Rockchip RK3288

 RK3288

El Rockchip RK3288 es un SoC ARM de gama media para sistema móviles Android y Chrome OS. Integra cuatro núcleos Cortex-A12 con velocidad de hasta 1,8 GHz. ARM llama a estos núcleos Cortex-A17 debido a que tienen niveles de rendimiento muy similares. El SoC incluye una GPU ARM Mali-T760 MP4 (también llamado Mali-T764) con velocidad de 600 MHz y un controlador de memoria dual-channel DDR3, DDR3L, LPDDR2, LPDDR3.

El ARM Cortex-A12 es el sucesor del Cortex-A9 y se basa en una micro arquitectura de 32 Bit ARMv7-A. Un solo núcleo A12 debe ser casi 40 % más poderoso que un núcleo A9, según ARM.

El motor de vídeo integrado soporta la codificación de vídeos H.264, VP8, y MVC hasta 1080p. La decodificación es soportada para vídeos hasta 4K H.264 y 10 Bit H.265.

El chip es producido bajo un proceso HKMG de 28 nm.

Serie
Serie:
UNISOC Tiger T3101.8 - 2 GHz4 / 4
» Rockchip RK32881.8 GHz4 / 4
Apple A6x1.4 GHz2
Apple A61 GHz2
Apple S52 / 2
HiSilicon k3v2 Hi36201.2 GHz4 / 4
Rockchip RK3066 1.5 GHz1.5 GHz2 / 2
Amlogic AML8726-MX1.5 GHz2 / 2
Rockchip RK31681.2 GHz2 / 2
Rockchip RK2918 1.2 GHz1.2 GHz1 / 1
ARM Cortex A8 1.2 GHz1.2 GHz1 / 1
Telechips TCC8803 1GHz1 GHz1 / 1
Loongson 2F 900MHz0.9 GHz1 / 1
CSR86700.08 GHz2
ARM Cortex-M4
HiSilicon Hi6262
DK3.5+ST2
unknown
Velocidad de reloj1800 MHz
Número de Núcleos/Subprocesos4 / 4
Tecnología de producción28 nm
RecursosARM MAli-T624 at 600 MHz, dedicated 2D processor, 1080P H.264, VP8, MVC encoding, 4K H.264 and 10 Bits H.265 decoding, 1080p multi video decode, Dual-channel DDR3(L) memory controller, HDMI 2.0
GPUARM Mali-T760 MP4 (600 MHz)
ArchitectureARM
Fecha de anuncio08/01/2014
Enlace de Producto (externo) RK3288

Benchmarks

3DMark - 3DMark Ice Storm Unlimited Physics
15496 Points (13%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 1909     de promedio: 2183     mediana: 2182.5 (4%)     max: 2456 puntos
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 698     de promedio: 779     mediana: 778.5 (15%)     max: 859 puntos
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 4753     de promedio: 5809     mediana: 5790 (7%)     max: 6884 ms
Sunspider - Sunspider 1.0 Total Score *
min: 745     de promedio: 746     mediana: 745.5 (8%)     max: 746 ms
Octane V2 - Octane V2 Total Score
min: 5967     de promedio: 6798     mediana: 7107 (7%)     max: 7319 Points
AnTuTu v6 - AnTuTu v6 Total Score
47100 Points (16%)
PCMark for Android - PCM f. Android Work Score
3888 Points (19%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
