Intel Core i3-2330M

Intel 2330M

El Intel Core i3-2330M es un procesador dual-core para portátiles. Está basado en la arquitectura Sandy Bridge y ofrece Hyperthreading para manejar 4 hilos a la vez (para un mejor uso de la pipeline). Comparado con la mas veloz Core i5, la i3 no ofrece la técnica Turbo Boost para la parte CPU cuya velocidad es de 2.2 GHz (máximo). Comparado con la Core i3-2310M, la 2330M ofrece sólo 100 MHz mas velocidad de reloj.

Sandy Bridge es el sucesor evolutivo de la arquitectura Arrandale. Las mejoras mas notables son las nuevas instrucciones 265Bit AVX, el mejorado Turbo 2.0 (no habilitada para la parte del procesador del 2330M) y la integración de la gráfica en el núcleo de 32nm dde la CPU.

El i3-2330M ofrece una tarjeta gráfica integrada (Intel HD Graphics 3000) que es claramente más rápida que la vieja Intel HD Graphics en las CPUs Arrandale. Como la nueva GPU está incluída en la CPU, también se fabrica en 32nm y comparte la rápida caché L3 con los núcleos CPU (usando un nuevo bus ring). En la 2330M la velocidad es de  650-1100MHz (con Turbo Boost). Las CPUs Sandy Bridge mas veloces van hasta a 1300 MHz (como el i5-2520M).

Lo que es mas, un controlador de memoria mejorado dual-channel DDR3 viene incluído en la CPU y lo usan tanto la parte CPU como la GPU.

Gracias a la mejorada arquitectura, el rendimiento medio del Core i7-2330M es superior a la de un Arrandale Core i3 a velocidad similar sin Turbo Boost. En bancos de pruebas sintéticos, el rendimiento queda casi a la par con el más rápido Core i3-380M (2.5 GHz) y por tanto es adecuado para la mayoría de aplicaciones.

La valoración del TDP de 35W incluye la CPU integrada y el controlador de memoria.

SerieIntel Core i3
Nombre códigoSandy Bridge

Serie: Core i3 Sandy Bridge

Intel Core i3-2370M2.4 GHz2 / 4 cores3 MB L3
Intel Core i3-2350M2.3 GHz2 / 4 cores3 MB L3
Intel Core i3-2348M2.3 GHz2 / 4 cores3 MB L3
Intel Core i3-2330M « 2.2 GHz2 / 4 cores3 MB L3
Intel Core i3-2328M2.2 GHz2 / 4 cores3 MB L3
Intel Core i3-2312M2.1 GHz2 / 4 cores3 MB L3
Intel Core i3-2310M2.1 GHz2 / 4 cores3 MB L3
Intel Core i3-2308M2.1 GHz2 / 4 cores3 MB L3
Intel Core i3-2377M1.5 GHz2 / 4 cores3 MB L3
Intel Core i3-2375M1.5 GHz2 / 4 cores3 MB L3
Intel Core i3-2367M1.4 GHz2 / 4 cores3 MB L3
Intel Core i3-2365M1.4 GHz2 / 4 cores3 MB L3
Intel Core i3-2357M1.3 GHz2 / 4 cores3 MB L3
Velocidad de reloj2200 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 33 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)35 Watt
Conteo de Transistores624 Millón
Tecnología de producción32 nm
Tamaño de Matriz149 mm2
Temperatura Máx.85 (PGA); 100(BGA) °C
ConectorrPGA988B / BGA1023
RecursosHD Graphics 3000 (650-1100MHz), DDR3-1066/1333 Memory Controller (max 8GB), HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 3000 (650 - 1100 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio05/15/2011
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 2.07     de promedio: 2.1     mediana: 2.1 (3%)     max: 2.14 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2869     de promedio: 2888     mediana: 2888 (17%)     max: 2904 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 6263     de promedio: 6457     mediana: 6465.5 (5%)     max: 6593 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 7745     de promedio: 7876     mediana: 7887 (5%)     max: 7944 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 3591     de promedio: 3624     mediana: 3623.5 (4%)     max: 3654 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 722     de promedio: 781     mediana: 789 (9%)     max: 826 s
wPrime 2.10 - wPrime 2.0 32m *
min: 22     de promedio: 24.7     mediana: 25.1 (5%)     max: 26.38 s
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (3%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (3%)
TrueCrypt - TrueCrypt AES
0.2 GB/s (1%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2610     de promedio: 2629     mediana: 2627 (6%)     max: 2649 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 17     de promedio: 17.6     mediana: 17.7 (4%)     max: 18 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 40     de promedio: 40.3     mediana: 40 (2%)     max: 41 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 926     de promedio: 936     mediana: 941 (4%)     max: 944 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 33000     de promedio: 35000     mediana: 35000 (17%)     max: 37000 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 22170     de promedio: 24085     mediana: 24085 (18%)     max: 26000 MFLOPS
Windows 7 Experience Index - Win7 CPU
6.5 Points (83%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 6879     de promedio: 7014     mediana: 7008 (6%)     max: 7165 Points
3DMark 11 - 3DM11 Performance Physics
min: 2782     de promedio: 2786     mediana: 2786 (8%)     max: 2790 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
