Intel Core i7-6567U

Intel 6567U

El Intel Core i7-6567U es un SoC dual-core basado en la arquitectura Skylake. En Septiembre de 2015, es la CPU más veloz de la serie de 28 W que puede ser encontrada en ultrabooks y portátiles de tamaño mediano. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 3,3 - 3,6 GHz (2 núcleos: máx. 3,4 GHz), el chip también integra una GPU Iris Graphics 550 con 64 MB de memoria eDRAM así como un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. El SoC es producido utilizando un proceso de 14 nm con transistores FinFET.

Arquitectura

Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. Las amplias mejorías del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizados, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").

Además, la organización del cache eDRAM ha sido modificada. En vez de actuar como un cache víctima, que debe ser abordada mediante la L3/LLC, la eDRAM ahora puede ser abordada directamente por programas justo como las memoria principal. El tamaño aun es de 128 MB para los modelos quad-core (4C + GT4e), mientras que los chips dual-core (2C + GT3e) solo ofrecen 64 MB.

Rendimiento

Según las velocidades especificadas y la arquitectura mejorada, el Core i7-6567U debe desempeñarse un poco más arriba del anterior Core i5-5350H (Broadwell) y es uno de los dual-cores más veloces de finales del 2015.

Incluso aplicaciones exigentes y multi-tareas, son manejadas con facilidad.

Gráficos

La unidad gráfica integrada, llamada Iris Graphics 550 representa la versión "GT3e" de la GPU Skylake (Intel Gen. 9). Las 48 Unidades de Ejecución Execution, también llamadas EUs, tienen una velocidad de 350 - 1100 MHz y ofrece (gracias al veloz cache eDRAM) un rendimiento similar al de una GeForce 930M dedicada. Por eso, juegos de 2015 pueden ser jugados con fluidez con configuraciones bajas o medianas. Para más información sobre el rendimiento y recursos, visite nuestra página de la Iris Graphics 550.

Consumo de Energía

Especificada con un TDP de 28 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles medianos (13-pulgadas y superiores). De forma opcional, el TDP puede ser reducido a 23 watts (cTDP down), reduciendo la disipación de calor y el rendimiento.

SerieIntel Core i7
Nombre códigoSkylake

Serie: Core i7 Skylake

Intel Core i7-6920HQ2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-6970HQ2.8 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-6870HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HK2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6770HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6700HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6567U « 3.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-6600U2.6 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6650U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6560U2.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-6500U2.5 - 3.1 GHz2 / 4 cores4 MB L3
Velocidad de reloj3300 - 3600 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)28 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel Iris Graphics 550 (300 - 1100 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio09/01/2015
Enlace de Producto (externo)ark.intel.com

