Intel Core i5-6300U
El Intel Core i5-6300U es un veloz SoC dual-core ULV (ultra low voltage) basado en la arquitectura Skylake, y fue lanzado en septiembre del 2015. La CPU puede ser encontrada en ultrabooks, así como en portátiles normales. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 2,4 - 3,0 GHz (2 núcleos: máx. 2,9 GHz), el chip también integra una GPU Graphics 520 y un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. El SoC es producido utilizando un proceso de 14 nm con transistores FinFET.
Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. Las amplias mejorías del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizados, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").
Según las velocidades especificadas y la arquitectura mejorada, el Core i5-6300U debe desempeñarse de forma similar (o un poco superior) al antiguo Core i7-5500U (Broadwell, 15 W). Así, la CPU tiene poder suficiente para tareas de oficina y multimedia, bien como las aplicaciones más exigentes y multi tareas.
La unidad gráfica integrada, llamada HD Graphics 520 representa la versión "GT2" de la GPU Skylake (Intel Gen. 9). Las 24 Unidades de Ejecución, también llamadas EUs, tienen una velocidad de 300 - 1000 MHz y ofrecen un rendimiento en algún lugar en el rango de una GeForce 820M. Por eso, juegos de 2015 pueden ser jugados con fluidez con configuraciones bajas. Para más información sobre el rendimiento y recursos, visite nuestra página de la HD Graphics 520.
Especificada con un TDP de 15 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles y ultrabooks pequeños (11-pulgadas y superiores). De forma opcional, el TDP puede ser reducido a 7,5 watts (cTDP down), reduciendo la disipación de calor y el rendimiento, y permite diseños aun más compactos.
Serie Intel Core i5 Nombre código Skylake Serie: Core i5 Skylake Velocidad de reloj 2400 - 3000 MHz Caché de Nivel 1 128 KB Caché de Nivel 2 512 KB Caché de Nivel 3 3 MB Número de Núcleos/Subprocesos 2 / 4 Consumo de Corriente (TDP = Thermal Design Power) 15 Watt Tecnología de producción 14 nm Tamaño de Matriz 99 mm2 Temperatura Máx. 100 °C Conector BGA Recursos Dual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT GPU Intel HD Graphics 520 (300 - 1000 MHz)64 Bit soporte para 64 Bit Architecture x86 Precio inicial $281 U.S. Fecha de anuncio 09/01/2015 Enlace de Producto (externo) Intel Core i5 6300U
Benchmarks Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 301 de promedio: 307 mediana: 307 (7%) max: 311 Points
...
Intel Core i5-5257U -1%
Intel Core i5-6360U 1%
Intel Core i7-6560U 2%
AMD A10-7850K 4%
Intel Core i3-8121U 4%
Intel Core i5-4200H 5%
...
AMD Ryzen Threadripper 2970WX 1325%
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 91 de promedio: 118 mediana: 122 (45%) max: 125 Points
...
Intel Core i5-5350U -2%
Intel Core i5-6400T 1%
Intel Core m3-7Y32 2%
Intel Core i5-5257U 3%
Intel Core i5-2500K 3%
Intel Core i7-4712HQ 3%
Intel Core i7-2860QM 4%
...
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.34 de promedio: 3.4 mediana: 3.4 (7%) max: 3.45 Points
...
Intel Core i5-6360U -1%
Intel Core 2 Quad (Desktop) Q9550 0%
Intel Core i5-5257U 0%
Intel Core 2 Extreme (Desktop) QX6850 0%
AMD A8-3850 1%
Intel Core i7-6560U 1%
AMD A10-7700K 1%
Intel Core i5-4200H 4%
Intel Core i5-6267U 5%
...
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.1 de promedio: 1.4 mediana: 1.4 (45%) max: 1.42 Points
...
Intel Core i5-6400T 0%
Intel Core i7-2640M 1%
Intel Core i5-5257U 3%
...
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4573 de promedio: 4682 mediana: 4678.5 (42%) max: 4805 puntos
...
AMD Ryzen 3 2200G -1%
AMD Ryzen 7 1700X 0%
AMD Ryzen 3 1300X 0%
AMD Ryzen 5 2600 1%
AMD Ryzen Threadripper 1950X 2%
Intel Core i5-2500K 2%
...
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 7812 de promedio: 10243 mediana: 10573 (18%) max: 10705 puntos
...
