Intel Core i7-3770K

Intel 3770K

El Intel Core i7-3770K es el procesador más rápido LGA1155 para PCs desktop y se basa en la arquitectura Ivy Bridge. Gracias al Hyperthreading, los cuatro núcleos pueden soportar hasta ocho threads en paralelo haciendo un mejor uso del CPU. Cada núcleo ofrece una velocidad base de 3,5 GHz, pero puede aumentar la frecuencia dinámicamente con Turbo Boost, hasta 3,7 GHz (para 4 núcleos activos), 3,8 GHz (para 2 núcleos activos) y 3,9 GHz (para 1 núcleo activo). Además, los procesadores de la serie "K" ofrecen un multiplicador desbloqueado para la fácil aceleración (overclocking).

Ivy Bridge es una matriz mejorada y reducida de la arquitectura Sandy Bridge con mejoras en el rendimiento del GPU y CPU. Los CPUs son producidos en 22nm (contra 32nm de los CPUs Sandy Bridge) y son los primeros en introducir transistores 3D para una mejor eficiencia energética al compararlo con procesadores Sandy Bridge con frecuencias similares. Otros nuevos recursos son el PCI Express 3.0 integrado y soporte para DDR3(L)-1600.

El rendimiento del Core i7-3770K es ligeramente superior que el de un procesador Sandy Bridge con frecuencia similar gracias a pequeñas alteraciones estructurales. Por tanto, el Core i7-2700K es superado por cerca de 10 por ciento. Comparada con la CPU de desktop más rápida de la AMD (FX-8350), la Core i7-3770K es significativamente más rápida.

El Intel HD Graphics 4000 integrado, ofrece 16 Unidades de Ejecución (EUs) con frecuencia de 650 MHz hasta 1150 MHz (Turbo Boost). En los últimos juegos, el rendimiento sólo es suficiente para resoluciones y detalles bajos.

El consumo total de energía de la CPU, gráficos e controlador de memoria es especificado por Intel en 77 watts (TDP).

SerieIntel Core i7 (Desktop)
Nombre códigoIvy Bridge

Serie: Core i7 (Desktop) Ivy Bridge

Intel Core i7-3770K « 3.5 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-37703.4 - 3.9 GHz4 / 8 cores8 MB L3
Velocidad de reloj3500 - 3900 MHz
Caché de Nivel 21 MB
Caché de Nivel 38 MB
Número de Núcleos/Subprocesos4 / 8
Consumo de Corriente (TDP = Thermal Design Power)77 Watt
Tecnología de producción22 nm
Temperatura Máx.67.4 °C
ConectorFCLGA1155
RecursosHD Graphics 4000 (650-1150 MHz), SSE 4.1/4.2, AVX, Trusted Execution, AES, Dual Channel Memory Controller DDR3-1600 (max 32GB)
GPUIntel HD Graphics 4000 (650 - 1150 MHz)
64 Bitsoporte para 64 Bit
Architecturex86
Precio inicial$294 U.S.
Fecha de anuncio04/08/2012
Enlace de Producto (externo)ark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 7.52     de promedio: 7.7     mediana: 7.7 (10%)     max: 7.88 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.7 Points (41%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
5536 puntos (33%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
22190 puntos (16%)
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
27536 Points (19%)
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
6972 Points (8%)
wPrime 2.10 - wPrime 2.0 1024m *
198.1 s (2%)
wPrime 2.10 - wPrime 2.0 32m *
6.4 s (1%)
wPrime 1.55 - wPrime 1.55 1024m *
190.6 s (1%)
wPrime 1.55 - wPrime 1.55 32m *
6.4 s (3%)
WinRAR - WinRAR 4.0
3698 puntos (6%)
X264 HD Benchmark 4.0 - x264 Pass 2
43.4 fps (15%)
X264 HD Benchmark 4.0 - x264 Pass 1
172.3 fps (40%)
TrueCrypt - TrueCrypt Serpent
0.4 GB/s (12%)
TrueCrypt - TrueCrypt Twofish
0.7 GB/s (12%)
TrueCrypt - TrueCrypt AES
3.9 GB/s (10%)
3DMark 06 - CPU - 3DMark 06 - CPU
min: 7170     de promedio: 7309     mediana: 7229 (15%)     max: 7606 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
9.4 s (2%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
21.1 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
516 s (2%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 26132     de promedio: 26498     mediana: 26269 (23%)     max: 27825 Points
3DMark 11 - 3DM11 Performance Physics
min: 8042     de promedio: 9019     mediana: 9216.5 (25%)     max: 9294 Points
3DMark - 3DMark Ice Storm Physics
min: 44692     de promedio: 48571     mediana: 49145 (40%)     max: 49714 Points
3DMark - 3DMark Ice Storm Unlimited Physics
51296 Points (43%)
3DMark - 3DMark Cloud Gate Physics
min: 7001     de promedio: 7176     mediana: 7184 (18%)     max: 7316 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 9475     de promedio: 9810     mediana: 9882 (18%)     max: 9942 Points
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
12835 puntos (23%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
3322 puntos (65%)
Geekbench 2 - 32 Bit - Geekbench Stream
9073 Points (73%)
Geekbench 2 - 32 Bit - Geekbench Memory
8131 Points (74%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
15159 Points (30%)
Geekbench 2 - 32 Bit - Geekbench Integer
13133 Points (26%)
Geekbench 2 - 32 Bit - Geekbench Total Score
12435 Points (33%)
Sunspider - Sunspider 0.9.1 Total Score *
120.9 ms (1%)
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance
