Intel Core i7-2635QM

Intel 2635QM

El Intel Core i7-2630QM es un veloz procesador quad core para portátiles. Se basa en la arquitectura Sandy Bridge y ofrece Hyperthreading para controlar 8 threads simultáneamente (para un mejor uso del pipeline). Comparado con los anteriores quad-cores Clarksdale, el i7-2635QM ahora es producido por en 32nm y ofrece una tarjeta de video integrada y funciones AES. Comparado con el más veloz Core i7, el 2635QM no soporta funciones AES y VT-d (Sólo VT-x Virtualization).

Comparado con el Core i7-2630QM, el 2635QM ofrece una frecuencia Turbo Boost un poco más alta para el GPU (1200MHz contra 1100MHz) y es ofrecido en el paquete BGA (2630QM rPGA).

Sandy Bridge es la sucesora evolutiva de la arquitectura Arrandale. Las mejoras más notables son las nuevas instrucciones AVX de 265Bit, el Turbo Boost 2.0 mejorado y la integración de la tarjeta de video en el núcleo de 32nm del CPU.

El i7-2635QM ofrece una tarjeta de video integrada (Intel HD Graphics 3000) la cual es claramente más veloz que la antigua Intel HD Graphics en los CPUs Arrandale. Como el nuevo GPU está incluido en el CPU, también es producido en 32nm y comparte el veloz cache de nivel 3 con los núcleos del CPU (usando un nuevo ring bus). En el 2635QM tiene una frecuencia de 650-1200MHz (Turbo Boost).

Además, un controlador de memoria de dos canales DDR3 está incluida en el molde del CPU, y es utilizada por CPU y en parte por el GPU.

El rendimiento del Core i7-2635QM debe ser cerca de 10-15% más veloz que un Core i7 Clarksfield de frecuencia similar (vea las primeras pruebas de Anandtech). Por tanto, el 2635QM debe estar a la altura (o hasta más veloz) de un Core i7-920XM Quad-Core.

SerieIntel Core i7
Nombre códigoSandy Bridge

Serie: Core i7 Sandy Bridge

Intel Core i7-2960XM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-2860QM2.5 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-2920XM2.5 - 3.5 GHz4 / 8 cores8 MB L3
Intel Core i7-2760QM2.4 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-2820QM2.3 - 3.4 GHz4 / 8 cores8 MB L3
Intel Core i7-2720QM2.2 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-2675QM2.2 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-2670QM2.2 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-2635QM « 2 - 2.9 GHz4 / 8 cores6 MB L3
Intel Core i7-2630QM2 - 2.9 GHz4 / 8 cores6 MB L3
Intel Core i7-2640M2.8 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i7-2620M2.7 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-2649M2.3 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-2629M2.1 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-2677M1.8 - 2.9 GHz2 / 4 cores4 MB L3
Intel Core i7-2637M1.7 - 2.8 GHz2 / 4 cores4 MB L3
Intel Core i7-2657M1.6 - 2.7 GHz2 / 4 cores4 MB L3
Intel Core i7-2617M1.5 - 2.6 GHz2 / 4 cores4 MB L3
Velocidad de reloj2000 - 2900 MHz
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 36 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)45 Watt
Conteo de Transistores995 Millón
Tecnología de producción32 nm
Tamaño de Matriz216 mm2
Temperatura Máx.100 °C
ConectorFCBGA1224
RecursosHD Graphics 3000 (650-1200MHz), DDR-1333 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (650 - 1200 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio01/06/2011
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 4.6     de promedio: 4.7     mediana: 4.7 (6%)     max: 4.68 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 3677     de promedio: 3697     mediana: 3699 (22%)     max: 3699 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 13045     de promedio: 13521     mediana: 13581 (10%)     max: 13581 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
15522 Points (11%)
wPrime 2.10 - wPrime 2.0 1024m *
486 s (6%)
wPrime 2.10 - wPrime 2.0 32m *
15 s (3%)
3DMark 06 - CPU - 3DMark 06 - CPU
4906 Points (10%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
14 s (3%)
3DMark 11 - 3DM11 Performance Physics
5658 Points (15%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
