Texas Instruments OMAP 4470

 OMAP 4470

El OMAP 4470 es un SoC (System on Chip) de cuarta generación desarrollado por Texas Instruments (TI) para el uso en teléfonos móviles y tablets. El chip de 45 nm incluye núcleos de Núcleos de CPU dual ARM Cortex-A9 funcionando a 1,3 GHz hasta 1,8 GHz en un conjunto de instrucciones ARM v7 y motor ARM NEON SIMD (Single Instruction, Multiple Data).

El SoC integra un GPU SGX540 PowerVR con frecuencia de 277 - 384 MHz, que puede utilizar el mismo controlador de memoria de 400 MHz de dos canales LPDDR2 que los dos procesadores core. Comparado con el OMAP 4430, el 4470 tiene una frecuencia más alta, tanto en el CPU como en el GPU.

Serie
Nombre códigoCortex A9
Serie: Cortex A9
» Texas Instruments OMAP 44701.5 GHz2 / 2 Cortex A9
Texas Instruments OMAP 44601.2 GHz2 / 2 Cortex A9
Broadcom BCM281551.2 GHz2 / 2 Cortex A9
Texas Instruments OMAP 44301 GHz2 / 2 Cortex A9
Apple A5x1 GHz2 Cortex A9
Apple A51 GHz2 Cortex A9
Velocidad de reloj1500 MHz
Caché de Nivel 11 MB
Número de Núcleos/Subprocesos2 / 2
Tecnología de producción45 nm
RecursosDual Channel LPDDR 400MHz Memory Controller, IVA 3 Multimedia Accelerator, PowerVR SGX 540 Graphics Core, Image Signal Processor
ArchitectureARM
Fecha de anuncio09/01/2011

Benchmarks

Geekbench 2 - 32 Bit - Geekbench Stream
min: 436     de promedio: 438     mediana: 438 (4%)     max: 440 Points
Geekbench 2 - 32 Bit - Geekbench Memory
min: 1302     de promedio: 1326     mediana: 1325.5 (12%)     max: 1349 Points
Geekbench 2 - 32 Bit - Geekbench Floating Point
min: 1895     de promedio: 1929     mediana: 1929 (4%)     max: 1963 Points
Geekbench 2 - 32 Bit - Geekbench Integer
min: 1118     de promedio: 1136     mediana: 1135.5 (2%)     max: 1153 Points
Geekbench 2 - 32 Bit - Geekbench Total Score
min: 1367     de promedio: 1381     mediana: 1381 (4%)     max: 1395 Points
Linpack Android / IOS - Linpack Multi Thread
min: 80.548     de promedio: 87.6     mediana: 87.6 (3%)     max: 94.597 MFLOPS
Linpack Android / IOS - Linpack Single Thread
min: 52.527     de promedio: 55.4     mediana: 55.4 (5%)     max: 58.339 MFLOPS
Sunspider - Sunspider 0.9.1 Total Score *
min: 1437.9     de promedio: 1497     mediana: 1496.8 (14%)     max: 1555.7 ms
Quadrant Standard Edition 2.0 - Quadrant Standard 2.0 Total Score
min: 2747     de promedio: 3447     mediana: 3447 (8%)     max: 4147 points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
