Intel Core i5-6200U
El Intel Core i5-6200U es un veloz SoC dual-core ULV (ultra low voltage) basado en la arquitectura Skylake, y fue lanzado en septiembre del 2015. La CPU puede ser encontrada en ultrabooks, así como en portátiles normales. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 2,3 - 2,8 GHz (2 núcleos: máx. 2,7 GHz), el chip también integra una GPU Graphics 520 y un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. El SoC es producido utilizando un proceso de 14 nm con transistores FinFET.
Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. Las amplias mejorías del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizados, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").
Según las velocidades especificadas y la arquitectura mejorada, el Core i5-6200U debe desempeñarse solo un poco más abajo del antiguo Core i7-5500U (Broadwell, 15 W). Así, la CPU tiene poder suficiente para tareas de oficina y multimedia, bien como las aplicaciones más exigentes y multi tareas.
La unidad gráfica integrada, llamada HD Graphics 520 representa la versión "GT2" de la GPU Skylake (Intel Gen. 9). Las 24 Unidades de Ejecución, también llamadas EUs, tienen una velocidad de 300 - 1000 MHz y ofrecen un rendimiento en algún lugar en el rango de una GeForce 820M. Por eso, juegos de 2015 pueden ser jugados con fluidez con configuraciones bajas. Para más información sobre el rendimiento y recursos, visite nuestra página de la HD Graphics 520.
Especificada con un TDP de 15 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles y ultrabooks pequeños (11-pulgadas y superiores). De forma opcional, el TDP puede ser reducido a 7,5 watts (cTDP down), reduciendo la disipación de calor y el rendimiento, y permite diseños aun más compactos.
Serie Intel Core i5 Nombre código Skylake Serie: Core i5 Skylake Velocidad de reloj 2300 - 2800 MHz Caché de Nivel 1 128 KB Caché de Nivel 2 512 KB Caché de Nivel 3 3 MB Número de Núcleos/Subprocesos 2 / 4 Consumo de Corriente (TDP = Thermal Design Power) 15 Watt Tecnología de producción 14 nm Tamaño de Matriz 99 mm2 Temperatura Máx. 100 °C Conector BGA Recursos Dual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI GPU Intel HD Graphics 520 (300 - 1000 MHz)64 Bit soporte para 64 Bit Architecture x86 Precio inicial $281 U.S. Fecha de anuncio 09/01/2015 Enlace de Producto (externo) Intel Core i5 6200U
Benchmarks Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 170 de promedio: 282.5 mediana: 289 (3%) max: 310 Points
...
Intel Core i5-4310U
AMD Ryzen Embedded R1505G
Intel Core m3-7Y32
Intel Core i5-7Y57
Intel Core i5-5350U
Intel Core i3-7130U
...
AMD Ryzen 9 7945HX3D
0 15 30 45 60 75 90 105 120 135 150 165 180 195 210 225 240 255 270 285 Tooltip Fujitsu Lifebook E746: Ø206 (180.72-223.76)
Lenovo E31-80 80MX0107GE: Ø287 (285.74-288.64)
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 70 de promedio: 111.8 mediana: 115 (35%) max: 123 Points
...
Intel Celeron N4505
Intel Core i5-4310U
Intel Celeron N5105
Intel Core i3-7130U
Intel Core i5-5350U
...
AMD Ryzen 9 7945HX3D
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.75 de promedio: 3.1 mediana: 3.2 (5%) max: 3.42 Points
...
Intel Core i5-5350U
Intel Core i5-7Y57
Intel Core i3-7130U
Intel Core i7-2640M
...
AMD Ryzen 9 7945HX
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.94 de promedio: 1.3 mediana: 1.3 (34%) max: 1.37 Points
...
Intel Core i5-5350U
Intel Celeron N4505
Intel Core i3-7130U
...
Intel Core i9-13980HX
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 3150 de promedio: 4319 mediana: 4383 (26%) max: 4802 puntos
...
Intel Processor N95
AMD Ryzen 5 PRO 2500U
Intel Core i3-7130U
Intel Core i7-2640M
...
Intel Core i9-13980HX
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 1810 de promedio: 9473 mediana: 9871.5 (7%) max: 10078 puntos
...
