Intel Core i7-7560U

Intel i7-7560U

El Intel Core i7-7560U es un veloz SoC dual-core para portátiles y Ultrabooks, basado en la arquitectura Kaby Lake y fue anunciado en enero de 2017. La CPU tiene dos núcleos de procesador con velocidades de 2,4-3,8 GHz (dos núcleos hasta 3,7 GHz). El procesador puede ejecutar hasta cuatro threads simultáneamente gracias al Hyper Threading. también estpa equipado con una GPU Intel Iris Plus Graphics 640 con 64 MB de eDRAM, un controlador de memoria dual-channel (DDR4), y de- codificador de vídeos VP9 y H.265. El chip aun es producido en un proceso de 14 nm con transistores FinFET.

Comparado con el Core i7-7500U, el 7560 tiene un Turbo single-core más alto de 3,8 GHz (+300 MHz) e un Turbo dual-core más alto (+200 MHz). La frecuencia base es más baja (-300 MHz), pero la parte de la CPU también puede utilizar los 64 MB de eDRAM como cache L5.

Arquitectura

Intel básicamente utiliza la misma micro arquitectura comparada con Skylake, por ellos, el rendimiento por-MHz no se diferencia. El fabricante solo reformuló la tecnología Speed Shift para ajustes dinámicos más veloces de voltajes y frecuencias, y el mejorado proceso de 14nm permite frecuencias mucho más altas, combinado con mejor eficiencia que antes.

Rendimiento

A 2,4-3,8 GHz, el Core i7-7560U tiene una frecuencia un poco inferior (excepto por el Turbo single-core) en comparación con el Core i7-7600U, pero la parte de la CPU también puede utilizar los 64 MB de eDRAM, por tanto, el rendimiento debe ser similar.

Gráficos

La Intel Iris Plus 640 Graphics integrada es el modelo GT3e de la GPU Kaby Lake (Intel Gen. 9,5). Posee 48 Unidades de Ejecución corriendo a 300-1050 MHz y el rendimiento es comparable al de una GeForce 920MX gracias al veloz cache eDRAM. Sin embargo, no existen mejorías significantes, en comparación con la antigua Iris Pro 540, por tanto, los juegos modernos, a menudo, no podrán ser jugados fluidamente o solo con las configuraciones más bajas o medianas, respectivamente.

Contrario a Skylake, Kaby Lake también soporta H.265/HEVC Main 10 con una profundidad de colores de 10-bits, así como el codec VP9 de Google. Los procesadores dual-core Kaby Lake, anunciados en enero, también deben soportar HDCP 2.2.

Consumo de Energía

El chip es producido en un proceso de 14nm mejorado, con transistores FinFET, que mejoran la eficiencia aun más. Intel aun especifica el TDP con 15 Watts, lo cual es típico para chips ULV. Dependiendo del escenario de uso, el TDP puede variar entre 7,5 (cTDP Down) y 25 Watts.

SerieIntel Kaby Lake
Nombre códigoKaby Lake

Serie: Kaby Lake Kaby Lake

Intel Core i7-7700K4.2 - 4.5 GHz4 / 8 cores8 MB L3
Intel Core i7-77003.6 - 4.2 GHz4 / 8 cores8 MB L3
Intel Xeon E3-1535M v63.1 - 4.2 GHz4 / 8 cores8 MB L3
Intel Core i7-7920HQ3.1 - 4.1 GHz4 / 8 cores8 MB L3
Intel Core i7-7700T2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i5-7600K3.8 - 4.2 GHz4 / 4 cores8 MB L3
Intel Xeon E3-1505M v63 - 4 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HQ2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7820HK2.9 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-7700HQ2.8 - 3.8 GHz4 / 8 cores6 MB L3
Intel Core i5-75003.4 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i5-7440HQ2.8 - 3.8 GHz4 / 4 cores6 MB L3
Intel Core i7-7567U3.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7660U2.5 - 4 GHz2 / 4 cores4 MB L3
Intel Core i7-7600U2.8 - 3.9 GHz2 / 4 cores4 MB L3
Intel Core i5-7300HQ2.5 - 3.5 GHz4 / 4 cores6 MB L3
Intel Core i5-7500T2.7 - 3.3 GHz4 / 4 cores6 MB L3
Intel Core i5-7287U3.3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-7560U « 2.4 - 3.8 GHz2 / 4 cores4 MB L3
Intel Core i5-7267U3.1 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7360U2.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-7500U2.7 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-7300U2.6 - 3.5 GHz2 / 4 cores3 MB L3
Intel Core i5-7260U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i5-7200U2.5 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i3-7100H3 GHz2 / 4 cores3 MB L3
Intel Core i3-7167U2.8 GHz2 / 4 cores3 MB L3
Intel Core i7-7Y751.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y571.2 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i5-7Y541.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i3-7100U2.4 GHz2 / 4 cores3 MB L3
Intel Core m3-7Y321 - 3 GHz2 / 4 cores4 MB L3
Intel Pentium Gold 4415U2.3 GHz2 / 4 cores2 MB L3
Intel Core m3-7Y301 - 2.6 GHz2 / 4 cores4 MB L3
Intel Celeron 3965U2.2 GHz2 / 2 cores2 MB L3
Intel Core i3-7020U2.3 GHz2 / 4 cores3 MB L3
Intel Celeron 3867U1.8 GHz2 / 2 cores2 MB L3
Intel Celeron 3865U1.8 GHz2 / 2 cores2 MB L3
Intel Pentium Gold 4425Y1.7 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4415Y1.6 GHz2 / 4 cores2 MB L3
Intel Pentium Gold 4410Y1.5 GHz2 / 4 cores2 MB L3
Intel Celeron 3965Y1.5 GHz2 / 2 cores2 MB L3
Velocidad de reloj2400 - 3800 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)15 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA1356
RecursosDual-Channel DDR4 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel Iris Plus Graphics 640 (300 - 1050 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$415 U.S.
Fecha de anuncio01/03/2017

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
336 Points (2%)
31 -91%
...
324 -4%
Intel Core i5-7200U
324.5 -3%
326 -3%
327.5 -3%
328.3 -2%
Intel Core i5-6267U
328.3 -2%
333 -1%
333.3 -1%
335 0%
Intel Core i7-7560U
336
338 1%
338.4 1%
338.5 1%
342 2%
343 2%
343.3 2%
Intel Core i5-6287U
345 3%
Intel Core i3-8145U
345.5 3%
351.8 5%
...
5600 1567%
max:
15842 4615%
0%
100%
020406080100120140160180200220240260280300320Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
153 Points (46%)
19 -88%
...
147.1 -4%
Intel Core i3-8145U
147.5 -4%
147.6 -4%
149 -3%
149.5 -2%
150 -2%
152 -1%
152 -1%
152.9 0%
Intel Core i7-7560U
153
153.5 0%
153.9 1%
Intel Core i5-8265U
155 1%
155.2 1%
Intel Core i7-7700HQ
155.4 2%
155.8 2%
Intel Core i5-8260U
156.9 3%
Intel Core i5-8305G
157 3%
157 3%
...
311 103%
max:
332 117%
0%
100%
3DMark 11 - 3DM11 Performance Physics
4693 Points (13%)
3DMark - 3DMark Ice Storm Unlimited Physics
51358 Points (43%)
3DMark - 3DMark Cloud Gate Physics
3651 Points (9%)
3DMark - 3DMark Fire Strike Standard Physics
5649 Points (10%)
3DMark - 3DMark Time Spy CPU
1857 Points (8%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
997 ms (1%)
Octane V2 - Octane V2 Total Score
36944 Points (33%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