AMD A10-6800K -2%
Intel Core 2 Quad Q9100 -2%
AMD A10-7850K 0%
Intel Core i5-6360U 3%
Intel Core i5-5257U 3%
Intel Core i5-4200H 5%
Intel Core 2 Quad (Desktop) Q9550 6%
...
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 13274 de promedio: 13525 mediana: 13564 (13%) max: 13751 Points
...
AMD A10-7700K 0%
Intel Core i5-7200U 1%
Intel Core i5-4200H 2%
Intel Core i5-5257U 3%
AMD A10-6800K 3%
Intel Core i5-6267U 3%
...
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 6028 de promedio: 6085 mediana: 6050 (46%) max: 6250 Points
...
Intel Core i5-2500K -2%
Intel Core i7-3960X 1%
Intel Core i7-4712HQ 2%
...
wPrime 2.10 - wPrime 2.0 1024m *
min: 491.395 de promedio: 510 mediana: 512.3 (6%) max: 522.696 s
AMD Ryzen Threadripper 2970WX -92%
...
Intel Core i5-7200U -3%
Intel Core i5-4200H -2%
Intel Core i5-7360U -2%
Intel Core i5-6360U 3%
...
VIA C3-M C3-M-1200 1559%
wPrime 2.10 - wPrime 2.0 32m *
min: 15.621 de promedio: 16.1 mediana: 16.2 (3%) max: 16.499 s
Intel Core i9-9980XE -83%
...
Intel Core i5-7267U -3%
Intel Core i5-4200H -2%
AMD A10-6800K 0%
...
X264 HD Benchmark 4.0 - x264 Pass 2
min: 19.98 de promedio: 20.2 mediana: 20.2 (9%) max: 20.38 fps
Intel Pentium 4 2.4 GHz -91%
...
Intel Core i3-7130U -6%
Intel Core i5-5257U 0%
Intel Core i7-6560U 0%
Intel Core i5-4200H 1%
Intel Core i5-6360U 2%
...
X264 HD Benchmark 4.0 - x264 Pass 1
min: 107.47 de promedio: 107 mediana: 107.5 (32%) max: 107.49 fps
...
Intel Core i5-4200H -4%
Intel Core i5-6360U 2%
Intel Core i7-6560U 3%
AMD A10-7700K 3%
AMD A10-6800K 4%
Intel Core i5-7200U 6%
AMD A10-7850K 7%
...
TrueCrypt - TrueCrypt Serpent
min: 0.175 de promedio: 0.2 mediana: 0.2 (7%) max: 0.182 GB/s
...
Intel Core i5-5257U -1%
Intel Core i5-6360U 0%
Intel Core i5-7Y57 2%
AMD Phenom II X4 905e 4%
Intel Core i5-7267U 6%
...
TrueCrypt - TrueCrypt Twofish
min: 0.303 de promedio: 0.3 mediana: 0.3 (8%) max: 0.311 GB/s
...
Intel Core i5-6360U -2%
Intel Core i5-5257U -1%
AMD PRO A8-9600B 0%
Intel Core i5-4200H 1%
Intel Core i5-7Y57 1%
Intel Core i5-7200U 3%
...
TrueCrypt - TrueCrypt AES
min: 1.6 de promedio: 1.7 mediana: 1.7 (6%) max: 1.8 GB/s
...
Intel Core i7-2640M -6%
Intel Core i5-4310U -6%
Intel Core i3-7130U 0%
...
3DMark 06 - CPU - 3DMark 06 - CPU
4050 Points (22%)
...
Intel Core i7-2640M -3%
Intel Core 2 Extreme (Desktop) QX6700 -1%
AMD A8-3850 -1%
Intel Core i5-6360U 1%
Intel Core i5-5257U 3%
Intel Core 2 Quad (Desktop) Q9550 5%
...
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 12.517 de promedio: 12.9 mediana: 12.8 (3%) max: 13.434 s
...
AMD Ryzen 5 PRO 2500U -2%
AMD Ryzen 7 1800X -2%
Intel Xeon E5-2697 v2 0%
Intel Core i5-2415M 1%
Intel Core i5-6400T 1%
Intel Core i5-4310U 1%
...
VIA C3-M C3-M-1200 3489%
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 28.16 de promedio: 29.1 mediana: 29 (1%) max: 30.084 s
...