Intel Core i7-2640M
Intel Core i3-7130U
Intel Core i5-7Y57
...
Intel Core i9-13980HX
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 11770 de promedio: 12612 mediana: 12624 (9%) max: 13058 Points
...
Intel Core i7-2640M
Intel Core i5-7Y57
...
Intel Core i9-13980HX
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 5055 de promedio: 5607 mediana: 5651.5 (31%) max: 5829 Points
...
Intel Core i7-2640M
Intel Core i5-4310U
Intel Core i7-2860QM
Intel Core i5-6267U
...
Intel Core i9-13980HX
wPrime 2.10 - wPrime 2.0 1024m *
min: 497.9 de promedio: 557 mediana: 560 (7%) max: 650 s
...
AMD Phenom II X4 N970
Intel Processor N95
AMD Phenom II X4 N950
Intel Core i3-7130U
...
VIA C3-M C3-M-1200
wPrime 2.10 - wPrime 2.0 32m *
min: 15.34 de promedio: 17.9 mediana: 17.8 (4%) max: 21.16 s
...
AMD Phenom II X4 N970
AMD Phenom II X4 N950
Intel Core i3-7130U
...
min: 1388 de promedio: 1867 mediana: 2041 (4%) max: 2188 puntos
...
Intel Pentium 3825U
Intel Core i3-8145U
Intel Core i5-6360U
...
AMD Ryzen 9 7945HX3D
X264 HD Benchmark 4.0 - x264 Pass 2
min: 16 de promedio: 18.9 mediana: 19 (7%) max: 19.9 fps
...
Intel Core i3-7130U
...
Intel Core i9-13900HX
X264 HD Benchmark 4.0 - x264 Pass 1
min: 87 de promedio: 99.6 mediana: 100 (24%) max: 106.9 fps
...
Intel Core m5-6Y57
AMD Ryzen 5 PRO 2500U
Intel Core i3-7130U
Intel Core i5-4200H
...
Intel Core i9-13900HX
TrueCrypt - TrueCrypt Serpent
min: 0.163 de promedio: 0.2 mediana: 0.2 (6%) max: 0.184 GB/s
...
AMD A6-7310
AMD Pro A8-8600B
Intel Core i3-7130U
Intel Core i5-4200H
...
AMD Ryzen 9 7945HX
TrueCrypt - TrueCrypt Twofish
min: 0.279 de promedio: 0.3 mediana: 0.3 (5%) max: 0.314 GB/s
...
Intel Core i3-7130U
Intel Core i5-6360U
Intel Core i5-5257U
AMD PRO A8-9600B
...
Intel Core i9-13980HX
TrueCrypt - TrueCrypt AES
min: 1.6 de promedio: 1.7 mediana: 1.7 (5%) max: 1.9 GB/s
...
Intel Core i7-2640M
Intel Core i5-4310U
Intel Core i3-7130U
...
AMD Ryzen 9 7945HX
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3082 de promedio: 3707 mediana: 3787 (8%) max: 3859 Points
...
Intel Core i5-7Y57
Intel Core i3-7130U
...
Intel Core i9-13980HX
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 12.45 de promedio: 13.8 mediana: 13.7 (3%) max: 15.42 s
...
Intel Core m5-6Y57
Intel Core i5-6267U
...
VIA C3-M C3-M-1200
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 28.24 de promedio: 31.2 mediana: 31 (1%) max: 33.91 s
...
Intel Core i5-2415M
Intel Core i5-4310U
...
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 473.2 de promedio: 695 mediana: 705 (3%) max: 752 s
...
Intel Core i5-4310U
AMD Ryzen 7 7735U
AMD Ryzen 5 7535HS
...
VIA C3-M C3-M-1200
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 8648 de promedio: 10027 mediana: 10215 (10%) max: 10834 Points
...
Intel Core i5-4310U
Intel Core i7-2640M
...
AMD Ryzen 9 7945HX
3DMark 11 - 3DM11 Performance Physics
min: 3055 de promedio: 3784 mediana: 3751 (10%) max: 4250 Points
...
Intel Core i3-7130U
...
