AMD E2-9000

AMD E2-9000

El AMD E2-9000 es el chip menos potente de la serie APU Stoney-Ridge para portátiles (7ma generación de APU) en el momento del anuncio en 2017. El SoC integra dos núcleos de CPU (un módulo Excavator con 2 enteros y una unidad FP) con velocidad entre 1,8-2,2 GHz. También incluye una GPU Radeon R2 con velocidad de 600 MHz, así como un controlador de memoria single-channel DDR4-1866, motor de vídeo H.265 y chipset con todos los puertos I/O. Comparado con el E2-9010 antiguo, el E2-9000 ofrece una velocidad base más baja (1,8 frente a 2 GHz).

Arquitectura

Stoney Ridge es el sucesor de la arquitectura Carrizo y e diseño es casi igual. Gracias a los procesos de producción optimizados y al comportamiento Boost más agresivo, sin embargo, las velocidades son un poco más altas con el mismo consumo de energía. El controlador de memoria ahora también soporta RAM DDR4, en este caso hasta 1866 MHz. Stoney Ridge es la designación para el chip dual-core y single-core más pequeño, mientras que Bristol Ridge es el chip quad-core más grande con controlador de memoria dual-channel. Más detalles técnicos están disponibles en los siguientes artículos:

La arquitectura Bristol Ridge y Stoney Ridge de AMD

AMD: Las APUs Bristol Ridge anunciaron

Consumo de Energía

AMD especifica el TDP del E2-9000 con 10 Watts (en comparación con el 9010 a 15 W). Esto significa que la APU está destinado para portátiles delgados y livianos.

SerieAMD Bristol Ridge
Nombre códigoStoney Ridge

Serie: Bristol Ridge Stoney Ridge

AMD A9-94253.1 - 3.7 GHz2 / 2 cores
AMD A9-9420e - 2.5 GHz2 / 2 cores
AMD A9-94203 - 3.6 GHz2 / 2 cores
AMD A9-94102.9 - 3.5 GHz2 / 2 cores
AMD A6-92252.6 - 3.1 GHz2 / 2 cores
AMD A6-92202.5 - 2.9 GHz2 / 2 cores
AMD A6-9220C1.8 - 2.7 GHz2 / 2 cores
AMD A6-92102.4 - 2.8 GHz2 / 2 cores
AMD A4-91202.2 - 2.5 GHz2 / 2 cores
AMD A4-9120C1.6 - 2.4 GHz2 / 2 cores
AMD E2-90102 - 2.2 GHz2 / 2 cores
AMD E2-9000 « 1.8 - 2.2 GHz2 / 2 cores
AMD A6-9220e1.6 - 2.4 GHz2 / 2 cores
Velocidad de reloj1800 - 2200 MHz
Caché de Nivel 21 MB
Número de Núcleos/Subprocesos2 / 2
Consumo de Corriente (TDP = Thermal Design Power)10 Watt
Conteo de Transistores1200 Millón
Tecnología de producción28 nm
Tamaño de Matriz124.5 mm2
Temperatura Máx.90 °C
ConectorBGA
RecursosSingle-Channel DDR4-1866, Virtualization,
GPUAMD Radeon R2 (Stoney Ridge) ( - 600 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio06/01/2016
Enlace de Producto (externo)www.amd.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
84 Points (1%)
31 -63%
...
59 -30%
Intel Celeron N3050
61.2 -27%
65 -23%
68.3 -19%
71.8 -15%
72 -14%
72.2 -14%
Intel Celeron N2840
73.7 -12%
AMD A6 Pro-7050B
81.5 -3%
AMD E2-9000
84
85.4 2%
86 2%
Intel Celeron J3355
90 7%
AMD E2-9010
91 8%
93 11%
Intel Atom x5-Z8300
93.5 11%
Intel Atom x5-E8000
94 12%
AMD A4 Micro-6400T
95 13%
96.1 14%
...
5600 6567%
max:
15842 18760%
0%
100%
05101520253035404550556065707580Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
47 Points (14%)
19 -60%
...
40.67 -13%
Intel Atom x7-E3950
41 -13%
41.88 -11%
42.45 -10%
44 -6%
44.03 -6%
AMD A6-7310
44.5 -5%
45.71 -3%
AMD A4-7210
46 -2%
AMD E2-9000
47
47.17 0%
Intel Celeron J3355
47.6 1%
49 4%
AMD A6 Pro-7050B
49.5 5%
AMD A8-7410
51.5 10%
51.7 10%
AMD E2-9010
53 13%
53.7 14%
55 17%
...
311 562%
max:
332 606%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
1 Points (1%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
0.6 Points (15%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
1787 puntos (11%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
2897 puntos (2%)
wPrime 2.10 - wPrime 2.0 1024m *
1242 s (15%)
WinRAR - WinRAR 4.0
744 puntos (1%)
X264 HD Benchmark 4.0 - x264 Pass 2
6.3 fps (2%)
X264 HD Benchmark 4.0 - x264 Pass 1
35.7 fps (8%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (3%)
TrueCrypt - TrueCrypt Twofish
0.1 GB/s (2%)
TrueCrypt - TrueCrypt AES
0.7 GB/s (2%)
3DMark 06 - CPU - 3DMark 06 - CPU
1556 Points (3%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
26.9 s (6%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
59.8 s (3%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
1304 s (6%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
3146 Points (3%)
3DMark 11 - 3DM11 Performance Physics
1199 Points (3%)
3DMark - 3DMark Ice Storm Physics
11949 Points (10%)
3DMark - 3DMark Ice Storm Extreme Physics
10209 Points (8%)
3DMark - 3DMark Ice Storm Unlimited Physics
11528 Points (10%)
3DMark - 3DMark Cloud Gate Physics
914 Points (2%)
3DMark - 3DMark Fire Strike Standard Physics
1255 Points (2%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
1591 puntos (16%)
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
2461 puntos (3%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
1543 puntos (21%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
2371 puntos (6%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
2323 puntos (4%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
1430 puntos (28%)
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
2439 puntos (4%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
1526 puntos (23%)
Geekbench 2 - 32 Bit - Geekbench Stream
2993 Points (24%)
Geekbench 2 - 32 Bit - Geekbench Memory
2893 Points (26%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
2847 Points (6%)
Geekbench 2 - 32 Bit - Geekbench Integer
2914 Points (6%)
Geekbench 2 - 32 Bit - Geekbench Total Score
2894 Points (8%)
Sunspider - Sunspider 1.0 Total Score *
258.9 ms (3%)
Octane V2 - Octane V2 Total Score
10575 Points (10%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance

