Intel Core i3-6100H

Intel 6100H

El Intel Core i3-6100H es un procesador dual-core basado en la arquitectura Broadwell, que fue lanzado en septiembre del 2015. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 2,7 GHz), el chip también integra una GPU HD Graphics 530 y un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. La CPU es producida utilizando un proceso de 14 nm con transistores FinFET.

Arquitectura

Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. Las amplias mejorías del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizados, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").

Además, la organización del cache eDRAM ha sido modificada. En vez de actuar como un cache víctima, que debe ser abordada mediante la L3/LLC, la eDRAM ahora puede ser abordada directamente por programas justo como las memoria principal. El tamaño aun es de 128 MB para los modelos quad-core (4C + GT4e), mientras que los chips dual-core (2C + GT3e) solo ofrecen 64 MB.

Rendimiento

Según las velocidades especificadas y la arquitectura mejorada, el Core i3-6100H debe desempeñarse de forma similar a un Core i5-5300U (Broadwell, 15 W) o un Core i7-4510U (Haswell, 15 W). Así, la CPU tiene poder suficiente para tareas de oficina y multimedia, bien como las aplicaciones más exigentes y multi tareas.

Gráficos

La unidad gráfica integrada, llamada HD Graphics 530 representa la versión "GT2" de la GPU Skylake (Intel Gen. 9). Las 24 Unidades de Ejecución, también llamadas EUs, tienen una velocidad de 350 - 900 MHz y ofrecen un rendimiento de alrededor de 20 por ciento por encima de la antigua HD Graphics 4600. Por eso, juegos de 2015 pueden ser jugados con fluidez con configuraciones bajas o medianas. Para más información sobre el rendimiento y recursos, visite nuestra página de la HD Graphics 530.

Consumo de Energía

Especificada con un TDP de 35 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles medianos (13-pulgadas y superiores).

SerieIntel Core i3
Nombre códigoSkylake

Serie: Core i3 Skylake

Intel Core i3-6167U2.7 GHz2 / 4 cores3 MB L3
Intel Core i3-6100H « 2.7 GHz2 / 4 cores3 MB L3
Intel Core i3-6157U2.4 GHz2 / 4 cores3 MB L3
Intel Core i3-6100U2.3 GHz2 / 4 cores3 MB L3
Intel Core i3-6006U2 GHz2 / 4 cores3 MB L3
Velocidad de reloj2700 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 33 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)35 Watt
Tecnología de producción14 nm
Tamaño de Matriz99 mm2
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel HD Graphics 530 (350 - 900 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$225 U.S.
Fecha de anuncio09/01/2015
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
292 Points (2%)
31 -89%
...
269.5 -8%
Intel Core i5-7Y57
273 -7%
Intel Core i5-5350U
277 -5%
278 -5%
278.3 -5%
282.5 -3%
282.8 -3%
Intel Core i3-7130U
284 -3%
290 -1%
Intel Core i3-6100H
292
292.5 0%
292.5 0%
294.5 1%
296 1%
298 2%
301 3%
Intel Core i5-5257U
305 4%
305.3 5%
307 5%
...
5600 1818%
max:
15842 5325%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
108 Points (33%)
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
3.2 Points (4%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.3 Points (32%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
4380 puntos (26%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
9989 puntos (7%)
WinRAR - WinRAR 4.0
1997 puntos (3%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (5%)
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (5%)
TrueCrypt - TrueCrypt AES
1.7 GB/s (4%)
3DMark 06 - CPU - 3DMark 06 - CPU
3829 Points (8%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
14 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
32 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
732 s (3%)
3DMark 11 - 3DM11 Performance Physics
3778 Points (10%)
3DMark - 3DMark Ice Storm Physics
35546 Points (29%)
3DMark - 3DMark Cloud Gate Physics
3148 Points (8%)
3DMark - 3DMark Fire Strike Standard Physics
4528 Points (8%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
4867 puntos (9%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
2321 puntos (45%)
Sunspider - Sunspider 1.0 Total Score *
94 ms (1%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
