Intel Pentium B980

Intel B980

El Intel Pentium B980 es un procesador de dos núcleos para portátiles de gama básica. Se basa en la arquitectura Sandy Bridge, pero muchas de las características como el Turbo Boost para la parte del CPU, HyperThreading, AES, Virtualización (VT-x y VT-d), Trusted Execution o Intel Quick Sync están desactivadas. El Pentium B980 integra una tarjeta de video llamada Intel HD Graphics que se basa en la HD Graphics 2000 para desktop con frecuencia de 650 / 1150 (con Turbo Boost).

El rendimiento del Pentium B980 debe ser notablemente más veloz que el del CPU Arrandale Pentium de frecuencia similar. Debido a la frecuencia elevada, el HyperThreading que falta y cache más pequeño de último nivel debe ser igualado y, por tanto, el rendimiento debe ser similar al de un Intel Core i3-2310M con 2,1 GHz.

El TDP de 35W incluye el GPU integrado y el controlador de memoria DDR3-1333.

SerieIntel Pentium
Nombre códigoSandy Bridge

Serie: Pentium Sandy Bridge

Intel Pentium B980 « 2.4 GHz2 / 2 cores2 MB L3
Intel Pentium B9702.3 GHz2 / 2 cores2 MB L3
Intel Pentium B9602.2 GHz2 / 2 cores2 MB L3
Intel Pentium B9502.1 GHz2 / 2 cores2 MB L3
Intel Pentium B9402 GHz2 / 2 cores2 MB L3
Intel Pentium 9971.6 GHz2 / 2 cores2 MB L3
Intel Pentium 9871.5 GHz2 / 2 cores2 MB L3
Intel Pentium 9771.4 GHz2 / 2 cores2 MB L3
Intel Pentium 9671.3 GHz2 / 2 cores2 MB L3
Intel Pentium 9571.2 GHz2 / 2 cores2 MB L3
Velocidad de reloj2400 MHz
Caché de Nivel 1128 KB
Caché de Nivel 2512 KB
Caché de Nivel 32 MB
Número de Núcleos/Subprocesos2 / 2
Consumo de Corriente (TDP = Thermal Design Power)35 Watt
Conteo de Transistores624 Millón
Tecnología de producción32 nm
Tamaño de Matriz149 mm2
Temperatura Máx.85 °C
ConectorrPGA988B
RecursosHD Graphics, DDR3 Memory Controller
GPUIntel HD Graphics (Sandy Bridge) (650 - 1100 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$125 U.S.
Fecha de anuncio07/01/2012

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.79     de promedio: 1.8     mediana: 1.8 (2%)     max: 1.85 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.88     de promedio: 0.9     mediana: 0.9 (23%)     max: 0.95 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 3054     de promedio: 3098     mediana: 3109 (19%)     max: 3118 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 5027     de promedio: 5715     mediana: 5878.5 (4%)     max: 6075 puntos
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 7167     de promedio: 7278     mediana: 7304 (5%)     max: 7337 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 3802     de promedio: 3835     mediana: 3825.5 (5%)     max: 3885 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 1028     de promedio: 1044     mediana: 1037 (12%)     max: 1072 s
wPrime 2.10 - wPrime 2.0 32m *
min: 32.43     de promedio: 33     mediana: 32.9 (7%)     max: 33.67 s
WinRAR - WinRAR 4.0
1435 puntos (2%)
X264 HD Benchmark 4.0 - x264 Pass 2
10 fps (3%)
X264 HD Benchmark 4.0 - x264 Pass 1
55 fps (13%)
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (2%)
TrueCrypt - TrueCrypt Twofish
0.1 GB/s (3%)
TrueCrypt - TrueCrypt AES
0.2 GB/s (0%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2424     de promedio: 2453     mediana: 2462.5 (5%)     max: 2464 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 16.64     de promedio: 16.9     mediana: 16.9 (4%)     max: 17.26 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 37.02     de promedio: 38     mediana: 38 (2%)     max: 38.97 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 853     de promedio: 867     mediana: 863 (4%)     max: 886 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 26000     de promedio: 30567     mediana: 29400 (14%)     max: 36300 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 17290     de promedio: 17370     mediana: 17390 (13%)     max: 17430 MFLOPS
Windows 7 Experience Index - Win7 CPU
6.1 Points (78%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 5597     de promedio: 5678     mediana: 5699.5 (5%)     max: 5717 Points
3DMark 11 - 3DM11 Performance Physics
min: 2196     de promedio: 2204     mediana: 2203.5 (6%)     max: 2211 Points
Geekbench 2 - 32 Bit - Geekbench Stream
3855 Points (31%)
Geekbench 2 - 32 Bit - Geekbench Memory
3745 Points (34%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
3798 Points (7%)
Geekbench 2 - 32 Bit - Geekbench Integer
3624 Points (7%)
Geekbench 2 - 32 Bit - Geekbench Total Score
3732 Points (10%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
