Intel HD Graphics (Skylake)

Intel HD Graphics (Skylake)

La Intel HD Graphics (Skylake) (GT1) es una unidad gráfica integrada de la generación Skylake, que puede ser encontrada en procesadores ULV (Ultra Low Voltage) de gama baja de la generación Skylake. Esta versión "GT1" de la GPU Skylake ofrece 12 Unidades de Ejecución (EUs) con velocidad de hasta 800 MHz (dependiendo del modelo de CPU). Debido a la falta de memoria gráfica dedicada o cache eDRAM, la HD Graphics debe acceder la memoria principal (2x 64bit DDR3L-1600 / DDR4-2133).

Rendimiento

Dependiendo de varios factores como configuración de memoria, la HD Graphics debe desempeñarse de forma similar a la antigua HD Graphics 4200 y aguantará solo algunos juegos antiguos y menos exigentes con las configuraciones más bajas.

Características

El motor de vídeo revisado ahora decodifica H.265/HEVC por completo en el hardware y consecuentemente, de forma mucho más eficiente que antes. Pantallas pueden ser conectadas mediante DP 1.2 / eDP 1.3 (máx. 3840 x 2160 @ 60 Hz) aunque el HDMI esté limitado a la versión anterior 1.4a (máx. 3840 x 2160 @ 30 Hz). Sin embargo, HDMI 2.0 puede ser añadido utilizando un convertidor DisplayPort. Hasta tres pantallas pueden ser controladas de forma simultánea.

Consumo de Energía

La HD Graphics (Skylake) puede ser encontrada en procesadores móviles especificados con TDP de 6 W y, por tanto es adecuada para portátiles 2-en-1 y tablets enfriados de forma pasiva.

HD Graphics Serie

HD Graphics P530 24 @ 0.35 - 1.05 GHz64/128 Bit
HD Graphics 5600 24 @ 0.3 - 1.05 GHz64/128 Bit
HD Graphics 6000 48 @ 0.3 - 1 GHz64/128 Bit
HD Graphics 4600 20 @ 0.2 - 1.35 GHz64/128 Bit
HD Graphics 5500 24 @ 0.3 - 0.95 GHz64/128 Bit
HD Graphics 5000 40 @ 0.2 - 1.1 GHz64/128 Bit
HD Graphics 4400 20 @ 0.2 - 1.1 GHz64/128 Bit
HD Graphics 5300 24 @ 0.1 - 0.9 GHz64/128 Bit
HD Graphics 4000 16 @ 0.35 - 1.35 GHz64/128 Bit
HD Graphics (Broadwell) 12 @ 0.1 - 0.85 GHz64/128 Bit
HD Graphics 4200 20 @ 0.2 - 0.85 GHz64/128 Bit
HD Graphics (Skylake) 12 @ 0.3 - 0.8 GHz64/128 Bit
HD Graphics 405 (Braswell) 16 @ 0.32 - 0.7 GHz64/128 Bit
HD Graphics (Braswell) 16 @ 0.32 - 0.7 GHz64/128 Bit
HD Graphics 400 (Braswell) 12 @ 0.32 - 0.64 GHz64/128 Bit
HD Graphics (Haswell) 10 @ 0.2 - 1 GHz64/128 Bit
HD Graphics (Cherry Trail) 16 @ 0.2 - 0.6 GHz64/128 Bit
HD Graphics 3000 12 @ 0.35 - 1.35 GHz64/128 Bit
HD Graphics 2500 6 @ 0.65 - 1.15 GHz64/128 Bit
HD Graphics (Ivy Bridge) 6 @ 0.35 - 1.1 GHz64/128 Bit
HD Graphics 2000 6 @ 0.85 - 1.35 GHz64/128 Bit
HD Graphics (Sandy Bridge) 6 @ 0.35 - 1.1 GHz64/128 Bit
HD Graphics (Bay Trail) 4 @ 0.31 - 0.9 GHz32/64/128 Bit
Nombre CódigoSkylake GT1
ArquitecturaGen. 9 Skylake
Pipelines12 - unificado
Velocidad del núcleo300 - 800 (Boost) MHz
Ancho de Bus de Memoria64/128 Bit
Tipo de MemoriaDDR3L/LPDDR3
Memoria Compartidasi
APIDirectX 12_1, OpenGL 4.4
tecnología14 nm
CaracterísticasQuickSync
Fecha de Anuncio01.09.2015

Benchmarks

- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance

Para ver más juegos jugables y una lista de todos los juegos y tarjetas gráficas visita nuestroListado de juegos
