Intel Core i5-520UM

Intel 520UM

El Intel Core i5-520UM es un procesador de doble nucleo de voltaje ultrabajo para portatiles pequeños y ligeros. Funciona a 1.06 -1.86 GHz (si está activado Turbo Boost). Cada nucleo se basa en la microarquitectura Nehalem (Westemere). Hyperthreading permite a la CPU de Doble Nucleo manejar 4 hilos de forma simultanea (para un mejor uso del pipeline). Comparado con el Core i7-620M el i5 ofrece solo 3 MB de cache de nivel 3 (el i7 4MB) y una menor frecuencia de Turbo Boost. Otras CPUs Core i5 (sin la U en el nombre) son más rápidas debido a la mayor velocidad de reloj, pero necesitan más energia.

Una característica del nuevo Core i5-520UM es la tarjeta gráfica integrada (llamada Intel HD Graphics) y el controlador de memoria. Ambos están en un 'die' separado que está fabricado en 45 nm mientras que el 'die' de la CPU está fabricado ya en 32 nm.

Debido al controlador de memoria integrado, Hyperthreading y Turbo Boost, el Core i5-520UM es más rápido que un Core 2 Duo a la misma velocidad de reloj (1.2 GHz) en todas las aplicaciones y tests conocidos (por nosotros). Aunque como Turbo Boost podría no estar activado de forma común (a veces ni siquiera en la BIOS) el máximo de 1.86 GHz no es muy importante.

Los nucleos de 32 nm de la generación Westemere pueden procesar algunas instrucciones para acelerar encriptados AES. Aplicaciones modernas que soporten la codificación AES pueden beneficiarse de forma significativa del uso de las nuevas instrucciones (p.e. El Communications Suite de PCMark Vantage se aceleró hasta un 70% usando AES en el Core i5-520M).

La tarjeta gráfica integrada Intel Graphics Media Accelerator HD (GMA HD) funciona entre 166-500 MHz (Turbo Boost) y por tanto la velocidad base está claramente más alla que el de las versiones de voltaje normal. El rendimiento debería ser mejor que el de la antigua GMA 4500MHD.

El consumo de 18 vatios de TDP (máximo) cuenta para el paquete completo y por tanto es mejor que los 17 vatios de TDP del Core 2 Duo de la gama SL (que son solo de la CPU).

SerieIntel Core i5
Nombre códigoArrandale

Serie: Core i5 Arrandale

Intel Core i5-580M2.67 - 3.33 GHz2 / 4 cores3 MB L3
Intel Core i5-560M2.67 - 3.2 GHz2 / 4 cores3 MB L3
Intel Core i5-480M2.67 - 2.93 GHz2 / 4 cores3 MB L3
Intel Core i5-540M2.53 - 3.07 GHz2 / 4 cores3 MB L3
Intel Core i5-460M2.53 - 2.8 GHz2 / 4 cores3 MB L3
Intel Core i5-520M2.4 - 2.93 GHz2 / 4 cores3 MB L3
Intel Core i5-450M2.4 - 2.66 GHz2 / 4 cores3 MB L3
Intel Core i5-430M2.26 - 2.53 GHz2 / 4 cores3 MB L3
Intel Core i5-560UM1.33 - 2.13 GHz2 / 4 cores3 MB L3
Intel Core i5-470UM1.33 - 1.87 GHz2 / 4 cores3 MB L3
Intel Core i5-540UM1.2 - 2 GHz2 / 4 cores3 MB L3
Intel Core i5-520UM « 1.06 - 1.87 GHz2 / 4 cores3 MB L3
Intel Core i5-430UM1.2 - 1.73 GHz2 / 4 cores3 MB L3
Velocidad de reloj1060 - 1866 MHz
Bus Frontal2500
Caché de Nivel 2512 KB
Caché de Nivel 33 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)18 Watt
Conteo de Transistores382+177 Millón
Tecnología de producción32 nm
Tamaño de Matriz81+114 mm2
Temperatura Máx.105 °C
ConectorBGA1288
RecursosTurbo Boost (1.86 GHz max), Hyper Threading, Enhanced Speedstep, integrierte GMA HD 166-500MHz,
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$241 U.S.
Fecha de anuncio01/04/2010
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.02     de promedio: 1.2     mediana: 1.2 (2%)     max: 1.33 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 1471     de promedio: 1981     mediana: 1942.5 (12%)     max: 2569 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 2785     de promedio: 3670     mediana: 3778 (3%)     max: 4340 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 3946     de promedio: 4600     mediana: 4632.5 (3%)     max: 5187 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 2263     de promedio: 2561     mediana: 2423.5 (3%)     max: 3135 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 995     de promedio: 1110     mediana: 1110 (13%)     max: 1225 s
wPrime 2.10 - wPrime 2.0 32m *
min: 31.8     de promedio: 35.2     mediana: 35.2 (7%)     max: 38.5 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 982     de promedio: 1429     mediana: 1492 (3%)     max: 1718 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 24     de promedio: 26.7     mediana: 25 (5%)     max: 31 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 56     de promedio: 62.3     mediana: 58 (2%)     max: 73 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1303     de promedio: 1439     mediana: 1341 (6%)     max: 1674 s
PCMark 05 - PCMark 05 - Standard
min: 2848     de promedio: 3571     mediana: 3925 (8%)     max: 3940 Points
Windows 7 Experience Index - Win7 CPU
min: 3.9     de promedio: 4.7     mediana: 4.8 (61%)     max: 5.4 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 3751     de promedio: 4065     mediana: 4064.5 (4%)     max: 4378 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
