Intel Core i7-6650U

Intel 6650U

El Intel Core i7-6650U es un SoC dual-core ULV (ultra low voltage) basado en la arquitectura Skylake. En Septiembre de 2015, es la CPU más veloz de la serie de 15 W (además de la i7-6600U) y puede ser encontrada en ultrabooks así como en portátiles normales. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 2,2 - 3,4 GHz (2 núcleos: máx. 3,2 GHz), el chip también integra una GPU Iris Graphics 540 con 64 MB de eDRAM dedicada y un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. El SoC es producido utilizando un proceso de 14 nm con transistores FinFET.

Arquitectura

Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. Las amplias mejorías del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizados, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").

Además, la organización del cache eDRAM ha sido modificada. En vez de actuar como un cache víctima, que debe ser abordada mediante la L3/LLC, la eDRAM ahora puede ser abordada directamente por programas justo como las memoria principal. El tamaño aun es de 128 MB para los modelos quad-core (4C + GT4e), mientras que los chips dual-core (2C + GT3e) solo ofrecen 64 MB.

Rendimiento

Según las velocidades especificadas y la arquitectura mejorada, el Core i7-6650U debe desempeñarse de forma similar a un Core i5-4310M (Haswell, 37 W) y es uno de los dual-cores ULV más veloces de finales del 2015. Así, la CPU tiene poder suficiente para tareas de oficina y multimedia, bien como las aplicaciones más exigentes y multi tareas.

Gráficos

La unidad gráfica integrada, llamada Iris Graphics 540 representa la versión "GT3e" de la GPU Skylake (Intel Gen. 9). Las 48 Unidades de Ejecución, también llamadas EUs, tienen una velocidad de 300 - 1050 MHz y ofrece (gracias al veloz cache eDRAM) un rendimiento un poco superior que el de una GeForce 920M dedicada. Por eso, juegos de 2015 pueden ser jugados con fluidez con configuraciones bajas o medianas. Para más información sobre el rendimiento y recursos, visite nuestra página de la Iris Graphics 540.

Consumo de Energía

Especificada con un TDP de 15 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles y ultrabooks pequeños (11-pulgadas y superiores). De forma opcional, el TDP puede ser reducido a 9,5 watts (cTDP down), reduciendo la disipación de calor y el rendimiento, y permite diseños aun más compactos.

SerieIntel Core i7
Nombre códigoSkylake

Serie: Core i7 Skylake

Intel Core i7-6920HQ2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-6970HQ2.8 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-6870HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HK2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6770HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6700HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6567U3.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-6600U2.6 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6650U « 2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6560U2.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-6500U2.5 - 3.1 GHz2 / 4 cores4 MB L3
Velocidad de reloj2200 - 3400 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)15 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT
GPUIntel Iris Graphics 540 (300 - 1050 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$415 U.S.
Fecha de anuncio09/01/2015
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
342 Points (2%)
31 -91%
...
Intel Core i5-6267U
328.3 -4%
328.3 -4%
333 -3%
333.3 -3%
335 -2%
336 -2%
338 -1%
338.4 -1%
338.5 -1%
Intel Core i7-6650U
342
343 0%
343.3 0%
Intel Core i5-6287U
345 1%
Intel Core i3-8145U
345.5 1%
351.8 3%
352 3%
Intel Core i3-8109U
352.5 3%
352.7 3%
353 3%
...
5600 1537%
max:
15842 4532%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
132 Points (40%)
19 -86%
...
129.5 -2%
129.8 -2%
130 -2%
130 -2%
130.4 -1%
130.4 -1%
Intel Core i5-6267U
130.8 -1%
Intel Core i7-6560U
131.7 0%
131.9 0%
Intel Core i7-6650U
132
132.1 0%
133 1%
Intel Core i5-7Y57
133 1%
Intel Core i3-8121U
133 1%
133.2 1%
134 2%
134.5 2%
AMD Ryzen 5 PRO 2500U
135 2%
135.6 3%
...
311 136%
max:
332 152%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
3.8 Points (5%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.5 Points (38%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
11564 puntos (8%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
14833 Points (10%)
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
6787 Points (8%)
wPrime 2.10 - wPrime 2.0 1024m *
445.6 s (5%)
wPrime 2.10 - wPrime 2.0 32m *
14.9 s (3%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (6%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (6%)
TrueCrypt - TrueCrypt AES
2 GB/s (5%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
11.7 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
26.3 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
613 s (3%)
3DMark 11 - 3DM11 Performance Physics
4919 Points (13%)
3DMark - 3DMark Ice Storm Unlimited Physics
44857 Points (38%)
3DMark - 3DMark Cloud Gate Physics
3639 Points (9%)
3DMark - 3DMark Fire Strike Standard Physics
5372 Points (10%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
