Intel Core i7-640LM

Intel 640LM

El Intel Core i7-640LM es una rapida CPU de gama media y bajo voltaje de doble nucleo para portatiles con una velocidad de reloj (gracias al modo Turbo) de 2.16 a 2.93 GHz. Cada nucleo está basado en la microarquitectura Nehalem (Westemere). La tecnologia Hyperthreading permite a la CPU de doble nucleo manejar 4 hilos de forma simultanea (para un mejor uso del pipeline). Comparado con el Core i7-620M, el 640LM es más lento pero más eficiente.

Una caracteristica del nuevo Core i7-640LM es la tarjeta gráfica integrada (llamada HD Graphics) y el controlador de memoria. Estan situados en un 'die' separado que está aún fabricado en 45 nm mientras que la CPU está ya fabricada en el nuevo proceso de 32 nm.

Debido al controlador de memoria integrado, el Hyperthreading y el Turbo Boost, el Core i5-640LM es más rapido que los Core 2 Duo a velocidad similar en todoas las aplicaciones y pruebas que conocemos. El rendimiento debería estar en el nivel del Core i5-430M. Hay que tener en cuenta que algunos diseños pueden no presentar Turbo Boost. Por tanto, la CPU puede ser más lenta que la 430M.

Los nucleos de 32nm de la generación Westmere pueden procesar algunas instrucciones para acelerar encriptados AES. Aplicaciones modernas que soporten codificación AES pueden mejorar significativamente usando las nuevas instrucciones (p.e. el test Communication Suite en PCMark Vantage mejora un 70% su velocidad usando AES en el Core i520).

La tarjeta gráfica Graphics Media Accelerator HD de Intel (GMA HD) funciona a una velocidad entre 266566 MHz (Turbo Boost) y por tanto la velocidad base difiere claramente de las versiones de bajo voltaje. El rendimiento debería ser mejor que el de la vieja GMA 4500 MHD.

El consumo de corriente de 25 vatios de TDP (maximo) es para el paquete completo y por tanto es claramente mejor que el TDP de 25 vatios de la gama P de las CPUs Core 2 Duo (en los que el TDP se correspondia solo a la CPU).

SerieIntel Core i7
Nombre códigoArrandale

Serie: Core i7 Arrandale

Intel Core i7-640M2.8 - 3.46 GHz2 / 4 cores4 MB L3
Intel Core i7-620M2.66 - 3.33 GHz2 / 4 cores4 MB L3
Intel Core i7-660LM2.27 - 3.07 GHz2 / 4 cores4 MB L3
Intel Core i7-640LM « 2.13 - 2.93 GHz2 / 4 cores4 MB L3
Intel Core i7-620LM2 - 2.8 GHz2 / 4 cores4 MB L3
Intel Core i7-680UM1.47 - 2.53 GHz2 / 4 cores4 MB L3
Intel Core i7-660UM1.33 - 2.4 GHz2 / 4 cores4 MB L3
Intel Core i7-640UM1.2 - 2.27 GHz2 / 4 cores4 MB L3
Intel Core i7-620UM1.06 - 2.13 GHz2 / 4 cores4 MB L3
Velocidad de reloj2130 - 2933 MHz
Bus Frontal2500
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)25 Watt
Conteo de Transistores382+177 Millón
Tecnología de producción32 nm
Tamaño de Matriz81+177 mm2
Temperatura Máx.105 °C
ConectorBGA1288
RecursosTurbo Boost (2.93 GHz max), Hyper Threading, Enhanced Speedstep, integrierte GMA HD 266-566MHz, Dual-Channel DDR3-800/1066 Memory Controller
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$332 U.S.
Fecha de anuncio01/04/2010
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
1.9 Points (2%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 5869     de promedio: 5956     mediana: 5956 (4%)     max: 6043 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
7205 Points (5%)
wPrime 2.10 - wPrime 2.0 1024m *
min: 668     de promedio: 1037     mediana: 1036.5 (12%)     max: 1405 s
wPrime 2.10 - wPrime 2.0 32m *
min: 20.96     de promedio: 21.4     mediana: 21.4 (4%)     max: 21.9 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2496     de promedio: 2539     mediana: 2539 (5%)     max: 2582 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 14     de promedio: 14.5     mediana: 14.5 (3%)     max: 15 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 869     de promedio: 878     mediana: 877.5 (4%)     max: 886 s
PCMark 05 - PCMark 05 - Standard
5734 Points (12%)
Windows 7 Experience Index - Win7 CPU
min: 6.4     de promedio: 6.5     mediana: 6.5 (83%)     max: 6.6 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