Intel Core i7-7700T -1%
Intel Core i7-940 -1%
Intel Core i5-6400T 0%
AMD Ryzen 5 PRO 2500U 1%
...
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 659.555 de promedio: 686 mediana: 665.3 (3%) max: 753.883 s
...
Intel Core i7-960 -1%
Intel Core i5-6400T -1%
Intel Xeon X5670 0%
AMD Ryzen Threadripper 2970WX 1%
Intel Core i5-4310U 1%
...
VIA C3-M C3-M-1200 3182%
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
10355 Points (12%)
...
Intel Core i7-2640M 1%
...
3DMark 11 - 3DM11 Performance Physics
min: 3915 de promedio: 4129 mediana: 4152.5 (17%) max: 4403 Points
...
Intel Core i5-4200H -2%
AMD A10-6800K -2%
Intel Core i9-9900T -1%
Intel Core i7-2640M 0%
Intel Core i5-7200U 0%
Intel Core i3-8145U 3%
...
3DMark - 3DMark Ice Storm Physics
min: 33367 de promedio: 36773 mediana: 37104 (24%) max: 39125 Points
Samsung Hummingbird S5PC110 / Exynos 3110 -99%
...
Intel Core i5-7Y57 -3%
AMD A10-7850K -2%
Intel Core i7-4712HQ 0%
Intel Core i5-7200U 3%
Intel Core i3-8145U 4%
Intel Core i7-8706G 5%
...
3DMark - 3DMark Ice Storm Extreme Physics
min: 21421 de promedio: 32172 mediana: 34941 (37%) max: 37384 Points
...
AMD Ryzen Embedded R1505G -6%
AMD Ryzen 5 PRO 2500U 5%
Intel Core i5-7Y57 6%
...
3DMark - 3DMark Ice Storm Unlimited Physics
min: 35400 de promedio: 38243 mediana: 38293 (40%) max: 41037 Points
Qualcomm Snapdragon S4 Play MSM8625Q -92%
...
AMD A10-7700K -4%
AMD A10-7850K 0%
Intel Core i5-6360U 0%
AMD Ryzen Embedded R1505G 0%
Apple A14 Bionic 2%
Intel Core i5-7Y57 3%
Apple A12X Bionic 3%
Intel Core i7-6950X 5%
...
3DMark - 3DMark Cloud Gate Physics
min: 3034 de promedio: 3323 mediana: 3342 (8%) max: 3419 Points
...
Intel Core i9-9900T -2%
AMD A10-6800K -1%
Intel Core i3-8121U -1%
Intel Core i5-6267U -1%
Intel Core i5-4200H 1%
Intel Core i7-6560U 3%
Intel Core i5-7200U 3%
...
3DMark - 3DMark Fire Strike Standard Physics
min: 4411 de promedio: 4740 mediana: 4775 (12%) max: 4870 Points
...
Intel Core i5-6360U -3%
AMD A10-6800K 0%
Intel Core i5-6267U 2%
Intel Core i5-4200H 2%
Intel Core i5-7200U 3%
...
3DMark - 3DMark Time Spy CPU
1773 Points (12%)
...
Intel Core i5-7Y57 -18%
AMD A10-7850K -4%
Intel Core i3-8145U 2%
Intel Core i5-7200U 2%
Intel Core i5-7360U 5%
Intel Core i5-6267U 10%
Intel Core i5-6287U 12%
...
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 6093 de promedio: 6220 mediana: 6184 (11%) max: 6419 puntos
Samsung Hummingbird S5PC110 / Exynos 3110 -96%
...
Intel Core i5-4200H -4%
Intel Core i3-7130U -3%
Intel Core i5-5257U 3%
Intel Core i5-7Y57 3%
...
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 2758 de promedio: 2893 mediana: 2863.5 (59%) max: 3085 puntos
Samsung Hummingbird S5PC110 / Exynos 3110 -92%
...
Intel Core i5-4200H -3%
Intel Core i3-7130U -2%
Intel Core i5-7200U 3%
...
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
6719 puntos (11%)
...
Intel Core i3-7130U -7%
Intel Core i5-7Y57 0%
Intel Core i5-7200U 1%
Intel Core i5-5257U 2%
Intel Core i5-6360U 4%
...
Geekbench 3 - Geekbench 3 64 Bit Single-Core
3231 puntos (66%)
...
