AMD A9-9410

AMD A9-9410

El AMD A9-9410 es un chip de nivel de entrada de la serie de APUs Bristol-Ridge para portátiles (7ma generación de APU), que fue anunciada a mediados de 2016. Al momento de su lanzamiento, el A9-9410 es el procesador Stoney Ridge más veloz (versión dual-core de Bristol Ridge) e integra dos núcleos de CPU (un módulo Excavator con 2 integer y una unidad FP) con velocidades entre 2,9-3,5 GHz. También incluye una GPU Radeon R5 con 192 shaders a 800 MHz, así como un controlador de memoria single-channel DDR4-2133, motor de vídeo H.265 y chipset con todos los puertos I/O.

Arquitectura

Stoney Ridge es el sucesor de la arquitectura Carrizo y e diseño es casi igual. Gracias a los procesos de producción optimizados y al comportamiento Boost más agresivo, sin embargo, las velocidades son un poco más altas con el mismo consumo de energía. El controlador de memoria ahora también soporta RAM DDR4, en este caso hasta 2133 MHz. Stoney Ridge es la designación para el chip dual-core y single-core más pequeño, mientras que Bristol Ridge es el chip quad-core más grande con controlador de memoria dual-channel. Más detalles técnicos están disponibles en los siguientes artículos:

La arquitectura Bristol Ridge y Stoney Ridge de AMD

AMD: Las APUs Bristol Ridge anunciaron

Rendimiento

Gracias a la velocidad máxima de hasta 3,5 GHz, el rendimiento single-core debe ser muy bueno. El rendimiento multi-core, por otro lado, es muy inferior en comparación con los modelos Bristol Ridge. Comparado con los antiguos quad-cores Carrizo-L/Beema, la APU aun debería desempeñarse muy bien. El nivel de rendimiento debe ser similar al del Core-m3 y, por tanto también sería suficiente para aplicaciones más exigentes.

El TDP puede ser configurado entre 10-25 Watts, así que puede haber grandes diferencias en el rendimiento, bajo carga de trabajo sostenidas.

Tarjeta de Vídeo

La GPU Radeon R5 (Stoney Ridge) integrada tiene 192 unidades shader activas (3 núcleos de cómputo) con velocidad de hasta 800 MHz. Más detalles sobre la GPU están disponibles en los artículos vinculados anteriormente.

Consumo de Energía

AMD especifica el TDP del A9-9450 con 15 Watts, pero puede ser configurado entre 10-25 Watts. Esto significa que la CPU es una buena opción para portátiles delgados y livianos, pero también dispositivos de 15 pulgadas con mejores capacidades de enfriamiento.

SerieAMD Bristol Ridge
Nombre códigoStoney Ridge

Serie: Bristol Ridge Stoney Ridge

AMD A9-94253.1 - 3.7 GHz2 / 2 cores
AMD A9-9420e - 2.5 GHz2 / 2 cores
AMD A9-94203 - 3.6 GHz2 / 2 cores
AMD A9-9410 « 2.9 - 3.5 GHz2 / 2 cores
AMD A6-92252.6 - 3.1 GHz2 / 2 cores
AMD A6-92202.5 - 2.9 GHz2 / 2 cores
AMD A6-9220C1.8 - 2.7 GHz2 / 2 cores
AMD A6-92102.4 - 2.8 GHz2 / 2 cores
AMD A4-91202.2 - 2.5 GHz2 / 2 cores
AMD A4-9120C1.6 - 2.4 GHz2 / 2 cores
AMD E2-90102 - 2.2 GHz2 / 2 cores
AMD E2-90001.8 - 2.2 GHz2 / 2 cores
AMD A6-9220e1.6 - 2.4 GHz2 / 2 cores
Velocidad de reloj2900 - 3500 MHz
Caché de Nivel 21 MB
Número de Núcleos/Subprocesos2 / 2
Consumo de Corriente (TDP = Thermal Design Power)10-25 Watt
Conteo de Transistores1200 Millón
Tecnología de producción28 nm
Tamaño de Matriz124.5 mm2
Temperatura Máx.90 °C
ConectorBGA
RecursosSingle-Channel DDR4-2133, Virtualization,
GPUAMD Radeon R5 (Stoney Ridge) ( - 800 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio06/01/2016
Enlace de Producto (externo)products.amd.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
130 Points (1%)
31 -76%
...
125 -4%
Intel Atom x7-E3950
125 -4%
125.5 -3%
127.1 -2%
127.7 -2%
128 -2%
129 -1%
129.4 0%
129.8 0%
AMD A9-9410
130
131.3 1%
132 2%
132.7 2%
133 2%
133 2%
133 2%
Intel Atom x5-Z8550
134 3%
134 3%
AMD A4-6210
134.5 3%
...
5600 4208%
max:
15842 12086%
0%
100%
0102030405060708090100110120130Tooltip
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
0.8 Points (20%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
2694 puntos (16%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
4619 puntos (3%)
wPrime 2.10 - wPrime 2.0 1024m *
751 s (9%)
wPrime 2.10 - wPrime 2.0 32m *
24 s (5%)
WinRAR - WinRAR 4.0
879 puntos (1%)
X264 HD Benchmark 4.0 - x264 Pass 2
10.1 fps (4%)
X264 HD Benchmark 4.0 - x264 Pass 1
53.5 fps (12%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (4%)
TrueCrypt - TrueCrypt Twofish
0.2 GB/s (3%)
TrueCrypt - TrueCrypt AES
1 GB/s (3%)
3DMark 06 - CPU - 3DMark 06 - CPU
2455 Points (5%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
17.8 s (4%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
878 s (4%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
4764 Points (4%)
3DMark 11 - 3DM11 Performance Physics
1470 Points (4%)
3DMark - 3DMark Ice Storm Physics
17953 Points (15%)
3DMark - 3DMark Ice Storm Extreme Physics
17279 Points (14%)
3DMark - 3DMark Ice Storm Unlimited Physics
17768 Points (15%)
3DMark - 3DMark Cloud Gate Physics
1318 Points (3%)
3DMark - 3DMark Fire Strike Standard Physics
2054 Points (4%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
2133 puntos (29%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
3182 puntos (8%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
3299 puntos (6%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
2134 puntos (42%)
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
3516 puntos (6%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
2255 puntos (34%)
Geekbench 2 - 32 Bit - Geekbench Stream
3482 Points (28%)
Geekbench 2 - 32 Bit - Geekbench Memory
3458 Points (31%)
Geekbench 2 - 32 Bit - Geekbench Total Score
4260 Points (11%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
2081 ms (2%)
Sunspider - Sunspider 1.0 Total Score *
147.7 ms (2%)
Octane V2 - Octane V2 Total Score
17423 Points (16%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
