Intel Core i7-2720QM

Intel 2720QM

El Intel Core i7-2720QM es un veloz procesador quad core de alta capacidad para portátiles. Se basa en la arquitectura Sandy Bridge y ofrece Hyperthreading para controlar 8 threads simultáneamente (para un mejor uso del pipeline). Comparado con los anteriores quad-cores Clarksdale, el i7-2720QM ahora es producido por en 32nm y ofrece una tarjeta de video integrada y funciones AES. Comparado con el 2820QM de mayor frecuencia, el 2720QM ofrece menos cache de nivel 3 (6 vs. 8MB).

Sandy Bridge es la sucesora evolutiva de la arquitectura Arrandale. Las mejoras más notables son las nuevas instrucciones AVX de 265Bit, el Turbo Boost mejorado y la integración de la tarjeta de video en el núcleo de 32nm del CPU. Además, el controlador de memoria integrado fue mejorado y soporta hasta 8 GB DDR3-1333.

El i7-2720QM ofrece una tarjeta de video integrada (Intel HD Graphics 3000) la cual demostró ser claramente más veloz que la antigua Intel HD Graphics en los CPUs Arrandale y a la altura de tarjeta de video dedicada de nivel básico como la GeForce 310M. La HD Graphics 3000 también soporta Turbo Boost y funciona con una frecuencia entre 650 MHz y 1300 MHz. Como la tarjeta de video comparte el veloz cache de último nivel, el procesador es un poco más lento con GPU activo.

El rendimiento del Core i7-2720QM es notablemente mejor que el antiguo i7-720QM e incluso un poco más veloz que el CPU Clarksfield i7-940XM quad core. Por tanto, el rendimiento debe ser suficiente para modernos juegos 3D aplicaciones exigentes. Gracias al veloz Turbo Boost 2.0 hasta aplicaciones de un solo thread funcionan muy rápido. Los resultados detallados de benchmark del 2720QM se pueden encontrar en la parte inferior de esta página, o en nuestro análisis detallado de los nuevos procesadores quad core Sandy Bridge.

El TDP relativamente alto del 2720QM de 45 Watt permite el uso del quad core sólo en portátiles de 15" y superiores. Sin embargo, comparado con la anterior generación de quad-cores el TDP ha mejorado, ya que ahora está incluido el GPU.

SerieIntel Core i7
Nombre códigoSandy Bridge

Serie: Core i7 Sandy Bridge

Intel Core i7-2960XM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-2860QM2.5 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-2920XM2.5 - 3.5 GHz4 / 8 cores8 MB L3
Intel Core i7-2760QM2.4 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-2820QM2.3 - 3.4 GHz4 / 8 cores8 MB L3
Intel Core i7-2720QM « 2.2 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-2675QM2.2 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-2670QM2.2 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-2635QM2 - 2.9 GHz4 / 8 cores6 MB L3
Intel Core i7-2630QM2 - 2.9 GHz4 / 8 cores6 MB L3
Intel Core i7-2640M2.8 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i7-2620M2.7 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-2649M2.3 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-2629M2.1 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-2677M1.8 - 2.9 GHz2 / 4 cores4 MB L3
Intel Core i7-2637M1.7 - 2.8 GHz2 / 4 cores4 MB L3
Intel Core i7-2657M1.6 - 2.7 GHz2 / 4 cores4 MB L3
Intel Core i7-2617M1.5 - 2.6 GHz2 / 4 cores4 MB L3
Velocidad de reloj2200 - 3300 MHz
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 36 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)45 Watt
Conteo de Transistores995 Millón
Tecnología de producción32 nm
Tamaño de Matriz216 mm2
Temperatura Máx.100 °C
ConectorFCBGA1224, FCPGA988
RecursosHD Graphics 3000 (650-1300MHz), DDR-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (650 - 1300 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$378 U.S.
Fecha de anuncio01/06/2011
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 5.12     de promedio: 5.3     mediana: 5.3 (7%)     max: 5.64 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4114     de promedio: 4168     mediana: 4167 (25%)     max: 4219 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 13961     de promedio: 14649     mediana: 14852 (11%)     max: 15301 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 15819     de promedio: 17946     mediana: 18193 (13%)     max: 19061 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 4204     de promedio: 5084     mediana: 5236 (6%)     max: 5299 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 410.2     de promedio: 423.1     mediana: 423.5 (5%)     max: 435.6 s
wPrime 2.10 - wPrime 2.0 32m *
min: 12.13     de promedio: 13     mediana: 13.1 (3%)     max: 13.73 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 5133     de promedio: 5529     mediana: 5616 (12%)     max: 5772 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 11     de promedio: 11.4     mediana: 11 (2%)     max: 12.3 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 26     de promedio: 27     mediana: 27 (1%)     max: 28.2 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 635     de promedio: 650     mediana: 647 (3%)     max: 671 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
109640 MIPS (52%)
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
66400 MFLOPS (51%)
Windows 7 Experience Index - Win7 CPU
7.5 Points (96%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 11457     de promedio: 17984     mediana: 18725 (17%)     max: 19716 Points
3DMark 11 - 3DM11 Performance Physics
min: 5473     de promedio: 6495     mediana: 6627 (18%)     max: 7334 Points
3DMark - 3DMark Ice Storm Physics
36234 Points (29%)
3DMark - 3DMark Cloud Gate Physics
5494 Points (14%)
3DMark - 3DMark Fire Strike Standard Physics
7558 Points (13%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
