Intel HD Graphics (Sandy Bridge)

La Intel HD Graphics (Familia) es una tarjeta de vídeo, integrada en los modelos económicos Celeron y Pentium de la generación Sandy Bridge. Es similar a la Intel HD Graphics 2000 y no con los gráficos de los antiguos procesadores Arrandale dual-core (que llevan el mismo nombre).

Dependiendo del procesador, la HD graphics ofrece una frecuencia base y Turbo Boost distintos. Actualmente existen tres modelos diferentes:

    Ahorrador de energía, por ejemplo, el Celeron 847: base 350MHz, Turbo 800MHz
    Celeron, como el Celeron B810: base 650MHz, Turbo 950MHz
    Pentium, como el Pentium B950: base 650MHz, Turbo 1100MHz

Además, el lento rendimiento del CPU de algunos modelos puede influenciar mucho en los juegos. Por ejemplo, aunque el GPU en el Celeron B710 no se diferencie mucho del Pentium B950, el rendimiento de los juegos fue evidentemente peor y muchos juegos eran inutilizables.

Como la HD Intel Graphics 3000 y 2000, la tarjeta de video integrada es capaz de usar parte del cache del último nivel del procesador (generalmente 2MB para los CPUs de gama básica). Esto podría ser visto como una pequeña cantidad de memoria dedicada muy veloz.

El feature set en comparación con la HD Graphics 3000 también es reducido en estos CPUs de gama básica. Por ejemplo, Intel Quick Sync (para la de- y codificación de videos HD), en Tru 3D, el Clear Video HD normalmente está desactivado.

Fabricante

Intel

HD Graphics Serie

HD Graphics P530	24 @ 0.35 - 1.05 GHz	64/128 Bit
HD Graphics 5600	24 @ 0.3 - 1.05 GHz	64/128 Bit
HD Graphics 6000	48 @ 0.3 - 1 GHz	64/128 Bit
HD Graphics 4600	20 @ 0.2 - 1.35 GHz	64/128 Bit
HD Graphics 5500	24 @ 0.3 - 0.95 GHz	64/128 Bit
HD Graphics 5000	40 @ 0.2 - 1.1 GHz	64/128 Bit
HD Graphics 4400	20 @ 0.2 - 1.1 GHz	64/128 Bit
HD Graphics 5300	24 @ 0.1 - 0.9 GHz	64/128 Bit
HD Graphics 4000	16 @ 0.35 - 1.35 GHz	64/128 Bit
HD Graphics (Broadwell)	12 @ 0.1 - 0.85 GHz	64/128 Bit
HD Graphics 4200	20 @ 0.2 - 0.85 GHz	64/128 Bit
HD Graphics (Skylake)	12 @ 0.3 - 0.8 GHz	64/128 Bit
HD Graphics 405 (Braswell)	16 @ 0.32 - 0.7 GHz	64/128 Bit
HD Graphics (Braswell)	16 @ 0.32 - 0.7 GHz	64/128 Bit
HD Graphics 400 (Braswell)	12 @ 0.32 - 0.64 GHz	64/128 Bit
HD Graphics (Haswell)	10 @ 0.2 - 1 GHz	64/128 Bit
HD Graphics (Cherry Trail)	16 @ 0.2 - 0.6 GHz	64/128 Bit
HD Graphics 3000	12 @ 0.35 - 1.35 GHz	64/128 Bit
HD Graphics 2500	6 @ 0.65 - 1.15 GHz	64/128 Bit
HD Graphics (Ivy Bridge)	6 @ 0.35 - 1.1 GHz	64/128 Bit
HD Graphics 2000	6 @ 0.85 - 1.35 GHz	64/128 Bit
HD Graphics (Sandy Bridge)	6 @ 0.35 - 1.1 GHz	64/128 Bit
HD Graphics (Bay Trail)	4 @ 0.31 - 0.9 GHz	32/64/128 Bit

Nombre Código

Sandy Bridge

Arquitectura

Gen. 6 Sandy Bridge

Pipelines

6 - unificado

Velocidad del núcleo

350 - 1100 (Boost) MHz

Ancho de Bus de Memoria

64/128 Bit

Memoria Compartida

DirectX

DirectX 10.1, Shader 4.1

tecnología

32 nm

Fecha de Anuncio

01.05.2011

Link a la Página del Fabricante

http://www.intel.com/technology/graphics...

CPU in HD Graphics (Sandy Bridge)		GPU Base Speed	GPU Boost / Turbo
Intel Pentium G860	2 x 3000 MHz, 65 W	650 MHz	1100 MHz
Intel Pentium B980	2 x 2400 MHz, 35 W	650 - 1100 MHz	? MHz
Intel Pentium B970	2 x 2300 MHz, 35 W	650 MHz	1150 MHz
» show 23 more
Intel Pentium B960	2 x 2200 MHz, 35 W	650 MHz	1100 MHz
Intel Pentium B950	2 x 2100 MHz, 35 W	650 MHz	1100 MHz
Intel Pentium B940	2 x 2000 MHz, 35 W	650 MHz	1100 MHz
Intel Celeron B840	2 x 1900 MHz, 35 W	650 MHz	950 MHz
Intel Celeron B830	2 x 1800 MHz, 35 W	650 MHz	950 MHz
Intel Celeron B820	2 x 1700 MHz, 35 W	650 MHz	1050 MHz
Intel Celeron B815	2 x 1600 MHz, 35 W	650 MHz	1050 MHz
Intel Celeron B810	2 x 1600 MHz, 35 W	650 MHz	950 MHz
Intel Pentium 997	2 x 1600 MHz, 17 W	350 MHz	1000 MHz
Intel Pentium 987	2 x 1500 MHz, 17 W	350 MHz	1000 MHz
Intel Celeron 887	2 x 1500 MHz, 17 W	350 MHz	1000 MHz
Intel Celeron B800	2 x 1500 MHz, 35 W	650 MHz	1000 MHz
Intel Pentium 977	2 x 1400 MHz, 17 W	350 MHz	1000 MHz
Intel Celeron 877	2 x 1400 MHz, 17 W	350 MHz	1000 MHz
Intel Pentium 967	2 x 1300 MHz, 17 W	350 MHz	1000 MHz
Intel Celeron 867	2 x 1300 MHz, 17 W	350 MHz	1000 MHz
Intel Pentium 957	2 x 1200 MHz, 17 W	350 MHz	800 MHz
Intel Celeron B730	1 x 1800 MHz, 35 W	650 MHz	1000 MHz
Intel Celeron 847	2 x 1100 MHz, 17 W	350 MHz	800 MHz
Intel Celeron 807	1 x 1500 MHz, 17 W	350 MHz	950 MHz
Intel Celeron B720	1 x 1700 MHz, 35 W	650 MHz	1000 MHz
Intel Celeron B710	1 x 1600 MHz, 35 W	650 MHz	1000 MHz
Intel Celeron 797	1 x 1400 MHz, 35 W	350 MHz	950 MHz
min. - max.		350 - 650 - 1100 MHz	800 - 1150 MHz

Benchmarks

3DMark - 3DMark Cloud Gate Score

min: 1386 de promedio: 1452 mediana: 1451.5 (2%) max: 1517 Points

+ 2 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Compal Barebone	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	1386
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	1517

3DMark - 3DMark Cloud Gate Graphics

min: 1389 de promedio: 1405 mediana: 1404.5 (1%) max: 1420 Points

+ 2 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Compal Barebone	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	1389
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	1420

3DMark - 3DMark Ice Storm Graphics

min: 13132 de promedio: 13747 mediana: 13746.5 (2%) max: 14361 Points

+ 2 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	13132
Compal Barebone	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	14361

3DMark Vantage
3DM Vant. Perf. total +

3DMark Vantage - 3DM Vant. Perf. total

min: 737 de promedio: 932 mediana: 976 (1%) max: 1057 Points

+ 18 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	737
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	738
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	771
Acer Aspire V5-431-887B4G50Mauu	887	HD Graphics (Sandy Bridge)	4 GB	775
Lenovo ThinkPad Edge E130 NZU5FGE	977	HD Graphics (Sandy Bridge) 1050 / 667 MHz	4 GB	780
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	917
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	933
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	941
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	953
Asus F75A-TY089H	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	999
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	1002
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	1007
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	1012
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	1037
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	1039
Acer Aspire E1-531-B9606G50Mnks	B960	HD Graphics (Sandy Bridge) 2200 / 99.8 MHz 1.7 GB	6 GB	1040
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	1043
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	1057

3DM Vant. Perf. GPU no PhysX +

3DMark Vantage - 3DM Vant. Perf. GPU no PhysX

min: 581 de promedio: 736 mediana: 767.5 (1%) max: 831 Points

+ 18 mas detalles - Ocultar tabla de comparación

modelo	CPU	GPU	RAM	valor
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	581
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	610
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	611
Lenovo ThinkPad Edge E130 NZU5FGE	977	HD Graphics (Sandy Bridge) 1050 / 667 MHz	4 GB	615
Acer Aspire V5-431-887B4G50Mauu	887	HD Graphics (Sandy Bridge)	4 GB	616
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	719
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	737
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	740
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	751
Asus F75A-TY089H	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	784
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	790
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	794
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	798
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	807
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	819
Acer Aspire E1-531-B9606G50Mnks	B960	HD Graphics (Sandy Bridge) 2200 / 99.8 MHz 1.7 GB	6 GB	820
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	822
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	831

ATI Radeon HD 3200 -92%

...

ATI Mobility Radeon HD 4530 -24%

AMD Radeon HD 7310 -23%

AMD Radeon HD 6310 -21%

NVIDIA ION 2 -15%

ATI Mobility Radeon HD 3650 -14%

NVIDIA GeForce G 105M -12%

NVIDIA GeForce 9500M GS -6%

Intel HD Graphics 2000 -6%

AMD Radeon HD 8180 -6%

Intel HD Graphics (Sandy Bridge)

AMD Radeon HD 6320 0%

ATI Mobility Radeon HD 5430 2%

NVIDIA NVS 2100M 4%

ATI Mobility Radeon HD 540v 6%

ATI Mobility FireGL V5700 9%

ATI Mobility Radeon HD 4550 10%

NVIDIA GeForce 8600M GT 15%

ATI Mobility Radeon HD 4570 16%

NVIDIA GeForce 315M 18%

...

NVIDIA GeForce GTX 1070 SLI (Laptop) 10434%

100%

3DMark 2001SE - 3DMark 2001 - Standard

min: 9769 de promedio: 11443 mediana: 11429.5 (12%) max: 13145 Points

+ 4 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	9769
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	9837
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	13022
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	13145

3DMark 03 - 3DMark 03 - Standard

min: 2701 de promedio: 6189 mediana: 6390 (3%) max: 7772 Points

+ 15 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Asus X201E-KX096H	847	HD Graphics (Sandy Bridge) 850 MHz	4 GB	2701
Acer Aspire 5349 - B812G32Mnkk	B815	HD Graphics (Sandy Bridge)	2 GB	5335
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	5705
HP ProBook 4530s	B810	HD Graphics (Sandy Bridge)	2 GB	5744
Acer Aspire V5-531	967	HD Graphics (Sandy Bridge) 350 / 667 MHz	4 GB	5965
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	6360
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	6379
	B950	HD Graphics (Sandy Bridge) 1100 MHz	3 GB	6390
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	6404
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	6442
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	6446
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	6589
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	6852
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	7756
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	7772

3DMark 05 - 3DMark 05 - Standard

min: 2000 de promedio: 4691 mediana: 4768 (7%) max: 5917 Points

+ 16 mas detalles - Ocultar tabla de comparación

modelo	CPU	GPU	RAM	valor
Asus X201E-KX096H	847	HD Graphics (Sandy Bridge) 850 MHz	4 GB	2000
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	4004
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	4196
Acer Aspire V5-531	967	HD Graphics (Sandy Bridge) 350 / 667 MHz	4 GB	4540
Lenovo ThinkPad Edge E130 NZU5FGE	977	HD Graphics (Sandy Bridge) 1050 / 667 MHz	4 GB	4566
Asus F75A-TY089H	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	4685
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	4721
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	4729
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	4807
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	4832
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	4921
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	4939
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	4943
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	5619
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	5634
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	5917

Intel Graphics Media Accelerator (GMA) 500 -97%

...

ATI Mobility Radeon X2500 -10%

NVIDIA GeForce G 105M -10%

NVIDIA GeForce Go 7700 -10%

AMD Radeon HD 6320 -8%

ATI Mobility Radeon X1700 -8%

NVIDIA GeForce 8600M GS -6%

AMD Radeon HD 7340 -5%

AMD Radeon HD 7400G -4%

ATI Mobility Radeon HD 3470 Hybrid X2 -3%

Intel HD Graphics (Sandy Bridge)

NVIDIA GeForce Go 7600 GT 5%

NVIDIA GeForce Go 6800 Ultra 7%

Intel HD Graphics (Ivy Bridge) 8%

ATI Mobility Radeon HD 4330 9%

AMD Radeon HD 8240 9%

Intel HD Graphics 2000 11%

AMD Radeon HD 7600G 17%

ATI Mobility Radeon HD 5430 17%

AMD Radeon HD 8330 19%

...

AMD Radeon RX 6800M 893%

100%

3DMark 06 3DMark 06 - Score Unknown Settings +

3DMark 06

min: 2365 de promedio: 2618 mediana: 2438 (4%) max: 3050 puntos

+ 3 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
3DMark 06 - Score Unknown Settings
Acer Aspire 5349 - B812G32Mnkk	B815	HD Graphics (Sandy Bridge)	2 GB	2365
HP ProBook 4530s	B810	HD Graphics (Sandy Bridge)	2 GB	2438
	B950	HD Graphics (Sandy Bridge) 1100 MHz	3 GB	3050

3DMark 06 - Standard 1366x768 +

3DMark 06

3002 Points (5%)

+ 1 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
3DMark 06 - Standard 1366x768
Toshiaba Satellite L755-5244	B940	HD Graphics (Sandy Bridge)	4 GB	3002

3DMark 06 - Standard 1280x1024 +

3DMark 06

min: 1027 de promedio: 2435 mediana: 2509 (4%) max: 3230 Points

+ 19 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
3DMark 06 - Standard 1280x1024
Asus X201E-KX096H	847	HD Graphics (Sandy Bridge) 850 MHz	4 GB	1027
Acer Aspire V5-531	967	HD Graphics (Sandy Bridge) 350 / 667 MHz	4 GB	1054
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	2087
Acer Aspire V5-431-887B4G50Mauu	887	HD Graphics (Sandy Bridge)	4 GB	2274
Lenovo ThinkPad Edge E130 NZU5FGE	977	HD Graphics (Sandy Bridge) 1050 / 667 MHz	4 GB	2293
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	2424
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	2439
Asus F75A-TY089H	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2459
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	2495
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	2509
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	2518
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2577
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2593
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2597
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	2701
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	2914
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	2928
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	3142
Acer Aspire E1-531-B9606G50Mnks	B960	HD Graphics (Sandy Bridge) 2200 / 99.8 MHz 1.7 GB	6 GB	3230

3DMark 06 - Standard 1280x768 +

3DMark 06

2433 Points (4%)

+ 1 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
3DMark 06 - Standard 1280x768
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	2433

3DMark 06 - Standard 1024x768 +

3DMark 06

3530 Points (6%)

+ 1 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
3DMark 06 - Standard 1024x768
Toshiaba Satellite L755-5244	B940	HD Graphics (Sandy Bridge)	4 GB	3530

Unigine Heaven 2.1 - Heaven 2.1 high

min: 5.3 de promedio: 5.7 mediana: 5.5 (1%) max: 7 fps

+ 6 mas detalles - Ocultar tabla de comparación

modelo	CPU	GPU	RAM	valor
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	5.3
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	5.4
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	5.4
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	5.5
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	5.6
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	7

AMD Radeon HD 7310 -89%

...

AMD Radeon HD 7600G -12%

AMD Radeon R2 (Mullins/Beema/Carrizo-L) -11%

AMD Radeon HD 7640G -11%

Intel HD Graphics 2000 -7%

AMD Radeon HD 6520G -5%

AMD Radeon HD 7470M -5%

AMD Radeon R3 (Mullins/Beema) -4%

AMD Radeon HD 6480G -4%

Intel HD Graphics (Cherry Trail) 0%

Intel HD Graphics (Sandy Bridge)

AMD Radeon HD 6470M 9%

AMD Radeon HD 6490M 18%

AMD Radeon HD 7520G 20%

AMD Radeon HD 7450M 20%

NVIDIA GeForce 310M 23%

Intel HD Graphics 405 (Braswell) 30%

NVIDIA NVS 4200M 31%

NVIDIA GeForce GT 520M 34%

NVIDIA GeForce 610M 35%

...

NVIDIA Quadro RTX 5000 (Laptop) 9233%

100%

SPECviewperf 11
specvp11 snx-01 +

SPECviewperf 11 - specvp11 snx-01

0.1 fps (0%)

+ 1 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	0.14

specvp11 tcvis-02 +

SPECviewperf 11 - specvp11 tcvis-02

0.1 fps (0%)

+ 1 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	0.09

specvp11 proe-05 +

SPECviewperf 11 - specvp11 proe-05

0.3 fps (1%)

+ 1 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	0.34

specvp11 ensight-04 +

SPECviewperf 11 - specvp11 ensight-04

0.1 fps (0%)

+ 1 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	0.08

Windows 7 Experience Index - Win7 Gaming graphics

min: 5.4 de promedio: 5.7 mediana: 5.7 (72%) max: 5.8 Points

+ 17 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	5.4
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	5.4
HP ProBook 4530s	B810	HD Graphics (Sandy Bridge)	2 GB	5.6
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	5.6
Acer Aspire V5-531	967	HD Graphics (Sandy Bridge) 350 / 667 MHz	4 GB	5.6
Acer Aspire V5-431-887B4G50Mauu	887	HD Graphics (Sandy Bridge)	4 GB	5.6
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	5.6
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	5.7
Acer Aspire 5349 - B812G32Mnkk	B815	HD Graphics (Sandy Bridge)	2 GB	5.7
Lenovo ThinkPad Edge E130 NZU5FGE	977	HD Graphics (Sandy Bridge) 1050 / 667 MHz	4 GB	5.7
	B950	HD Graphics (Sandy Bridge) 1100 MHz	3 GB	5.8
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	5.8
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	5.8
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	5.8
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	5.8
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	5.8
Acer Aspire E1-531-B9606G50Mnks	B960	HD Graphics (Sandy Bridge) 2200 / 99.8 MHz 1.7 GB	6 GB	5.8

Windows 7 Experience Index - Win7 Graphics

min: 3.8 de promedio: 4.5 mediana: 4.5 (57%) max: 5.1 Points

+ 17 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	3.8
Acer Aspire 5349 - B812G32Mnkk	B815	HD Graphics (Sandy Bridge)	2 GB	4.1
HP ProBook 4530s	B810	HD Graphics (Sandy Bridge)	2 GB	4.4
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	4.4
Acer Aspire V5-531	967	HD Graphics (Sandy Bridge) 350 / 667 MHz	4 GB	4.5
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	4.5
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	4.5
Lenovo ThinkPad Edge E130 NZU5FGE	977	HD Graphics (Sandy Bridge) 1050 / 667 MHz	4 GB	4.5
Acer Aspire V5-431-887B4G50Mauu	887	HD Graphics (Sandy Bridge)	4 GB	4.5
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	4.6
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	4.6
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	4.6
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	4.6
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	4.6
Acer Aspire E1-531-B9606G50Mnks	B960	HD Graphics (Sandy Bridge) 2200 / 99.8 MHz 1.7 GB	6 GB	4.9
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	5
	B950	HD Graphics (Sandy Bridge) 1100 MHz	3 GB	5.1

