Intel Core i5-6260U

Intel 6260U

El Intel Core i5-6260U es un veloz SoC dual-core ULV (ultra low voltage) basado en la arquitectura Skylake, y fue lanzado en septiembre del 2015. La CPU puede ser encontrada en ultrabooks, así como en portátiles normales. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 1,8 - 2,9 GHz (2 núcleos: máx. 2,7 GHz), el chip también integra una GPU Iris Graphics 540 con 64 MB de eDRAM dedicada y un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. El SoC es producido utilizando un proceso de 14 nm con transistores FinFET.

Arquitectura

Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. Las amplias mejorías del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizados, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").

Además, la organización del cache eDRAM ha sido modificada. En vez de actuar como un cache víctima, que debe ser abordada mediante la L3/LLC, la eDRAM ahora puede ser abordada directamente por programas justo como las memoria principal. El tamaño aun es de 128 MB para los modelos quad-core (4C + GT4e), mientras que los chips dual-core (2C + GT3e) solo ofrecen 64 MB.

Rendimiento

Según las velocidades especificadas y la arquitectura mejorada, el Core i5-6260U debe desempeñarse de forma similar al antiguo Core i7-5500U/5550U (Broadwell, 15 W). Así, la CPU tiene poder suficiente para tareas de oficina y multimedia, bien como las aplicaciones más exigentes y multi tareas.

Gráficos

La unidad gráfica integrada, llamada Iris Graphics 540 representa la versión "GT3e" de la GPU Skylake (Intel Gen. 9). Las 48 Unidades de Ejecución Execution, también llamadas EUs, tienen una velocidad de 300 - 950 MHz y ofrece (gracias al veloz cache eDRAM) un rendimiento un poco superior que el de una GeForce 920M dedicada. Por eso, juegos de 2015 pueden ser jugados con fluidez con configuraciones bajas o medianas. Para más información sobre el rendimiento y recursos, visite nuestra página de la Iris Graphics 540.

Consumo de Energía

Especificada con un TDP de 15 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles y ultrabooks pequeños (11-pulgadas y superiores). De forma opcional, el TDP puede ser reducido a 9,5 watts (cTDP down), reduciendo la disipación de calor y el rendimiento, y permite diseños aun más compactos.

SerieIntel Core i5
Nombre códigoSkylake

Serie: Core i5 Skylake

Intel Core i5-6440HQ2.6 - 3.5 GHz4 / 4 cores6 MB L3
Intel Core i5-6350HQ2.3 - 3.2 GHz4 / 4 cores6 MB L3
Intel Core i5-6300HQ2.3 - 3.2 GHz4 / 4 cores6 MB L3
Intel Core i5-6287U3.1 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-6267U2.9 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i5-6360U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i5-6300U2.4 - 3 GHz2 / 4 cores3 MB L3
Intel Core i5-6260U « 1.8 - 2.9 GHz2 / 4 cores4 MB L3
Intel Core i5-6198DU2.3 - 2.8 GHz2 / 4 cores3 MB L3
Intel Core i5-6200U2.3 - 2.8 GHz2 / 4 cores3 MB L3
Velocidad de reloj1800 - 2900 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 34 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)15 Watt
Tecnología de producción14 nm
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel Iris Graphics 540 (300 - 950 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$304 U.S.
Fecha de anuncio09/01/2015
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
298 Points (2%)
31 -90%
...
282.5 -5%
282.8 -5%
Intel Core i3-7130U
284 -5%
290 -3%
292 -2%
292.5 -2%
292.5 -2%
294.5 -1%
296 -1%
Intel Core i5-6260U
298
301 1%
Intel Core i5-5257U
305 2%
305.3 2%
307 3%
307.4 3%
308 3%
Intel Core i5-6360U
309 4%
310 4%
Intel Core i7-6560U
311.7 5%
...
5600 1779%
max:
15842 5216%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
117 Points (35%)
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
3.3 Points (4%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.3 Points (33%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
4481 puntos (27%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
9949 puntos (7%)
wPrime 2.10 - wPrime 2.0 1024m *
558 s (7%)
wPrime 2.10 - wPrime 2.0 32m *
18 s (4%)
X264 HD Benchmark 4.0 - x264 Pass 2
19.3 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
105 fps (24%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (5%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (5%)
TrueCrypt - TrueCrypt AES
1.7 GB/s (4%)
3DMark 06 - CPU - 3DMark 06 - CPU
3883 Points (8%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
13.8 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
29.2 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
660 s (3%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
11110 Points (10%)
3DMark 11 - 3DM11 Performance Physics
4420 Points (12%)
3DMark - 3DMark Ice Storm Unlimited Physics
39229 Points (33%)
3DMark - 3DMark Cloud Gate Physics
3208 Points (8%)
3DMark - 3DMark Fire Strike Standard Physics
4544 Points (8%)
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
6512 puntos (10%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
3193 puntos (48%)
Geekbench 2 - 32 Bit - Geekbench Stream
10021 Points (81%)
Geekbench 2 - 32 Bit - Geekbench Memory
8235 Points (75%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
6446 Points (13%)
Geekbench 2 - 32 Bit - Geekbench Integer
6033 Points (12%)
Geekbench 2 - 32 Bit - Geekbench Total Score
7016 Points (18%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
1181 ms (1%)
Sunspider - Sunspider 1.0 Total Score *
85.5 ms (1%)
Octane V2 - Octane V2 Total Score
30382 Points (27%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
