Intel Core i7-920XM

Intel 920XM

El Intel Core i7 920XM Extreme Edition es actualmente (2009) el procesador para portatiles más rapido. Presenta 4 nucleos (CPU quad core) y Hypertrheading. Por tanto, pueden funcionar 8 hilos de forma simultanea.

Debido al Modo Turbo la CPU tiene una velocidad de reloj de hasta 3.2 GHz y por tanto rápida para aplicaciones de un solo nucleo.

La linea Core i7 9xx tiene un controlador de memoria integrado para modulos DDR3 (1066o 1333). Por tanto, el rendimiento de memoria es muy bueno (comparado con CPUs más viejas con controladores de memoria externos). Esto lleva a mayores TDP en ele chip completo.

La arqutectura del nucleo es bastante similar a la usada en las CPUs Core 2.

El consumo de corriente de hasta 55 vatios (TDP) es muy alto para una CPU portatil y debido al Modo Turbo, el consumo de corriente debería llegar a valores altos.

Con un precio inicial de 1054$ (al comprar 1000 CPUs a Intel) el precio es bastante elevado.

SerieIntel Core i7
Nombre códigoClarksfield

Serie: Core i7 Clarksfield

Intel Core i7-940XM2.13 - 3.33 GHz4 / 8 cores8 MB L3
Intel Core i7-920XM « 2 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-840QM1.86 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-820QM1.73 - 3.06 GHz4 / 8 cores8 MB L3
Intel Core i7-740QM1.73 - 2.93 GHz4 / 8 cores6 MB L3
Intel Core i7-720QM1.6 - 2.8 GHz4 / 8 cores6 MB L3
Velocidad de reloj2000 - 3200 MHz
Bus Frontal2500
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)55 Watt
Conteo de Transistores774 Millón
Tecnología de producción45 nm
Tamaño de Matriz296 mm2
Temperatura Máx.100 °C
ConectorRPGA989
Recursos2.5 GT/s DMI, Virtualization Technology, Execute Disable Bit, Enahnced Speedstep Technology, Enhanced Halt State (C1E), 64, Turbo Boost, Hyper-Threading, Trusted Execution Technology
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$1054 U.S.
Fecha de anuncio09/23/2009
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.41     de promedio: 3.7     mediana: 3.9 (5%)     max: 3.9 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4310     de promedio: 4322     mediana: 4322 (26%)     max: 4334 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 11792     de promedio: 11916     mediana: 11916 (9%)     max: 12040 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 11420     de promedio: 12682     mediana: 13235 (9%)     max: 13390 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 2633     de promedio: 3717     mediana: 4197 (5%)     max: 4320 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 312     de promedio: 727     mediana: 600 (7%)     max: 1269 s
wPrime 2.10 - wPrime 2.0 32m *
min: 9.7     de promedio: 22.8     mediana: 19 (4%)     max: 39.78 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3591     de promedio: 3816     mediana: 3797 (8%)     max: 4078 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
13 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
31 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
719 s (3%)
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
48000 MIPS (23%)
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
43210 MFLOPS (33%)
Windows 7 Experience Index - Win7 CPU
min: 7.2     de promedio: 7.3     mediana: 7.3 (94%)     max: 7.3 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 11552     de promedio: 13318     mediana: 14150 (13%)     max: 14253 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance

v1.26
log 15. 11:36:18

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Wed, 13 Mar 2024 05:38:53 +0100 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_2 needed +0.007s ... 0.008s

#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#8 composed specs +0s ... 0.009s

#9 did output specs +0s ... 0.009s

#10 getting avg benchmarks for device 517 +0.003s ... 0.012s

#11 got single benchmarks 517 +0.023s ... 0.035s

#12 got avg benchmarks for devices +0s ... 0.035s

#13 min, max, avg, median took s +0.322s ... 0.357s

#14 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.357s

#15 return log +0s ... 0.357s

Análisis para el Intel Core i7-920XM procesador

HP EliteBook 8740w-VG316AV: NVIDIA Quadro 5000M, 17.00", 3.6 kg
  análise externo » HP EliteBook 8740w-VG316AV

Lenovo ThinkPad W701ds: NVIDIA Quadro FX 3800M, 17.00", 4.1 kg
  análise externo » Lenovo ThinkPad W701ds

Asus G73J: ATI Mobility Radeon HD 5870, 17.30", 3.6 kg
  análise externo » Asus G73J
