Intel Core i7-940XM

Intel 940XM

El Intel Core i7 940XM Extreme Edition es un procesador avanzado, el procesador más veloz para portátiles en el momento del anuncio. Presenta 4 núcleos (CPU quad core) y Hyperthreading. Por lo tanto, los 8 threads pueden trabajar simultáneamente.

Gracias al modo Turbo, el CPU funciona con una frecuencia de hasta 3,3 GHz en aplicaciones single threaded. Usando dos núcleos, el CPU puede funcionar a una frecuencia de 3,2 GHz y usando los 4 núcleos, 2,4 GHz es la frecuencia máxima. Por eso incluso los juegos antiguos (single threaded) deben ejecutarse fluentemente con este CPU móvil, aunque la velocidad de frecuencia base sea bastante lenta. El 940XM debe proporcionar la potencia suficiente para todos los juegos y aplicaciones modernas (en 2010).

La línea Core i7 9xx posee un controlador integrado de memoria para barras DDR3 (1066 o 1333).Por lo tanto, el rendimiento de la memoria es muy bueno (comparado con CPUs más antiguos con controladores externos de memoria). Aun así esto lleva a un TDP más elevado de todo el chip.

La arquitectura Core aún es muy similar a la usada en los CPUs Core 2.

El consumo de energía de hasta 55 Watt (TDP) es bastante alta para un CPU de portátil y debido al Modo Turbo, el consumo de energía debe alcanzar estos valores altos.

SerieIntel Core i7
Nombre códigoClarksfield

Serie: Core i7 Clarksfield

Intel Core i7-940XM « 2.13 - 3.33 GHz4 / 8 cores8 MB L3
Intel Core i7-920XM2 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-840QM1.86 - 3.2 GHz4 / 8 cores8 MB L3
Intel Core i7-820QM1.73 - 3.06 GHz4 / 8 cores8 MB L3
Intel Core i7-740QM1.73 - 2.93 GHz4 / 8 cores6 MB L3
Intel Core i7-720QM1.6 - 2.8 GHz4 / 8 cores6 MB L3
Velocidad de reloj2130 - 3333 MHz
Bus Frontal2500
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)55 Watt
Conteo de Transistores774 Millón
Tecnología de producción45 nm
Tamaño de Matriz296 mm2
Temperatura Máx.100 °C
ConectorRPGA989
Recursos2.5 GT/s DMI, Virtualization Technology, Execute Disable Bit, Enahnced Speedstep Technology, Enhanced Halt State (C1E), 64, Turbo Boost (max. 3.33 GHz), Hyper-Threading, Trusted Execution Technology
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$1096 U.S.
Fecha de anuncio06/01/2010
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 3.65     de promedio: 3.9     mediana: 3.9 (5%)     max: 4.05 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
3630 puntos (22%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
11391 puntos (8%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 12642     de promedio: 13381     mediana: 13381 (9%)     max: 14120 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 4479     de promedio: 4488     mediana: 4488 (5%)     max: 4497 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 374     de promedio: 798     mediana: 798 (9%)     max: 1222 s
wPrime 2.10 - wPrime 2.0 32m *
min: 12     de promedio: 25.2     mediana: 25.2 (5%)     max: 38.36 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3884     de promedio: 4080     mediana: 4064 (9%)     max: 4293 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
12 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
28 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 699     de promedio: 700     mediana: 700 (3%)     max: 701 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
62380 MIPS (30%)
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
40660 MFLOPS (31%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
13326 Points (12%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
