Intel Core i3-6100U

Intel 6100U

El Intel Core i3-6100U es un veloz SoC dual-core ULV (ultra low voltage) basado en la arquitectura Skylake, y fue lanzado en septiembre del 2015. La CPU puede ser encontrada en ultrabooks, así como en portátiles normales. Además de los dos núcleos de CPU con Hyper-Threading con velocidad de 2,3 GHz), el chip también integra una GPU HD Graphics 520 y un controlador de memoria dual-channel DDR4-2133/DDR3L-1600. El SoC es producido utilizando un proceso de 14 nm con transistores FinFET.

Arquitectura

Skylake remplaza tanto a Haswell como a Broadwell y trae la misma micro arquitectura en todas las clases de TDP desde 4,5 a 45 W. Las amplias mejorías del diseño Skylake incluye más buffers "out-of-order", prefetching y predicción de árbol optimizados, así como más rendimiento adicional mediante Hyper-Threading. En general, no obstante, el rendimiento fue incrementado en solo 5 a 10 por ciento (en comparación con Haswell) respectivamente bajo 5 por ciento (en comparación con Broadwell), lo cual es bastante modesto para una arquitectura nueva ("Tock").

Rendimiento

Según las velocidades especificadas y la arquitectura mejorada, el Core i3-6100U debe desempeñarse solo un poco más abajo del antiguo Core i5-4200U (Haswell, 15 W). Así, la CPU tiene poder suficiente para tareas de oficina y multimedia, bien como las aplicaciones más exigentes y multi tareas livianas.

Gráficos

La unidad gráfica integrada, llamada HD Graphics 520 representa la versión "GT2" de la GPU Skylake (Intel Gen. 9). Las 24 Unidades de Ejecución, también llamadas EUs, tienen una velocidad de 300 - 1000 MHz y ofrecen un rendimiento en algún lugar en el rango de una GeForce 820M. Por eso, juegos de 2015 pueden ser jugados con fluidez con configuraciones bajas. Para más información sobre el rendimiento y recursos, visite nuestra página de la HD Graphics 520.

Consumo de Energía

Especificada con un TDP de 15 W (incluyendo CPU, GPU y controlador de memoria), la CPU es más adecuada para portátiles y ultrabooks pequeños (11-pulgadas y superiores). De forma opcional, el TDP puede ser reducido a 7,5 watts (cTDP down), reduciendo la disipación de calor y el rendimiento, y permite diseños aun más compactos.

SerieIntel Core i3
Nombre códigoSkylake

Serie: Core i3 Skylake

Intel Core i3-6167U2.7 GHz2 / 4 cores3 MB L3
Intel Core i3-6100H2.7 GHz2 / 4 cores3 MB L3
Intel Core i3-6157U2.4 GHz2 / 4 cores3 MB L3
Intel Core i3-6100U « 2.3 GHz2 / 4 cores3 MB L3
Intel Core i3-6006U2 GHz2 / 4 cores3 MB L3
Velocidad de reloj2300 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 33 MB
Número de Núcleos/Subprocesos2 / 4
Consumo de Corriente (TDP = Thermal Design Power)15 Watt
Tecnología de producción14 nm
Tamaño de Matriz99 mm2
Temperatura Máx.100 °C
ConectorBGA
RecursosDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel HD Graphics 520 (300 - 1000 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$281 U.S.
Fecha de anuncio09/01/2015
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 240     de promedio: 246.9     mediana: 247 (2%)     max: 251 Points
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 92     de promedio: 96.1     mediana: 97 (29%)     max: 98 Points
19 -80%
...
92 -4%
92.6 -4%
93 -3%
93 -3%
93 -3%
Intel Core M-5Y31
93.3 -3%
94 -2%
94.2 -2%
Intel Core i3-7100U
94.3 -2%
Intel Core i3-6100U
96.1
96.7 1%
AMD Ryzen Embedded R1505G
97.3 1%
Intel Core i3-5157U
98 2%
98.4 2%
Intel Core i3-6157U
98.8 3%
99.3 3%
99.3 3%
100.3 4%
101 5%
...
311 224%
max:
332 245%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 2.75     de promedio: 2.8     mediana: 2.8 (4%)     max: 2.78 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.1     de promedio: 1.1     mediana: 1.1 (28%)     max: 1.11 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 3710     de promedio: 3713     mediana: 3714 (22%)     max: 3714 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 8413     de promedio: 8425     mediana: 8426 (6%)     max: 8437 puntos
wPrime 2.10 - wPrime 2.0 1024m *
min: 657     de promedio: 739     mediana: 739 (9%)     max: 821 s
wPrime 2.10 - wPrime 2.0 32m *
min: 20.92     de promedio: 23.5     mediana: 23.5 (5%)     max: 26.1 s
WinRAR - WinRAR 4.0
1921 puntos (3%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (4%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (4%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 3212     de promedio: 3242     mediana: 3241.5 (7%)     max: 3271 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 16.53     de promedio: 16.6     mediana: 16.6 (4%)     max: 16.72 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 37.68     de promedio: 37.7     mediana: 37.7 (2%)     max: 37.71 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 838     de promedio: 844     mediana: 843.5 (4%)     max: 849 s
3DMark 11 - 3DM11 Performance Physics
min: 2807     de promedio: 3145     mediana: 3142.5 (8%)     max: 3479 Points
3DMark - 3DMark Ice Storm Physics
min: 3681     de promedio: 22600     mediana: 28073 (23%)     max: 30573 Points
3DMark - 3DMark Cloud Gate Physics
min: 2449     de promedio: 2605     mediana: 2661 (7%)     max: 2718 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 3367     de promedio: 3684     mediana: 3764 (7%)     max: 3805 Points
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
2861 puntos (39%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
5320 puntos (13%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 4804     de promedio: 4846     mediana: 4826 (9%)     max: 4907 puntos
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 2188     de promedio: 2210     mediana: 2191 (43%)     max: 2251 puntos
Geekbench 2 - 32 Bit - Geekbench Stream
4918 Points (40%)
Geekbench 2 - 32 Bit - Geekbench Memory
5053 Points (46%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
5066 Points (10%)
Geekbench 2 - 32 Bit - Geekbench Integer
5127 Points (10%)
Geekbench 2 - 32 Bit - Geekbench Total Score
5069 Points (13%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 1474     de promedio: 2300     mediana: 2763 (3%)     max: 2817 ms
Sunspider - Sunspider 1.0 Total Score *
min: 109.1     de promedio: 125.6     mediana: 133.7 (1%)     max: 134.1 ms
Octane V2 - Octane V2 Total Score
min: 12368     de promedio: 16817     mediana: 13598 (12%)     max: 24139 Points
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
