Intel Core i5-6198DU

Intel 6198DU

El Intel Core i5-6198DU es un veloz SoC dual-core ULV (ultra low voltage) basado en la arquitectura Skylake, y fue lanzado en septiembre del 2015. La CPU puede ser encontrada en ultrabooks, así como en portátiles normales. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 2,3 - 2,8 GHz (2 núcleos: máx. 2,7 GHz), el chip también integra una GPU Graphics 510 y un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. El SoC es producido utilizando un proceso de 14 nm con transistores FinFET. Comparado con el similar Core i5-6200U, el i5-6198DU ofrece una GPU más lenta (HD Graphics 510 versus 520).

Arquitectura

Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. La amplia mejoría del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizado, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento  fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").

Rendimiento de la CPU

Según las velocidades especificadas y la arquitectura mejorada, el Core i5-6198DU debe desempeñarse solo un poco más abajo del antiguo Core i7-5500U (Broadwell, 15 W) y es casi tan veloz como el Core i5-6200U. Así, la CPU tiene poder suficiente para tareas de oficina y multimedia, bien como las aplicaciones más exigentes y multi tareas.

Gráficos

La unidad gráfica integrada, llamada HD Graphics 510 representa la versión "GT1" de la GPU Skylake (Intel Gen. 9). Las 12 Unidades de Ejecución, también llamadas EUs, tienen una velocidad de 300 - 1000 MHz. La HD 520 en el 6200U para comparación, tiene 24 EUs.

Consumo de Energía

Especificada con un TDP de 15 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles y ultrabooks pequeños (11-pulgadas y superiores). De forma opcional, el TDP puede ser reducido a 7,5 watts (cTDP down, velocidad de 800 MHz), reduciendo la disipación de calor y el rendimiento, y permite diseños aun más compactos. Además, hay la opción de incrementar el TDP a 25 W (cTDP up, 2,4 GHz).

SerieIntel Core i5
Nombre códigoSkylake

Serie: Core i5 Skylake

Intel Core i5-6440HQ2.6 - 3.5 GHz4 / 4 cores6 MB L3
Intel Core i5-6350HQ2.3 - 3.2 GHz4 / 4 cores6 MB L3
Intel Core i5-6300HQ2.3 - 3.2 GHz4 / 4 cores6 MB L3
Intel Core i5-6287U3.1 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-6267U2.9 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i5-6360U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i5-6300U2.4 - 3 GHz2 / 4 cores3 MB L3
Intel Core i5-6260U1.8 - 2.9 GHz2 / 4 cores4 MB L3
Intel Core i5-6198DU « 2.3 - 2.8 GHz2 / 4 cores3 MB L3
Intel Core i5-6200U2.3 - 2.8 GHz2 / 4 cores3 MB L3
Velocidad de reloj2300 - 2800 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 33 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)15 Watt
Tecnología de producción14 nm
Tamaño de Matriz99 mm2
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel HD Graphics 510 (300 - 1000 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio09/01/2015
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
290 Points (2%)
31 -89%
...
269.5 -7%
269.5 -7%
Intel Core i5-7Y57
273 -6%
Intel Core i5-5350U
277 -4%
278 -4%
278.3 -4%
282.5 -3%
282.8 -2%
Intel Core i3-7130U
284 -2%
Intel Core i5-6198DU
290
292 1%
292.5 1%
292.5 1%
294.5 2%
296 2%
298 3%
301 4%
Intel Core i5-5257U
305 5%
305.3 5%
...
5600 1831%
max:
15842 5363%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
117 Points (35%)
19 -84%
...
112.3 -4%
113 -3%
113 -3%
114.3 -2%
114.3 -2%
115.4 -1%
115.9 -1%
Intel Core i5-5350U
116 -1%
116.8 0%
Intel Core i5-6198DU
117
117.5 0%
118 1%
118.1 1%
118.3 1%
118.4 1%
119 2%
119.1 2%
Intel Core m3-7Y32
120 3%
Intel Core i7-4712HQ
121.5 4%
...
311 166%
max:
332 184%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
3.2 Points (4%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.3 Points (33%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
4491 puntos (27%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
9954 puntos (7%)
wPrime 2.10 - wPrime 2.0 1024m *
569 s (7%)
wPrime 2.10 - wPrime 2.0 32m *
18 s (4%)
X264 HD Benchmark 4.0 - x264 Pass 2
19.1 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
102.3 fps (24%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (5%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (5%)
TrueCrypt - TrueCrypt AES
1.7 GB/s (4%)
3DMark 06 - CPU - 3DMark 06 - CPU
3769 Points (8%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
13.6 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
30.4 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
675 s (3%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
10734 Points (10%)
3DMark 11 - 3DM11 Performance Physics
min: 4182     de promedio: 4222     mediana: 4222 (11%)     max: 4262 Points
3DMark - 3DMark Ice Storm Physics
34986 Points (28%)
3DMark - 3DMark Ice Storm Extreme Physics
33879 Points (27%)
3DMark - 3DMark Ice Storm Unlimited Physics
35007 Points (29%)
3DMark - 3DMark Cloud Gate Physics
2984 Points (8%)
3DMark - 3DMark Fire Strike Standard Physics
4281 Points (8%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
3618 puntos (49%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
6769 puntos (16%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
6205 puntos (11%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
3009 puntos (59%)
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
6472 puntos (10%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
3153 puntos (47%)
Geekbench 2 - 32 Bit - Geekbench Stream
10381 Points (84%)
Geekbench 2 - 32 Bit - Geekbench Memory
8197 Points (74%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
6095 Points (12%)
Geekbench 2 - 32 Bit - Geekbench Integer
6058 Points (12%)
Geekbench 2 - 32 Bit - Geekbench Total Score
6931 Points (18%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
1283 ms (2%)
Sunspider - Sunspider 1.0 Total Score *
113.5 ms (1%)
Octane V2 - Octane V2 Total Score
27986 Points (25%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
