Intel Xeon E3-1505M v6

Intel E3-1505M v6

El Intel Xeon E3-1505M v6 es un veloz procesador quad-core para portátiles, basado en la arquitectura Kaby Lake y fue anunciado en enero de 2017. Es el segundo modelo Xeon móvil más veloz y el rendimiento es un poco mejor que el del Core i7-7820HQ de consumo, 100 MHz más lento. Comparado con los procesadores Core, el chip también soporta ECC-RAM (corrección de errores). Además de cuatro núcleos incluyendo el soporte para Hyper-Threading corriendo a 3 - 4 GHz (4 núcleos hasta 3,6 GHz, 2 núcleos hasta 3,8 GHz), el procesador también está equipado con la GPU HD Graphics P630 profesional así como con controlador de memoria dual-channel (DDR3L-1600/DDR4-2400). Es producido en un proceso de 14 nm con transistores FinFET.

Arquitectura

Intel básicamente utiliza la misma micro arquitectura comparada con Skylake, por ellos, el rendimiento por-MHz no se diferencia. El fabricante solo reformuló la tecnología Speed Shift para ajustes dinámicos más veloces de voltajes y frecuencias, y el mejorado proceso de 14nm permite frecuencias mucho más altas, combinado con mejor eficiencia que antes.

Rendimiento

Gracias a las velocidades más altas, incluso el modelo más pequeño de los Xeon móviles está adelante de los modelos Skylake más veloces (Xeon E3-1575M v6) y es, por tanto, suficientemente poderoso para aplicaciones muy exigentes.

Gráficos

La Intel HD Graphics P630 integrada profesional tiene 24 Unidades de Ejecución (similar a la anterior HD Graphics 530) corriendo a 350 - 1100 MHz. El rendimiento depende mucho de la configuración de la memoria; debe ser comparable con una Nvidia GeForce 920M dedicada en combinación con la memoria dual-channel DDR4-2133. Ofrece controladores certificados para aplicaciones CAD profesionales.

Contrario a Skylake, Kaby Lake ahora soporta decodificación por hardware para H.265/HEVC Main 10 con una profundidad de colores de 10-bits, así como el codec VP9 de Google. Los procesadores dual-core Kaby Lake, que fueron anunciados en enero, también deben soportar HDCP 2.2.

Consumo de Energía

El chip es producido en un proceso de 14nm mejorado, con transistores FinFET, que mejoran la eficiencia aun más. Intel aun especifica el TDP con 45 Watts, pero también puede ser reducido a 35 Watts por los fabricantes de portátiles (cTDP down). Esto, obviamente, afectará al rendimiento, porque el Turbo Boost no puede ser mantenido por periodos más largos.