Intel Core i5-6400T -3%
Apple A9X -3%
Intel Core i5-7200U -3%
Intel Pentium G4500T 1%
Intel Core i5-5257U 2%
Intel Core i7-3960X 3%
...
Intel Core i7-8700K 52%
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
min: 3532 de promedio: 3540 mediana: 3539.5 (55%) max: 3547 puntos
...
Intel Core i3-7130U -2%
AMD Ryzen 5 PRO 2500U -2%
Apple A10 Fusion -2%
HiSilicon Kirin 980 2%
AMD Ryzen 5 1400 3%
Intel Core i5-7200U 3%
...
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
min: 6614 de promedio: 6685 mediana: 6685 (16%) max: 6756 puntos
...
AMD A10-7850K -6%
Intel Core i3-7130U 1%
Intel Core i5-7200U 4%
Intel Core i5-6360U 8%
Intel Core i3-8145U 12%
Intel Core i5-6267U 13%
...
AMD Ryzen 9 3900 514%
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
3652 puntos (50%)
...
AMD Ryzen 5 PRO 2500U -4%
Intel Core i3-7130U -4%
Intel Core i3-7167U -3%
Intel Core i5-2400 0%
Intel Core i7-4722HQ 0%
AMD Ryzen 5 1400 2%
Intel Core m3-7Y32 3%
...
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
7043 puntos (11%)
...
Intel Core m3-7Y32 -4%
Intel Core i3-7130U -4%
Qualcomm Snapdragon 850 1%
AMD A10-7850K 2%
Intel Core i3-7167U 2%
Qualcomm Snapdragon 690 5G 5%
Intel Core i5-7200U 5%
...
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 1007 de promedio: 1303 mediana: 1178 (2%) max: 2226.1 ms
...
Intel Core i3-8145U -2%
Intel Core m5-6Y57 0%
Intel Core i5-7500 3%
Intel Core i5-6267U 3%
Intel Core i7-2860QM 3%
...
Qualcomm Snapdragon S1 MSM7227A 4464%
Sunspider - Sunspider 1.0 Total Score *
min: 85.9 de promedio: 134 mediana: 104.5 (1%) max: 213 ms
...
Intel Core i5-7200U -7%
Intel Core M-5Y51 -4%
Intel Core i3-5015U -1%
AMD Ryzen 5 PRO 2500U 3%
...
Octane V2 - Octane V2 Total Score
min: 15750 de promedio: 28031 mediana: 29991 (48%) max: 30812 Points
...
Intel Core i7-8706G 2%
Intel Core i3-8145U 3%
Qualcomm Snapdragon 8cx 5%
Intel Core i5-7200U 7%
...
Apple M1 122%
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
v1.16
log 21. 20:16:03
#0 no ids found in url (should be separated by "_") +0s ... 0s
#1 not redirecting to Ajax server +0s ... 0s
#2 did not recreate cache, as it is less than 5 days old! Created at Thu, 21 Jan 2021 11:08:23 +0100 +0.001s ... 0.001s
#3 no comparison url found in template nbc.compare_page_2 needed +0.006s ... 0.007s
#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#10 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#11 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s
#12 composed specs +0s ... 0.007s
#13 did output specs +0s ... 0.007s
#14 getting avg benchmarks for device 6967 +0.001s ... 0.008s
#15 got single benchmarks 6967 +0.023s ... 0.031s
#16 got avg benchmarks for devices +0s ... 0.031s
#17 min, max, avg, median took s +0.41s ... 0.441s
#18 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.441s
#19 return log +0s ... 0.441s
Análisis para el Intel Core i5 6300U procesador
Alienware 15 R3-0012SLV (NVIDIA GeForce GTX 1060 Mobile, 15.60")
» Alienware 15 R3-0012SLV - análise externo
Dell Latitude 12 E5270 (Intel HD Graphics 520, 12.50")
» Breve análisis del portátil Dell Latitude 12 E5270 - análise » Dell Latitude 12 E5270 - análise externo
Dell Latitude 12 E7270 (Intel HD Graphics 520, 12.50")
