Intel Core i7-2920XM

Intel 2920XM

El Intel Core i7-2920XM es le procesador quad-core más veloz para portátiles el 1er trimestre de 2011. Gracias a la marca Extreme Edition, el CPU debe ser fácilmente acelerado (multiplicador desbloqueado). Se basa en la arquitectura Sandy Bridge y ofrece Hyperthreading para controlar 8 threads simultáneamente (para un mejor uso del pipeline). Comparado con los anteriores quad-cores Clarksdale, el i7-2920XM ahora es producido por en 32nm, ofrece una tarjeta de video integrada y funciones AES. Comparado con el 2820QM de menos frecuencia, el 2920XM está especificado un TDP más alto.

Sandy Bridge es la sucesora evolutiva de la arquitectura Arrandale. Las mejoras más notables son las nuevas instrucciones AVX de 265Bit, el Turbo Boost mejorado y la integración de la tarjeta de video en el núcleo de 32nm del CPU. Además, el controlador de memoria integrado fue mejorado y soporta hasta 8 GB DDR3-1333.

El Core i7-2920XM ofrece una tarjeta de video integrada (Intel HD Graphics 3000) la cual demostró ser claramente más veloz que la antigua Intel HD Graphics en los CPUs Arrandale y a la altura de tarjeta de video dedicada de nivel básico como la GeForce 310M. La HD Graphics 3000 también soporta Turbo Boost y funciona con una frecuencia entre 650 MHz y 1300 MHz. Como la tarjeta de video comparte el veloz cache de último nivel, el procesador es un poco más lento con GPU activo.

Debido al alto Turbo Boost y Hyperthreading, el rendimiento del Core i5-2920XM puede alcanzar niveles del veloz procesador Core i5-2500K para desktop. Comparado con la anterior generación, el i7-2920XM es hasta 42% más veloz que el antiguo procesador Core i7-940XM. Por tanto, el rendimiento debe ser el suficiente incluso para las tareas más exigentes como la edición de videos HD o juegos 3D. Se pude encontrar extensos benchmarks detallados al final de esta página y en nuestro análisis de los nuevos procesadores quad core Sandy Bridge.

El alto índice TDP del 2920XM permite el uso del quad core sólo en portátiles grandes y pesados (normalmente 15" a arriba). Sin embargo, comparado con la anterior generación de quad-cores el TDP ha mejorado,ya que ahora está incluido el GPU.

SerieIntel Core i7
Nombre códigoSandy Bridge

Serie: Core i7 Sandy Bridge

Intel Core i7-2960XM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-2860QM2.5 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-2920XM « 2.5 - 3.5 GHz4 / 8 cores8 MB L3
Intel Core i7-2760QM2.4 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-2820QM2.3 - 3.4 GHz4 / 8 cores8 MB L3
Intel Core i7-2720QM2.2 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-2675QM2.2 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-2670QM2.2 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-2635QM2 - 2.9 GHz4 / 8 cores6 MB L3
Intel Core i7-2630QM2 - 2.9 GHz4 / 8 cores6 MB L3
Intel Core i7-2640M2.8 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i7-2620M2.7 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-2649M2.3 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-2629M2.1 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-2677M1.8 - 2.9 GHz2 / 4 cores4 MB L3
Intel Core i7-2637M1.7 - 2.8 GHz2 / 4 cores4 MB L3
Intel Core i7-2657M1.6 - 2.7 GHz2 / 4 cores4 MB L3
Intel Core i7-2617M1.5 - 2.6 GHz2 / 4 cores4 MB L3
Velocidad de reloj2500 - 3500 MHz
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)55 Watt
Conteo de Transistores995 Millón
Tecnología de producción32 nm
Tamaño de Matriz216 mm2
Temperatura Máx.100 °C
ConectorFCPGA988
RecursosHD Graphics 3000 (650-1300MHz), DDR3-1066/1333/1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (650 - 1300 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$1096 U.S.
Fecha de anuncio01/06/2011
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 5.7     de promedio: 6     mediana: 6 (8%)     max: 6.2 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4282     de promedio: 4387     mediana: 4378.5 (26%)     max: 4507 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 16067     de promedio: 16949     mediana: 17187.5 (12%)     max: 17355 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 19727     de promedio: 20763     mediana: 20959 (15%)     max: 21407 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 5343     de promedio: 5525     mediana: 5565 (7%)     max: 5628 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 264.9     de promedio: 276.9     mediana: 273.8 (3%)     max: 295 s
wPrime 2.10 - wPrime 2.0 32m *
min: 8.29     de promedio: 8.5     mediana: 8.4 (2%)     max: 8.9 s
WinRAR - WinRAR 4.0
min: 3296     de promedio: 3923     mediana: 3923 (6%)     max: 4550 puntos
X264 HD Benchmark 4.0 - x264 Pass 2
min: 30.4     de promedio: 30.8     mediana: 30.8 (11%)     max: 31.2 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 129.4     de promedio: 131.4     mediana: 131.4 (30%)     max: 133.4 fps
TrueCrypt - TrueCrypt Serpent
min: 0.293     de promedio: 0.3     mediana: 0.3 (9%)     max: 0.296 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.508     de promedio: 0.5     mediana: 0.5 (9%)     max: 0.521 GB/s
TrueCrypt - TrueCrypt AES
min: 2.8     de promedio: 3     mediana: 3 (8%)     max: 3.1 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 5944     de promedio: 6100     mediana: 6131 (13%)     max: 6206 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 10     de promedio: 10.5     mediana: 10 (2%)     max: 11.7 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 24     de promedio: 24.6     mediana: 24 (1%)     max: 25.9 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 580     de promedio: 600     mediana: 594 (3%)     max: 620 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 118300     de promedio: 121717     mediana: 121780 (58%)     max: 125070 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 71200     de promedio: 74190     mediana: 75680 (58%)     max: 75690 MFLOPS
Windows 7 Experience Index - Win7 CPU
min: 7.5     de promedio: 7.6     mediana: 7.6 (97%)     max: 7.6 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 20540     de promedio: 21107     mediana: 21148 (19%)     max: 21592 Points
3DMark 11 - 3DM11 Performance Physics
min: 7804     de promedio: 7915     mediana: 7914.5 (21%)     max: 8025 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