v1.26
log 17. 21:11:19

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Sat, 16 Mar 2024 05:37:00 +0100 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_2 needed +0.007s ... 0.008s

#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.008s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.009s

#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#10 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#11 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#12 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#13 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.01s

#14 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.011s

#15 composed specs +0s ... 0.011s

#16 did output specs +0s ... 0.011s

#17 getting avg benchmarks for device 9294 +0.003s ... 0.014s

#18 got single benchmarks 9294 +0.013s ... 0.027s

#19 got avg benchmarks for devices +0s ... 0.027s

#20 min, max, avg, median took s +0.858s ... 0.885s

#21 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.885s

#22 return log +0s ... 0.885s

Análisis para el AMD E2-9000 procesador

Breve análisis del portátil Lenovo IdeaPad 320-17AST (E2-9000, HD )

Breve análisis del portátil Lenovo IdeaPad 320-17AST (E2-9000, HD )

Portátil de oficina simple. El nuevo Lenovo IdeaPad es un portátil de 17,3" que funciona silenciosamente y apenas se calienta. Estas características están acom...
AMD E2-9000 | AMD Radeon R2 (Stoney Ridge) | 17.30" | 2.8 kg

HP 255 G6 3GJ54ES: AMD Radeon R2 (Stoney Ridge), 15.60", 1.9 kg
  análise externo » HP 255 G6 3GJ54ES

Lenovo Ideapad 320-14AST-81D50000UK: AMD Radeon R2 (Stoney Ridge), 14.00", 2.1 kg
  análise externo » Lenovo Ideapad 320-14AST-81D50000UK

Lenovo Ideapad 320-15AST-80XV00U4SP: AMD Radeon R2 (Stoney Ridge), 15.60", 2.2 kg
  análise externo » Lenovo Ideapad 320-15AST-80XV00U4SP