AMD Ryzen 9 7945HX3D
3DMark - 3DMark Ice Storm Physics
min: 3457 de promedio: 32443 mediana: 33585.5 (28%) max: 37802 Points
...
...
Intel Core i9-12900HX
3DMark - 3DMark Ice Storm Extreme Physics
min: 23977 de promedio: 32608 mediana: 33113 (27%) max: 37587 Points
...
AMD Ryzen 5 PRO 2500U
Intel Core i5-7Y57
...
Intel Core i9-12900HX
3DMark - 3DMark Ice Storm Unlimited Physics
min: 26217 de promedio: 35322 mediana: 36596 (31%) max: 42260 Points
...
Intel Core i3-7130U
Intel Core i5-1230U
...
Intel Core i7-13700H
3DMark - 3DMark Cloud Gate Physics
min: 2380 de promedio: 3052 mediana: 3101 (8%) max: 3338 Points
...
Intel Core i5-7Y57
Intel Core i5-6360U
Intel Core i3-7130U
Intel Core i5-5350U
...
AMD Ryzen 9 7945HX
3DMark - 3DMark Fire Strike Standard Physics
min: 3388 de promedio: 4356 mediana: 4434 (8%) max: 4737 Points
...
Intel Core i5-7Y57
Intel Core i3-7130U
...
AMD Ryzen 9 7945HX3D
3DMark - 3DMark Time Spy CPU
1495 Points (7%)
...
Intel Core i5-7Y57
Intel Celeron N5105
Intel Core i3-8145U
...
Intel Core i9-13980HX
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
3285 puntos (34%)
...
Intel Celeron N4505
Intel Core i3-7100U
Intel Core i3-6157U
AMD Ryzen 3 PRO 2300U
Intel Core i7-2860QM
AMD Ryzen 5 PRO 2500U
Intel Core i3-7130U
...
Intel Core i9-13900HX
Geekbench 4.1 - 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
6126 puntos (7%)
...
AMD Ryzen Embedded R1505G
Intel Core i3-7100U
Intel Core i3-6157U
Intel Core m3-7Y32
Intel Core i3-7130U
...
Intel Core i9-13900HX
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
min: 3225 de promedio: 3444 mediana: 3507 (50%) max: 3601 puntos
...
Intel Core i3-7100U
Intel Core i3-7130U
AMD Ryzen 5 PRO 2500U
Intel Core i5-7200U
...
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
min: 5896 de promedio: 6393 mediana: 6502 (16%) max: 6780 puntos
...
Intel Core i3-7100U
Intel Core i3-7130U
Intel Core i5-7200U
Intel Core i5-6360U
...
AMD Ryzen 7 7735HS
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 5144 de promedio: 5794 mediana: 5796.5 (10%) max: 6182 puntos
...
Intel Core i5-4200H
Intel Core i3-7130U
...
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 2228 de promedio: 2702 mediana: 2726 (53%) max: 3013 puntos
...
Intel Core m5-6Y57
Intel Core i5-4200H
Intel Core i3-7130U
...
Intel Core i5-1230U
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
min: 5801 de promedio: 5964 mediana: 5929.5 (9%) max: 6195 puntos
...
Intel Core m5-6Y57
Intel Core i3-7130U
Intel Core i5-7Y57
...
Intel Core i5-1230U
Geekbench 3 - Geekbench 3 64 Bit Single-Core
min: 2694 de promedio: 2810 mediana: 2782.5 (42%) max: 2980 puntos
...
Intel Core M-5Y31
Intel Core m5-6Y57
Intel Core i3-7130U
Intel Core i5-7200U
...
Intel Core i5-1230U
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 1216 de promedio: 1524 mediana: 1285 (2%) max: 3622 ms
...
AMD Ryzen 5 PRO 2500U
Intel Core i3-7100U
AMD Ryzen Embedded R1505G
Intel Core i5-5257U
Intel Celeron N5105
Intel Core i3-6157U
...
Sunspider - Sunspider 1.0 Total Score *
min: 89 de promedio: 126.2 mediana: 97.8 (1%) max: 475.3 ms
...
Intel Core i5-7200U