» Breve análisis del Dell Latitude 12 E7270 - análise » Dell Latitude 12 E7270 - análise externo
Dell Latitude 14 7414 Rugged Extreme (Intel HD Graphics 520, 14.00")
» Breve análisis del Dell Latitude 14 7414 Rugged Extreme (6200U, HD) - análise
Dell Latitude 14 7414-9R2J5 (Intel HD Graphics 520, 14.00")
» Dell Latitude 14 7414-9R2J5 - análise externo
Dell Latitude 14 E5470 (Intel HD Graphics 520, 14.00")
» Breve análisis del Dell Latitude 14 E5470 - análise
Dell Latitude 14 Rugged 5414 (AMD Radeon R7 M360, 14.00")
» Breve análisis del Dell Latitude 14 Rugged 5414 - análise
Dell Latitude 15 E5570 (Intel HD Graphics 520, 15.60")
» Breve análisis del Dell Latitude 15 E5570 - análise » Dell Latitude 15 E5570 - análise externo
Dell Latitude E7470 N001LE747014EMEA (Intel HD Graphics 520, 14.00")
» Dell Latitude E7470 N001LE747014EMEA - análise externo
Fujitsu Stylistic R726-R7260M85BBDE (Intel HD Graphics 520, 12.50")
» Fujitsu Stylistic R726-R7260M85BBDE - análise externo
HP EliteBook 820 G3 (Intel HD Graphics 520, 12.50")
» Breve análisis del subportátil HP EliteBook 820 G3 - análise
HP EliteBook 840 G3-X2F52EA (Intel HD Graphics 520, 14.00")
» HP EliteBook 840 G3-X2F52EA - análise externo
HP EliteBook Folio 1040 G3 (Intel HD Graphics 520, 14.00")
» Breve análisis del HP EliteBook Folio 1040 G3 - análise » HP EliteBook Folio 1040 G3 - análise externo
Lenovo ThinkPad 13 Chromebook (Intel HD Graphics 520, 13.30")
» Breve análisis del Lenovo ThinkPad 13 Chromebook - análise » Lenovo ThinkPad 13 Chromebook - análise externo
Lenovo ThinkPad X1 Carbon 20FB-005XUS (Intel HD Graphics 520, 14.00")
» Breve análisis del Lenovo ThinkPad X1 Carbon 20FB-005XUS - análise » Lenovo ThinkPad X1 Carbon 20FB-005XUS - análise externo
Microsoft Surface Book Core i5 (NVIDIA Maxwell GPU (940M, GDDR5), 13.50")
» Breve análisis del Microsoft Surface Book (Core i5, Nvidia) - análise » Microsoft Surface Book, Core i5 - análise externo
Microsoft Surface Book, Core i5-6300U (NVIDIA GeForce 940M, 13.50")
» Microsoft Surface Book, Core i5-6300U - análise externo
Microsoft Surface Pro 4, Core i5, 128GB (Intel HD Graphics 520, 12.30")
» Microsoft Surface Pro 4, Core i5 - análise externo
Microsoft Surface Pro 4, Core i5, 256GB (Intel HD Graphics 520, 12.30")
» Microsoft Surface Pro 4, Core i5, 256GB - análise externo
Toshiba Portege Z30-C1310 (Intel HD Graphics 520, 13.30")
» Toshiba Portege Z30-C1310 - análise externo
Otras CPUs de la serie Core i5 » Intel Core i5-8305G 4x 2.8 GHz - 3.8 GHz
» Intel Core i5-8265U 4x 1.6 GHz - 3.9 GHz
» Intel Core i5-6287U 2x 3.1 GHz - 3.5 GHz
» Intel Core i5-5287U 2x 2.9 GHz - 3.3 GHz
» Intel Core i5-6267U 2x 2.9 GHz - 3.3 GHz
» Intel Core i5-4200H 2x 2.8 GHz - 3.4 GHz
» Intel Core i5-5257U 2x 2.7 GHz - 3.1 GHz
» Intel Core i5-4308U 2x 2.8 GHz - 3.3 GHz
» Intel Core i5-6360U 2x 2 GHz - 3.1 GHz
» Intel Core i5-5350U 2x 1.8 GHz - 2.9 GHz
» Intel Core i5-4310U 2x 2 GHz - 3 GHz
» Intel Core i5-4360U 2x 1.5 GHz - 3 GHz
» Intel Core i5-2415M 2x 2.3 GHz - 2.9 GHz
» Intel Core i5-4220Y 2x 1.6 GHz - 2 GHz
CPUs de alrededor + Intel Core i5-6360U 2x 2 GHz - 3.1 GHz
Please share our article, every link counts!
Klaus Hinum (Update: 2015-12-17)
