Y1.6 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4410Y1.5 GHz2 / 4 cores2 MB L3
Intel Celeron 3965Y1.5 GHz2 / 2 cores2 MB L3
Velocidad de reloj3000 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 33 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)35 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA1356
RecursosDual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel HD Graphics 630 (300 - 950 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$393 U.S.
Fecha de anuncio01/03/2017

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 325     de promedio: 327.5     mediana: 327.5 (2%)     max: 330 Points
31 -91%
...
Intel Core i7-6560U
311.7 -5%
311.8 -5%
313.5 -4%
AMD Ryzen Embedded R1606G
317 -3%
Intel Core i3-8121U
317.6 -3%
Intel Core i5-4200H
323.3 -1%
324 -1%
Intel Core i5-7200U
324.5 -1%
326 0%
Intel Core i3-7100H
327.5
Intel Core i5-6267U
328.3 0%
328.3 0%
333 2%
333.3 2%
335 2%
336 3%
338 3%
338.4 3%
338.5 3%
...
5600 1610%
max:
15842 4737%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
130 Points (39%)
19 -85%
...
127 -2%
AMD Ryzen Embedded V1605B
128 -2%
128.3 -1%
128.5 -1%
129 -1%
129.1 -1%
Intel Core i5-4200H
129.3 -1%
129.5 0%
129.8 0%
Intel Core i3-7100H
130
130.4 0%
130.4 0%
Intel Core i5-6267U
130.8 1%
Intel Core i7-6560U
131.7 1%
131.9 1%
132 2%
132 2%
132 2%
132.1 2%
...
311 139%
max:
332 155%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
3.6 Points (5%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
4870 puntos (29%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
11172 puntos (8%)
wPrime 2.10 - wPrime 2.0 1024m *
503 s (6%)
wPrime 2.10 - wPrime 2.0 32m *
15.9 s (3%)
WinRAR - WinRAR 4.0
2713 puntos (4%)
X264 HD Benchmark 4.0 - x264 Pass 2
21.3 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
113.6 fps (26%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (6%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (5%)
TrueCrypt - TrueCrypt AES
1.8 GB/s (5%)
3DMark 06 - CPU - 3DMark 06 - CPU
4231 Points (9%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
12.6 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
28.5 s (1%)
3DMark 11 - 3DM11 Performance Physics
4559 Points (12%)
3DMark - 3DMark Fire Strike Standard Physics
5154 Points (9%)
3DMark - 3DMark Time Spy CPU
2022 Points (9%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
