Intel Core i7-3520M

Intel 3520M

El Intel Core i7-3520M es el más veloz procesador dual-core para portátiles, basado en la arquitectura Ivy Bridge en el momento de la introducción en el segundo trimestre de 2012. Gracias al Hyperthreading, los dos núcleos pueden soportar hasta cuatro threads en paralelo haciendo un mejor uso del CPU. Cada núcleo ofrece una velocidad base de 2,9 GHz, pero puede aumentar la frecuencia dinámicamente con Turbo Boost, hasta 3,4 GHz (para 2 núcleos activos), y 3,6 GHz (para 1 núcleo activo). Como su predecesor, el Core i7-2640M basado en Sandy-Bridge, él ofrece un cache de 4 MB L3.

Ivy Bridge es una matriz mejorada y encogida de la arquitectura Sandy Bridge con mejoras en el rendimiento del GPU y CPU. Los CPUs son producidos en 22nm (contra 32nm de los CPUs Sandy Bridge) y son los primeros en introducir transistores 3D para una mejor eficiencia energética al compararlo con procesadores Sandy Bridge con frecuencias similares. Otros nuevos recursos son el PCI Express 3.0 integrado y soporte para DDR3(L)-1600.

El rendimiento del Core i7-3520M debe ser ligeramente superior que el de un procesador Sandy Bridge con frecuencia similar gracias a pequeñas alteraciones estructurales. Como resultado, el rendimiento general está cerca de 5 - 10 % por encima del antiguo i7-2640M (vea los benchmarks abajo).

La Intel HD Graphics 4000 integrada ofrece 16 Unidades de Ejecución (EUs) a una frecuencia de 350 MHz hasta 1050 MHz con Turbo Boost, ofreciendo un rendimiento comparable con el de una AMD Radeon HD 6620G.

Tal como la mayoría de los otros dual-cores Ivy Bridge, el i7-3520M está clasificado en un TDP de 35 W. Por tanto, hasta los portátiles más pequeños pueden utilizar el Core i7.

SerieIntel Core i7
Nombre códigoIvy Bridge

Serie: Core i7 Ivy Bridge

Intel Core i7-3940XM3 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-3920XM2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 8 cores6 MB L3
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 8 cores6 MB L3
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 8 cores6 MB L3
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-3540M3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-3520M « 2.9 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-3687U2.1 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i7-3667U2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-3537U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i7-3517U1.9 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 4 cores4 MB L3
Velocidad de reloj2900 - 3600 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)35 Watt
Tecnología de producción22 nm
Temperatura Máx.105 °C
ConectorBGA1023, PGA988
RecursosHD Graphics 4000, DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1250 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$346 U.S.
Fecha de anuncio06/03/2012
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3     de promedio: 3.3     mediana: 3.4 (4%)     max: 3.44 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.41     de promedio: 1.4     mediana: 1.5 (36%)     max: 1.47 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4408     de promedio: 4813     mediana: 4855 (29%)     max: 4903 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 9112     de promedio: 10167     mediana: 10467 (8%)     max: 10605 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 11581     de promedio: 12766     mediana: 12889.5 (9%)     max: 13151 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 6029     de promedio: 6128     mediana: 6146.5 (7%)     max: 6203 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 456     de promedio: 493.2     mediana: 492.1 (6%)     max: 570 s
wPrime 2.10 - wPrime 2.0 32m *
min: 14.4     de promedio: 15.5     mediana: 15.4 (3%)     max: 17.1 s
WinRAR - WinRAR 4.0
min: 2661     de promedio: 2863     mediana: 2715 (4%)     max: 3527 puntos
X264 HD Benchmark 4.0 - x264 Pass 2
min: 6.7     de promedio: 16.1     mediana: 18.9 (7%)     max: 19.44 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 35.1     de promedio: 86.2     mediana: 98.6 (23%)     max: 101.8 fps
TrueCrypt - TrueCrypt Serpent
min: 0.164     de promedio: 0.2     mediana: 0.2 (5%)     max: 0.176 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.249     de promedio: 0.3     mediana: 0.3 (5%)     max: 0.302 GB/s
TrueCrypt - TrueCrypt AES
min: 1.2     de promedio: 1.6     mediana: 1.7 (4%)     max: 1.7 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3528     de promedio: 4086     mediana: 4134 (9%)     max: 4212 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 10     de promedio: 10.3     mediana: 10 (2%)     max: 10.94 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 24     de promedio: 24.8     mediana: 25 (1%)     max: 25.87 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 565     de promedio: 591     mediana: 594 (3%)     max: 612 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 55800     de promedio: 63808     mediana: 67130 (32%)     max: 69140 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 41450     de promedio: 42502     mediana: 42450 (33%)     max: 44032 MFLOPS
Windows 7 Experience Index - Win7 CPU
7.2 Points (92%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 9277     de promedio: 11188     mediana: 11511 (10%)     max: 11788 Points
3DMark 11 - 3DM11 Performance Physics
min: 3582     de promedio: 4275     mediana: 4466 (12%)     max: 4774 Points
3DMark - 3DMark Ice Storm Physics
39221 Points (32%)
3DMark - 3DMark Cloud Gate Physics
3393 Points (9%)
3DMark - 3DMark Fire Strike Standard Physics
4772 Points (9%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
