Intel Core i7-6770HQ

Intel 6770HQ

El Intel Core i7-6770HQ es un veloz procesador quad-core para portátiles basados en la arquitectura Skylake y fue introducido a principios de 2016. Además de cuatro núcleos de CPU incluyendo Hyperthreading, que tienen una velocidad entre 2,6-3,5 GHz (probables pasos Turbo: 4 núcleos: hasta 3,1 GHz, 2 núcleos: hasta 3,3 GHz), el procesador también incluye una unidad gráfica muy veloz. La Iris Pro Graphics 580 (GT4e) tiene 72 EUs así como 128 MB de cache eDRAM, que también pueden ser utilizados por los núcleos da la CPU. Es producido utilizando un proceso de 14 nm con transistores FinFET.

Contrario a otros modelos como el Core i7-6700HQ, el i7-6770HQ posee una GPU mucho más veloz.

Arquitectura

Intel utiliza Skylake para sustituir tanto Broadwell como Haswell y, por tanto el diseño de un núcleo para todas las clases de TDP entre 4,5-45 Watts. Diversas mejoras de la arquitectura Skylake incluyen un Out-to-Order-Buffer más grande, optimizaciones para el pre-fetching, así como ganancias más grandes por el Hyperthreading. Sin embargo, los cambios son pequeños para un "Tock" – una nueva micro arquitectura – en general, así el rendimiento por-MHz solo está entre 5-10 % (en comparación con Haswell) o menos de 5 % superior (en comparación con Broadwell), respectivamente.

El i7-6770HQ también se beneficia del cache de eDRAM adicional en algunos casos, que pueden acelerar aplicaciones pesadas para la memoria en particular.

Rendimiento

Gracias al cache de eDRAM adicional, el i7-6770HQ incluso podría competir con el i7-6700HQ de velocidad similar, y es, por tanto, uno de los procesadores de portátil más veloz de principios de 2016. Incluso las aplicaciones más exigentes y multi-tareas excesivas no son problema para la CPU de gama alta.

Gráficos

La GPU integrada con la designación Iris Pro Graphics 580 (también conocida como "GT4e") representa la versión más veloz de la GPU Skylake (Intel Gen. 9). 72 Unidades de Ejecución (EUs) funcionan a 350 hasta 950 MHz y permiten un rendimiento comparable al de un chip convencional dedicado. La GPU podría ser capaz de competir con una GeForce 945M bajo condiciones perfectas y por tanto es la iGPU más veloz en el mercado por un margen muy grande. Los juegos modernos de 2015/2016 normalmente pueden ser jugados fluidamente con configuraciones medianas. Más información sobre el rendimiento y los recursos están disponibles en nuestra página dedicada para la Iris Pro Graphics 580.

Consumo de Energía

De acuerdo con su TDP de 45 Watts, el chip está diseñado para portátiles más grades, comenzando con pantallas de 15-pulgadas. El TDP opcionalmente puede ser reducido a 35 Watts (cTDP down), pero obviamente esto afectará al rendimiento.

SerieIntel Core i7
Nombre códigoSkylake

Serie: Core i7 Skylake

Intel Core i7-6920HQ2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-6970HQ2.8 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-6870HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HK2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6770HQ « 2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6700HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6567U3.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-6600U2.6 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6650U2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6560U2.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-6500U2.5 - 3.1 GHz2 / 4 cores4 MB L3
Velocidad de reloj2600 - 3500 MHz
Caché de Nivel 1256 KB
Caché de Nivel 21 MB
Caché de Nivel 36 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)45 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, AVX, AVX2, Quick Sync, Virtualization, AES-NI, TXT
GPUIntel Iris Pro Graphics 580 (350 - 950 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$434 U.S.
Fecha de anuncio01/24/2016
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
711 Points (4%)
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 130     de promedio: 134.5     mediana: 134.5 (41%)     max: 139 Points
19 -86%
...
132 -2%
132 -2%
132 -2%
132.1 -2%
133 -1%
Intel Core i5-7Y57
133 -1%
Intel Core i3-8121U
133 -1%
133.2 -1%
134 0%
Intel Core i7-6770HQ
134.5
AMD Ryzen 5 PRO 2500U
135 0%
135.6 1%
136.2 1%
136.2 1%
136.6 2%
137.5 2%
137.9 3%
138 3%
Intel Core i3-8109U
138.7 3%
...
311 131%
max:
332 147%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
7.8 Points (10%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.7 Points (41%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
5536 puntos (33%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
21075 puntos (15%)
wPrime 2.10 - wPrime 2.0 1024m *
225.7 s (3%)
wPrime 2.10 - wPrime 2.0 32m *
7.3 s (1%)
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
6069 MIPS (3%)
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
2480 MIPS (30%)
X264 HD Benchmark 4.0 - x264 Pass 2
43.5 fps (15%)
X264 HD Benchmark 4.0 - x264 Pass 1
164.7 fps (38%)
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
1.7 fps (3%)
00.20.30.50.70.811.21.31.51.71.822.22.32.52.72.833.2Tooltip
TrueCrypt - TrueCrypt Serpent
0.4 GB/s (12%)
TrueCrypt - TrueCrypt Twofish
0.7 GB/s (12%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
10.6 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
23.8 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
539 s (2%)
3DMark 11 - 3DM11 Performance Physics
9379 Points (25%)
3DMark - 3DMark Ice Storm Physics
45610 Points (37%)
3DMark - 3DMark Ice Storm Extreme Physics
45730 Points (37%)
3DMark - 3DMark Ice Storm Unlimited Physics
49105 Points (41%)
3DMark - 3DMark Cloud Gate Physics
6378 Points (16%)
3DMark - 3DMark Fire Strike Standard Physics
10210 Points (18%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
2641 puntos (26%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
5056 puntos (6%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
