Intel Core i7-3540M

Intel 3540M

El Intel Core i7-3540M es el más veloz procesador dual-core para portátiles, basado en la arquitectura Ivy Bridge en el momento de la introducción en el primer trimestre de 2013. Gracias al Hyperthreading, los dos núcleos pueden soportar hasta cuatro threads en paralelo haciendo un mejor uso del CPU. Cada núcleo ofrece una velocidad base de 3,0 GHz, pero puede aumentar la frecuencia dinámicamente con Turbo Boost, hasta 3,5 GHz (para 2 núcleos activos), y 3,7 GHz (para 1 núcleo activo). Como su predecesor, el Core i7-2640M basado en Sandy-Bridge, él ofrece un cache de 4 MB L3.

Ivy Bridge es una matriz mejorada y reducida de la arquitectura Sandy Bridge con mejoras en el rendimiento del GPU y CPU. Los CPUs son producidos en 22nm (contra 32nm de los CPUs Sandy Bridge) y son los primeros en introducir transistores 3D para una mejor eficiencia energética al compararlo con procesadores Sandy Bridge con frecuencias similares. Otros nuevos recursos son el PCI Express 3.0 integrado y soporte para DDR3(L)-1600.

El rendimiento del Core i7-3540M es ligeramente superior al de un procesador Sandy Bridge con frecuencia similar gracias a las mejoras arquitectónicas. Como resultado, el rendimiento es de alrededor de 5 - 10 % por encima del antiguo i7-2640M.

El Intel HD Graphics 4000 integrado, ofrece 16 Unidades de Ejecución (EUs) con frecuencia de 650 MHz hasta 1300 MHz con Turbo Boost, lo cual lo convierte en la variante más veloz.

Tal como la mayoría de los otros dual-cores Ivy Bridge, el i7-3540M está clasificado en un TDP de 35 W. Por tanto, hasta los portátiles más pequeños pueden utilizar el Core i7.

SerieIntel Core i7
Nombre códigoIvy Bridge

Serie: Core i7 Ivy Bridge

Intel Core i7-3940XM3 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-3920XM2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 8 cores6 MB L3
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 8 cores6 MB L3
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 8 cores6 MB L3
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-3540M « 3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-3520M2.9 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-3687U2.1 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i7-3667U2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-3537U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i7-3517U1.9 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 4 cores4 MB L3
Velocidad de reloj3000 - 3700 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)35 Watt
Tecnología de producción22 nm
Temperatura Máx.105 °C
ConectorBGA1023, PGA988
RecursosHD Graphics 4000 (650 - 1300 MHz), DDR3-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1300 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio01/01/2013
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.41     de promedio: 3.5     mediana: 3.5 (4%)     max: 3.49 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.52     de promedio: 1.5     mediana: 1.5 (38%)     max: 1.54 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5018     de promedio: 5030     mediana: 5029.5 (30%)     max: 5041 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 10628     de promedio: 10811     mediana: 10810.5 (8%)     max: 10993 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 13307     de promedio: 13435     mediana: 13434.5 (9%)     max: 13562 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 6326     de promedio: 6414     mediana: 6414 (8%)     max: 6502 Points
wPrime 2.10 - wPrime 2.0 1024m *
471.2 s (6%)
wPrime 2.10 - wPrime 2.0 32m *
14.9 s (3%)
WinRAR - WinRAR 4.0
2940 puntos (5%)
X264 HD Benchmark 4.0 - x264 Pass 2
19.9 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
105.3 fps (24%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (6%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (5%)
TrueCrypt - TrueCrypt AES
1.7 GB/s (4%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 4267     de promedio: 4320     mediana: 4319.5 (9%)     max: 4372 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
10.4 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
23.9 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
557 s (2%)
Windows 7 Experience Index - Win7 CPU
7.3 Points (94%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
11749 Points (10%)
3DMark 11 - 3DM11 Performance Physics
min: 4391     de promedio: 4627     mediana: 4627 (13%)     max: 4863 Points
3DMark - 3DMark Ice Storm Physics
min: 40631     de promedio: 42023     mediana: 42022.5 (34%)     max: 43414 Points
3DMark - 3DMark Cloud Gate Physics
min: 3424     de promedio: 3483     mediana: 3482.5 (9%)     max: 3541 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 4929     de promedio: 4966     mediana: 4966 (9%)     max: 5003 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