SerieIntel Kaby Lake
Nombre códigoKaby Lake

Serie: Kaby Lake Kaby Lake

Intel Core i7-7700K4.2 - 4.5 GHz4 / 8 cores8 MB L3
Intel Core i7-77003.6 - 4.2 GHz4 / 8 cores8 MB L3
Intel Xeon E3-1535M v63.1 - 4.2 GHz4 / 8 cores8 MB L3
Intel Core i7-7920HQ3.1 - 4.1 GHz4 / 8 cores8 MB L3
Intel Core i7-7700T2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i5-7600K3.8 - 4.2 GHz4 / 4 cores8 MB L3
Intel Xeon E3-1505M v6 « 3 - 4 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HQ2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HK2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7700HQ2.8 - 3.8 GHz4 / 8 cores6 MB L3
Intel Core i5-75003.4 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i5-7440HQ2.8 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i7-7567U3.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7660U2.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7600U2.8 - 3.9 GHz2 / 4 cores4 MB L3
Intel Core i5-7300HQ2.5 - 3.5 GHz4 / 4 cores6 MB L3
Intel Core i5-7500T2.7 - 3.3 GHz4 / 4 cores6 MB L3
Intel Core i5-7287U3.3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-7560U2.4 - 3.8 GHz2 / 4 cores4 MB L3
Intel Core i5-7267U3.1 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7360U2.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-7500U2.7 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7300U2.6 - 3.5 GHz2 / 4 cores3 MB L3
Intel Core i5-7260U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i5-7200U2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i3-7100H3 GHz2 / 4 cores3 MB L3
Intel Core i3-7167U2.8 GHz2 / 4 cores3 MB L3
Intel Core i7-7Y751.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y571.2 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y541.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i3-7100U2.4 GHz2 / 4 cores3 MB L3
Intel Core m3-7Y321 - 3 GHz2 / 4 cores4 MB L3
Intel Pentium Gold 4415U2.3 GHz2 / 4 cores2 MB L3
Intel Core m3-7Y301 - 2.6 GHz2 / 4 cores4 MB L3
Intel Celeron 3965U2.2 GHz2 / 2 cores2 MB L3
Intel Core i3-7020U2.3 GHz2 / 4 cores3 MB L3
Intel Celeron 3867U1.8 GHz2 / 2 cores2 MB L3
Intel Celeron 3865U1.8 GHz2 / 2 cores2 MB L3
Intel Pentium Gold 4425Y1.7 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4415Y1.6 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4410Y1.5 GHz2 / 4 cores2 MB L3
Intel Celeron 3965Y1.5 GHz2 / 2 cores2 MB L3
Velocidad de reloj3000 - 4000 MHz
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)45 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
RecursosDual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, SIPP, vPro, TXT
GPUIntel HD Graphics P630 (300 - 1150 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$623 U.S.
Fecha de anuncio01/03/2017
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 654     de promedio: 728     mediana: 737 (5%)     max: 792 Points
04080120160200240280320360400440480520560600640680720760Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 170     de promedio: 170.3     mediana: 170 (51%)     max: 171 Points
19 -89%
...
166 -3%
166.5 -2%
167.5 -2%
168.6 -1%
168.7 -1%
168.8 -1%
Intel Core i5-1038NG7
169 -1%
169.4 -1%
170 0%
Intel Xeon E3-1505M v6
170.3
Intel Core i5-8400H
170.4 0%
171.6 1%
171.7 1%
Intel Core i7-8706G
172 1%
172 1%
172.5 1%
172.6 1%
172.8 1%
173.4 2%
...
311 83%
max:
332 95%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 7.89     de promedio: 8.3     mediana: 8.3 (11%)     max: 8.61 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.9 Points (48%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
23780 puntos (17%)
wPrime 2.10 - wPrime 2.0 1024m *
min: 319     de promedio: 327.2     mediana: 327.2 (4%)     max: 335.3 s
wPrime 2.10 - wPrime 2.0 32m *
min: 11     de promedio: 11     mediana: 11 (2%)     max: 11.02 s
WinRAR - WinRAR 4.0
min: 3986     de promedio: 4554     mediana: 4554 (7%)     max: 5122 puntos
X264 HD Benchmark 4.0 - x264 Pass 2
min: 48     de promedio: 48.5     mediana: 48.5 (17%)     max: 49.05 fps
X264 HD Benchmark 4.0 - x264 Pass 1
185 fps (43%)
TrueCrypt - TrueCrypt Serpent
0.5 GB/s (14%)
TrueCrypt - TrueCrypt Twofish
0.8 GB/s (13%)
TrueCrypt - TrueCrypt AES
4.4 GB/s (11%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 7230     de promedio: 7714     mediana: 7713.5 (16%)     max: 8197 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 9     de promedio: 9.5     mediana: 9.5 (2%)     max: 10 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 20     de promedio: 21.5     mediana: 21.5 (1%)     max: 23 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 489     de promedio: 509     mediana: 508.5 (2%)     max: 528 s
3DMark 11 - 3DM11 Performance Physics
min: 9594     de promedio: 9882     mediana: 9813 (27%)     max: 10239 Points
3DMark - 3DMark Ice Storm Physics
44564 Points (36%)
3DMark - 3DMark Ice Storm Extreme Physics
42023 Points (34%)
3DMark - 3DMark Ice Storm Unlimited Physics
min: 52711     de promedio: 53987     mediana: 53987 (45%)     max: 55263 Points
3DMark - 3DMark Cloud Gate Physics
min: 4304     de promedio: 6891     mediana: 8126 (21%)     max: 8243 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 6294     de promedio: 9708     mediana: 11348 (20%)     max: 11483 Points
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
14680 puntos (26%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
4042 puntos (79%)
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
15367 puntos (24%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
4224 puntos (63%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 847     de promedio: 884     mediana: 897 (1%)     max: 907 ms
Octane V2 - Octane V2 Total Score
min: 36239     de promedio: 39903     mediana: 39902.5 (36%)     max: 43566 Points
Power Consumption - Prime95 Power Consumption - external Monitor *
81.1 Watt (14%)
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
78.7 Watt (14%)
Power Consumption - Cinebench R15 Multi Power Efficiency - external Monitor
10.1 Points per Watt (8%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
