AMD A4-4300M

AMD A4-4300M

El AMD A4-4300M es un procesador dual-core móvil basado en la arquitectura Trinity. Presentado oficialmente en 2012, es el sucesor directo de la serie A Llano de APUs (Accelerated Processing Unit) . La unidad de procesamiento es producida en 32nm SOI e integra un CPU de 2,5 GHz (hasta 3,0 GHz con Turbo Core) con un GPU Radeon HD 7420G con un controlador de memoria de dos canales, decodificadores y codificadores de video y un northbridge.

Los núcleos del CPU se basan en una arquitectura Bulldozer reformulada, llamada Piledriver. Aunque es comercializado como un procesador dual-core, el A6-4400M incluye sólo un módulo con dos núcleos enteros y un núcleo de punto flotante. Como resultado, el CPU no es un verdadero procesador dual-core.

II) Cuando se lo compara con anteriores núcleos Bulldozer, AMD logró mejorar el rendimiento IPC (instrucciones per clock) de núcleos Trinity mientras permite frecuencias superiores. No obstante, cuando es comparado con su predecesor Llano, el rendimiento multithreaded del Trinity fue apenas ligeramente mejorado. El recurso Turbo Core 3.0 mejorado funciona bien, acelerando el rendimiento single threaded, aunque aún no esté en el mismo nivel del equivalente Turbo Boost de Intel. A pesar de todo, AMD también logró incluir otros recursos, tal como la extensión AVX (incluyendo FMA) y soporte para la codificación AES.

En términos de rendimiento bruto general, el A4-4300M se desempeña de forma similar al A4-3310MX basado en Llano. Cargas de trabajo single-threaded pueden beneficiarse mucho de la nueva arquitectura y de la actualización de la funcionalidad Turbo Core. Si es comparado con las series Pentium de Intel, el A4-4300M ofrece menos rendimiento en la mayoría de los casos. A pesar de todo, el rendimiento de CPU del procesador AMD es suficiente para todos las tareas de oficina del día a día y navegar por Internet, pero alcanzará sus límites en aplicaciones más exigentes.

La Radeon HD 7420G integrada, compatible con DirectX 11 probablemente ofrece apenas 192 núcleos shader del chip Trinity (7660G: 384) y, gracias al Turbo Core, operará en algún lugar entre 470 a 640 MHz dependiendo de la exigencia de la aplicación. En promedio, el rendimiento de la GPU HD 7420G debe estar en algún lugar entre la Radeon HD 6520G basada en Llano y la HD Graphics 4000 como encontramos en el Ivy Bridge de Intel.

El consumo de energía de la APU A4-4300M se clasifica con TDP de 35 Watts y es, por tanto, comparable con procesadores dual-core Ivy Bridge. Consecuentemente, la A4-4300M es bien adecuada para portátiles de 14 pulgadas o superiores.

SerieAMD A-Series
Nombre códigoTrinity

Serie: A-Series Trinity

AMD A10-4600M2.3 - 3.2 GHz4 / 4 cores
AMD A10-4657M2.3 - 3.2 GHz4 / 4 cores
AMD A10-4655M2 - 2.8 GHz4 / 4 cores
AMD A8-4500M1.9 - 2.8 GHz4 / 4 cores
AMD A8-4557M1.9 - 2.8 GHz4 / 4 cores
AMD A8-4555M1.6 - 2.4 GHz4 / 4 cores
AMD A6-4400M2.7 - 3.2 GHzcores
AMD A4-4300M « 2.5 - 3 GHzcores
AMD A6-4455M2.1 - 2.6 GHzcores
AMD A4-4355M1.9 - 2.4 GHzcores
Velocidad de reloj2500 - 3000 MHz
Caché de Nivel 21 MB
Número de Núcleos/Subprocesos2
Consumo de Corriente (TDP = Thermal Design Power)35 Watt
Conteo de Transistores1303 Millón
Tecnología de producción32 nm
Tamaño de Matriz246 mm2
RecursosSSE (1, 2, 3, 3S, 4.1, 4.2, 4A), x86-64, AES, AVX, FMA
GPUAMD Radeon HD 7420G (480 - 655 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio06/30/2012

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
93 Points (1%)
31 -67%
...
72 -23%
72.2 -22%
Intel Celeron N2840
73.7 -21%
AMD A6 Pro-7050B
81.5 -12%
84 -10%
85.4 -8%
86 -8%
Intel Celeron J3355
90 -3%
AMD E2-9010
91 -2%
AMD A4-4300M
93
Intel Atom x5-Z8300
93.5 1%
Intel Atom x5-E8000
94 1%
AMD A4 Micro-6400T
95 2%
96.1 3%
97 4%
AMD A9-9420e
97 4%
101 9%
103 11%
Intel Atom x5-Z8500
103.3 11%
...
5600 5922%
max:
15842 16934%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.03     de promedio: 1     mediana: 1 (1%)     max: 1.05 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
0.7 Points (17%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 1779     de promedio: 1997     mediana: 1996.5 (12%)     max: 2214 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 3140     de promedio: 3144     mediana: 3144 (2%)     max: 3148 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 2127     de promedio: 3161     mediana: 3161 (2%)     max: 4195 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 2283     de promedio: 2613     mediana: 2613 (3%)     max: 2943 Points
wPrime 2.10 - wPrime 2.0 1024m *
1619 s (19%)
wPrime 2.10 - wPrime 2.0 32m *
50.4 s (10%)
X264 HD Benchmark 4.0 - x264 Pass 2
7.1 fps (2%)
X264 HD Benchmark 4.0 - x264 Pass 1
36 fps (8%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (2%)
TrueCrypt - TrueCrypt Twofish
0.1 GB/s (2%)
TrueCrypt - TrueCrypt AES
0.6 GB/s (2%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 1671     de promedio: 1684     mediana: 1684 (4%)     max: 1697 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
33.9 s (7%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
75.6 s (3%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
2066 s (9%)
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
16680 MIPS (8%)
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
11210 MFLOPS (9%)
Windows 7 Experience Index - Win7 CPU
5.2 Points (67%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
3254 Points (3%)
3DMark 11 - 3DM11 Performance Physics
1355 Points (4%)
3DMark - 3DMark Ice Storm Physics
12469 Points (10%)
3DMark - 3DMark Cloud Gate Physics
996 Points (3%)
3DMark - 3DMark Fire Strike Standard Physics
1359 Points (2%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
2115 puntos (4%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
1512 puntos (30%)
Geekbench 2 - 32 Bit - Geekbench Stream
2965 Points (24%)
Geekbench 2 - 32 Bit - Geekbench Memory
2978 Points (27%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
3696 Points (7%)
Geekbench 2 - 32 Bit - Geekbench Integer
2855 Points (6%)
Geekbench 2 - 32 Bit - Geekbench Total Score
3184 Points (8%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