Cinebench R10 Cinebench R10 Shading (32bit) +

Cinebench R10 - Cinebench R10 Shading (32bit)

min: 1030 de promedio: 2571 mediana: 2577 (12%) max: 3508 puntos

+ 18 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Asus X201E-KX096H	847	HD Graphics (Sandy Bridge) 850 MHz	4 GB	1030
Acer Aspire V5-531	967	HD Graphics (Sandy Bridge) 350 / 667 MHz	4 GB	1567
Acer Aspire V5-431-887B4G50Mauu	887	HD Graphics (Sandy Bridge)	4 GB	1824
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	2427
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	2500
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2523
Asus F75A-TY089H	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2538
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	2545
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	2557
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2597
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	2637
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	2769
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	2940
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	2942
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	2995
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	3152
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	3234
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	3508

Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +

Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit

min: 2.68 de promedio: 6.3 mediana: 6.6 (2%) max: 7.93 fps

+ 20 mas detalles + Mostrar tabla de comparación

modelo	CPU	GPU	RAM	valor
Asus X201E-KX096H	847	HD Graphics (Sandy Bridge) 850 MHz	4 GB	2.68
HP ProBook 4330s LW759ES	B810	HD Graphics (Sandy Bridge)	2 GB	4.76
HP ProBook 4530 (XX964EA)	B810	HD Graphics (Sandy Bridge)	2 GB	4.85
	B710	HD Graphics (Sandy Bridge) 1000 MHz	4 GB	5.2
MSI CR643-B9404CR	B940	HD Graphics (Sandy Bridge) 650 / 667 MHz	4 GB	5.5
Sony Vaio VPC-EH3C0E/W	B960	HD Graphics (Sandy Bridge)	4 GB	5.54
Compal Barebone	B950	HD Graphics (Sandy Bridge)	4 GB	5.98
Compal Barebone	B960	HD Graphics (Sandy Bridge)	4 GB	5.99
Acer Aspire V5-531	967	HD Graphics (Sandy Bridge) 350 / 667 MHz	4 GB	6.38
Lenovo ThinkPad Edge E130 NZU5FGE	977	HD Graphics (Sandy Bridge) 1050 / 667 MHz	4 GB	6.55
Acer Aspire V5-431-887B4G50Mauu	887	HD Graphics (Sandy Bridge)	4 GB	6.68
Asus F75A-TY089H	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	7.02
Lenovo IdeaPad G580-MBBG3GE	B960	HD Graphics (Sandy Bridge) 650 MHz	4 GB	7.05
Lenovo B570e-N2F23GE	B960	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	7.12
HP Compaq Presario CQ58-148SG	B950	HD Graphics (Sandy Bridge) 1100 MHz	4 GB	7.15
Lenovo IdeaPad N581-MBA4YGE	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	7.31
HP 650-B0Y92EA	B970	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	7.35
Asus F55A-SX099D	B980	HD Graphics (Sandy Bridge) 1150 MHz	4 GB	7.35
Acer Aspire E1-531-B9606G50Mnks	B960	HD Graphics (Sandy Bridge) 2200 / 99.8 MHz 1.7 GB	6 GB	7.69
Intel Pentium G860, Intel DZ77GA-70K Desktop, DDR3-1333	G860	HD Graphics (Sandy Bridge) 1100 MHz	8 GB	7.93

- Gama de valores de las pruebas para esta tarjeta gráfica

- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance

Pruebas de juegos

Los siguientes benchmarks se derivan de nuestros benchmarks de los portátiles de análisis. El rendimiento depende de la memoria gráfica utilizada, velocidad de reloj, procesador, configuración del sistema, controladores y sistemas operativos. Así que los resultados no tienen que ser representativos de todos los portátiles con esta GPU. Para información más detallada sobre los resultados del benchmark, haga clic en el número de fps.
