Intel Core i7-6970HQ

Intel 6970HQ

El Intel Core i7-6970HQ es un veloz procesador quad-core para portátiles basados en la arquitectura Skylake y fue introducido a principios de 2016. Además de cuatro núcleos de CPU incluyendo Hyperthreading, que tienen una velocidad entre 2,8-3,7 GHz (probables pasos Turbo: 4 núcleos: hasta 3,3 GHz, 2 núcleos: hasta 3,5 GHz), el procesador también incluye una unidad gráfica muy veloz. La Iris Pro Graphics 580 (GT4e) tiene 72 EUs así como 128 MB de cache eDRAM, que también pueden ser utilizados por los núcleos da la CPU. Es producido utilizando un proceso de 14 nm con transistores FinFET.

Contrario a los otros modelos como el Core i7-6920HQ, el i7-6970HQ tiene una GPU mucho más veloz, pero ninguno soporta las extensiones del conjunto de instrucciones TSX-NI ni vPro.

Arquitectura

Intel utiliza Skylake para sustituir tanto Broadwell como Haswell y, por tanto el diseño de un núcleo para todas las clases de TDP entre 4,5-45 Watts. Diversas mejoras de la arquitectura Skylake incluyen un Out-to-Order-Buffer más grande, optimizaciones para el pre-fetching, así como ganancias más grandes por el Hyperthreading. Sin embargo, los cambios son pequeños para un "Tock" – una nueva micro arquitectura – en general, así el rendimiento por-MHz solo está entre 5-10 % (en comparación con Haswell) o menos de 5 % superior (en comparación con Broadwell), respectivamente.

El i7-6970HQ también se beneficia del cache de eDRAM adicional en algunos casos, que pueden acelerar aplicaciones pesadas para la memoria en particular.

Rendimiento

Gracias al cache de eDRAM adicional, el i7-6970HQ incluso podría competir con el i7-6920HQ de más velocidad y es, por tanto, uno de los procesadores de portátil más veloz de principio de 2016. Incluso las aplicaciones más exigentes y multi-tareas excesivas no son problema para la CPU de gama alta.

Gráficos

La GPU integrada con la designación Iris Pro Graphics 580 (también conocida como "GT4e") representa la versión más veloz de la GPU Skylake (Intel Gen. 9). 72 Unidades de Ejecución (EUs) funcionan a 350 hasta 1050 MHz y permiten un rendimiento comparable al de un chip convencional dedicado. La GPU podría ser capaz de competir con una GeForce 945M bajo condiciones perfectas y por tanto es la iGPU más veloz en el mercado por un margen muy grande. Los juegos modernos de 2015/2016 normalmente pueden ser jugados fluidamente con configuraciones medianas. Más información sobre el rendimiento y los recursos están disponibles en nuestra página dedicada para la Iris Pro Graphics 580.

Consumo de Energía

De acuerdo con su TDP de 45 Watts, el chip está diseñado para portátiles más grades, comenzando con pantallas de 15-pulgadas. El TDP opcionalmente puede ser reducido a 35 Watts (cTDP down), pero obviamente esto afectará al rendimiento.

SerieIntel Core i7
Nombre códigoSkylake

Serie: Core i7 Skylake

Intel Core i7-6920HQ2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-6970HQ « 2.8 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-6870HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HK2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6770HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6700HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6567U3.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-6600U2.6 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6650U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6560U2.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-6500U2.5 - 3.1 GHz2 / 4 cores4 MB L3
Velocidad de reloj2800 - 3700 MHz
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)45 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, AVX, AVX2, Quick Sync, Virtualization, AES-NI, TXT
GPUIntel Iris Pro Graphics 580 (350 - 1050 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$623 U.S.
Fecha de anuncio01/24/2016
Enlace de Producto (externo)ark.intel.com

Benchmarks

- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance

v1.26
log 16. 15:41:30

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Sat, 16 Mar 2024 05:37:00 +0100 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_2 needed +0.007s ... 0.008s

#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#10 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.011s

#11 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.011s

#12 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.011s

#13 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.011s

#14 composed specs +0s ... 0.012s

#15 did output specs +0s ... 0.012s

#16 getting avg benchmarks for device 8017 +0.003s ... 0.015s

#17 got single benchmarks 8017 +0s ... 0.015s

#18 got avg benchmarks for devices +0s ... 0.015s

#19 min, max, avg, median took s +0s ... 0.015s

#20 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.015s

#21 return log +0s ... 0.015s

No se encontraron análisis para esta CPU (aún)
