AMD A8-5600K

AMD AMD A8-5600K

La AMD A8-5600K es una APU de desktop basada en la arquitectura Trinity. El chip es producido en un proceso de 32nm e integra dos módulos con 4 núcleos de CPU con frecuencia de 3,6 a 3,9 GHz. Además, el 5.600K tiene una unidad gráfica Radeon HD 7560D y un controlador de memoria DDR3-1866. Debido al multiplicador desbloqueado, el procesador puede hacer overclock fácilmente.

Los núcleos del CPU se basan en una arquitectura Bulldozer reformulada, llamada Piledriver. Aunque es comercializado como un procesador quad-core, el A8-5600K incluye apenas dos módulos con cuatro núcleos enteros y dos unidades de punto flotante, en total. Como resultado, el CPU no es un verdadero procesador quad-core.

Dependiendo del benchmark, el rendimiento del procesador A8-5600K es más o menos similar al del Core i3-3220 de desktop. El chip muestra un buen rendimiento en aplicaciones con alta paralelización, mientras que el rendimiento por thread es menos impresionante. Para las tareas diarias, como Office, aplicaciones multimedia o navegando en Internet, el 5600K es adecuado sin restricciones, incluso es posible jugar juegos 3D si está utilizando una tarjeta de video dedicada.

La Radeon HD 7560D integrada, compatible con DirectX 11 ofrece apenas 256 núcleos shader (7660G: 384) y una velocidad de 760 MHz sin soporte para Turbo. En promedio, el rendimiento de la GPU HD 7560D es comparable con el de una GPU de portátil Radeon HD 6630M dedicada y un poco más veloz que la HD Graphics 4000 encontrada en la plataforma Ivy Bridge de Intel.

El consumo de energía de toda la APU de desktop es de 100 watts.

SerieAMD A-Series (Desktop)
Nombre códigoTrinity

Serie: A-Series (Desktop) Trinity

AMD A10-5800K3.8 - 4.2 GHz4 / 4 cores
AMD A8-5600K « 3.6 - 3.9 GHz4 / 4 cores
AMD A4-53003.4 - 3.6 GHz2 / 2 cores
Velocidad de reloj3600 - 3900 MHz
Caché de Nivel 1192 KB
Caché de Nivel 24 MB
Número de Núcleos/Subprocesos4 / 4
Consumo de Corriente (TDP = Thermal Design Power)100 Watt
Conteo de Transistores1303 Millón
Tecnología de producción32 nm
Tamaño de Matriz246 mm2
ConectorFM2
GPUAMD Radeon HD 7560D (760 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Fecha de anuncio09/26/2012

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
292 Points (2%)
31 -89%
...
Intel Core i5-5350U
277 -5%
278 -5%
278.3 -5%
Intel Pentium Silver J5040
279 -4%
282.5 -3%
282.8 -3%
Intel Core i3-7130U
284 -3%
AMD A10-7700K
285 -2%
290 -1%
AMD A8-5600K
292
292.5 0%
292.5 0%
294.5 1%
296 1%
296 1%
298 2%
301 3%
Intel Core i5-5257U
305 4%
305.3 5%
...
15842 5325%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
87 Points (26%)
19 -78%
...
83 -5%
Intel Core M-5Y51
83 -5%
84 -3%
84 -3%
Intel Celeron 2970M
85 -2%
85 -2%
Intel Core i3-5015U
85 -2%
85.3 -2%
AMD A10-7850K
86 -1%
AMD A8-5600K
87
AMD A6-6400K
88 1%
88.3 1%
89 2%
89.5 3%
90.5 4%
Intel Pentium Silver J5040
91 5%
91 5%
92 6%
92.6 6%
...
332 282%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
3.2 Points (4%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1 Points (24%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
2941 puntos (18%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
8838 puntos (6%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
12505 Points (9%)
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
3983 Points (5%)
wPrime 2.10 - wPrime 2.0 1024m *
529 s (6%)
wPrime 2.10 - wPrime 2.0 32m *
16.7 s (3%)
WinRAR - WinRAR 4.0
2449 puntos (4%)
X264 HD Benchmark 4.0 - x264 Pass 2
20.9 fps (7%)
X264 HD Benchmark 4.0 - x264 Pass 1
102.4 fps (24%)
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (6%)
TrueCrypt - TrueCrypt Twofish
0.4 GB/s (6%)
TrueCrypt - TrueCrypt AES
1.8 GB/s (5%)
3DMark 06 - CPU - 3DMark 06 - CPU
4295 Points (9%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
25.4 s (5%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
1497 s (7%)
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
12490 MIPS (6%)
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
8670 MFLOPS (7%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
10081 Points (9%)
3DMark 11 - 3DM11 Performance Physics
3965 Points (11%)
3DMark - 3DMark Ice Storm Physics
35814 Points (29%)
3DMark - 3DMark Cloud Gate Physics
2908 Points (7%)
3DMark - 3DMark Fire Strike Standard Physics
4175 Points (7%)
Geekbench 2 - 32 Bit - Geekbench Stream
4439 Points (36%)
Geekbench 2 - 32 Bit - Geekbench Memory
4030 Points (37%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
8620 Points (17%)
Geekbench 2 - 32 Bit - Geekbench Integer
6438 Points (13%)
Geekbench 2 - 32 Bit - Geekbench Total Score
6520 Points (17%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