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
25.6 pt (36%)
2.47 -90%
...
24.4 -5%
Intel Core i7-2860QM
24.6 -4%
24.6 -4%
24.6 -4%
25 -2%
Intel Core i3-8109U
25.1 -2%
25.1 -2%
AMD Ryzen Embedded V1605B
25.3 -1%
Intel Core i5-6287U
25.4 -1%
Intel Core i7-6567U
25.6
25.9 1%
26 2%
26.1 2%
26.2 2%
26.2 2%
26.2 2%
26.3 3%
26.5 4%
26.5 4%
...
57 123%
max:
72.1 182%
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
367 Points (41%)
Cinebench R20 - Cinebench R20 CPU (Multi Core)
883 Points (2%)
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 355     de promedio: 359.5     mediana: 359.5 (2%)     max: 364 Points
31 -91%
...
343.3 -5%
Intel Core i5-6287U
345 -4%
Intel Core i3-8145U
345.5 -4%
351.8 -2%
352 -2%
Intel Core i3-8109U
352.5 -2%
352.7 -2%
353 -2%
Intel Core i5-7360U
354 -2%
Intel Core i7-6567U
359.5
368 2%
Intel Core i5-7260U
373 4%
382 6%
Intel Core i5-7267U
383 7%
390.8 9%
400 11%
403.5 12%
416 16%
422.5 18%
...
5600 1458%
max:
15842 4307%
0%
100%
020406080100120140160180200220240260280300320340Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 142     de promedio: 143.6     mediana: 143.6 (43%)     max: 145.2 Points
19 -87%
...
141.9 -1%
Intel Core i5-7260U
142 -1%
142 -1%
142.2 -1%
142.4 -1%
Intel Core i5-7360U
142.5 -1%
142.8 -1%
142.9 0%
Intel Core i5-6287U
143 0%
Intel Core i7-6567U
143.6
143.6 0%
143.9 0%
145 1%
146.8 2%
147.1 2%
Intel Core i3-8145U
147.5 3%
147.6 3%
149 4%
149.5 4%
...
311 117%
max:
332 131%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.8     de promedio: 3.9     mediana: 3.9 (5%)     max: 4.02 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.63     de promedio: 1.7     mediana: 1.7 (41%)     max: 1.7 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5506     de promedio: 5549     mediana: 5549 (34%)     max: 5592 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 12259     de promedio: 12367     mediana: 12367 (9%)     max: 12475 puntos
wPrime 2.10 - wPrime 2.0 1024m *
min: 419.4     de promedio: 435.5     mediana: 435.5 (5%)     max: 451.6 s
wPrime 2.10 - wPrime 2.0 32m *
min: 13.33     de promedio: 13.9     mediana: 13.9 (3%)     max: 14.4 s
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
9819 MIPS (6%)
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
3733 MIPS (45%)
X264 HD Benchmark 4.0 - x264 Pass 2
24.1 fps (8%)
X264 HD Benchmark 4.0 - x264 Pass 1
128.8 fps (30%)
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
3.2 fps (6%)
0123456Tooltip
TrueCrypt - TrueCrypt Twofish
0.4 GB/s (6%)
Blender - Blender 3.3 Classroom CPU *
2451 Seconds (31%)
Blender - Blender 2.79 BMW27 CPU *
1244 Seconds (9%)
3DMark 06 - CPU - 3DMark 06 - CPU
4800 Points (10%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
11 s (2%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
585 s (3%)
3DMark 11 - 3DM11 Performance Physics
5251 Points (14%)
3DMark - 3DMark Ice Storm Physics
47495 Points (39%)
3DMark - 3DMark Ice Storm Extreme Physics
47567 Points (39%)
3DMark - 3DMark Ice Storm Unlimited Physics
min: 46247     de promedio: 48811     mediana: 48810.5 (41%)     max: 51374 Points
3DMark - 3DMark Cloud Gate Physics
min: 3985     de promedio: 3993     mediana: 3993 (10%)     max: 4001 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 5773     de promedio: 5792     mediana: 5791.5 (10%)     max: 5810 Points
3DMark - 3DMark Time Spy CPU
2078 Points (9%)
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core
970 puntos (41%)
125 -87%
...
914 -6%
917 -5%
Intel Core i5-7260U
920 -5%
928 -4%
932 -4%
940 -3%
948 -2%
953 -2%
961 -1%
Intel Core i7-6567U
970
986 2%
987 2%
990 2%
992 2%
Intel Core i3-10110Y
996 3%
Intel Core i7-7700HQ
1004 4%
Intel Core i7-10510Y
1005 4%
1033 6%
Intel Core i5-8265U
1039 7%
...
2331 140%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
2117 puntos (4%)
238.5 -89%
...
Qualcomm Snapdragon 850
1923 -9%
1928 -9%
1934 -9%
Intel Core i5-6287U
1989 -6%
2010 -5%
2026 -4%
2028 -4%
Intel Core i5-7260U
2064 -3%
2080 -2%
Intel Core i7-6567U
2117
AMD Ryzen 3 PRO 2300U
2156 2%
2159 2%
Intel Core i5-7287U
2193 4%
2245 6%
2322 10%
2332 10%
2360 11%
2420 14%
AMD Ryzen 3 3350U
2455 16%
...
22938 984%
max:
55811 2536%
0%
100%
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
4051 puntos (40%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
8271 puntos (9%)
CrossMark - CrossMark Overall
723 Points (28%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
