Intel Iris Xe Graphics G7 96EUs
La Intel Xe Graphics G7 (GPU Tiger-Lake U con 96 EUs) es una tarjeta gráfica integrada en las CPUs Tiger-Lake U de gama alta (15 - 28 Watt). Utiliza la nueva arquitectura Xe (Gen12) y se introdujo en septiembre de 2020. La GPU tiene una velocidad de reloj base (garantizada) de 400 MHz en todas las CPUs y puede aumentar hasta 1340 MHz (i7-1185G7). La variante más lenta sólo ofrece 1100 MHz de refuerzo (i5-1130G7, TDP de 12 vatios).
El rendimiento depende de la configuración del TDP del portátil y de la refrigeración utilizada. Las primeras informaciones muestran que el chip puede configurarse con un TDP de 12 y 28 vatios por defecto (como los chips Ice Lake-U) y el rendimiento debería estar en torno a una GeForce MX350 dedicada en los benchmarks 3DMark. Para los juegos esperamos un rendimiento algo peor debido a la falta de memoria gráfica dedicada y de soporte de controladores. Muchos juegos, por ejemplo, tuvieron problemas al probar los distintos portátiles (por ejemplo, Horizon Zero Dawn o Cyberpunk 2077 no se iniciaban o se bloqueaban - véase la lista más abajo). Los juegos menos exigentes, como Mass Effect Legendary Edition, funcionaron bien en la configuración media. Comparada con la antigua GPU Ice Lake Iris Plus G7, la nueva GPU Tiger Lake debería ser aproximadamente el doble de rápida. Por lo tanto, la iGPU sigue siendo sólo para los ajustes gráficos más bajos y las resoluciones bajas en juegos exigentes.
Los SoCs Tiger Lake y por tanto la GPU integrada están fabricados en el moderno proceso de 10nm+ (10nm SuperFin) de Intel y por tanto deberían ofrecer una muy buena eficiencia.
Gen. 12 / Xe Serie Iris Xe G7 96EUs 96 @ 0.4 - 1.35 GHz Iris Xe G7 80EUs 80 @ 0.4 - 1.35 GHz UHD Graphics 64EUs 64 @ 1.4 GHz UHD Graphics Xe G4 48EUs 48 @ 0.35 - 1.45 GHz UHD Graphics Xe 32EUs (Tiger Lake-H) 32 @ 0.35 - 1.45 GHz UHD Graphics Xe 750 32EUs 32 @ 0.35 - 1.45 GHz UHD Graphics Xe 16EUs (Tiger Lake-H) 16 @ 0.35 - 1.45 GHz
Nombre Código Tiger Lake Xe Arquitectura Gen. 11 Ice Lake Pipelines 96 - unificado Velocidad del núcleo 400 - 1350 (Boost) MHz Memoria Compartida si API DirectX 12_1, OpenGL 4.6 Consumo de corriente 28 Watt tecnología 10 nm Características 3.8 MB L3 Cache, QuickSync, Device ID 9A49, Vendor ID 8086 Fecha de Anuncio 15.08.2020
CPU in Iris Xe G7 96EUs GPU Base Speed GPU Boost / Turbo Intel Core i9-12900HK 14 x 1800 MHz, 45 W ? MHz 1450 MHz Intel Core i9-12900H 14 x 1800 MHz, 45 W ? MHz 1450 MHz Intel Core i7-12800H 14 x 1800 MHz, 45 W ? MHz 1400 MHz » show 17 more Intel Core i7-12700H 14 x 1700 MHz, 45 W ? MHz 1400 MHz Intel Core i7-1280P 14 x 1300 MHz, 28 W ? MHz 1450 MHz Intel Core i7-1270P 12 x 1600 MHz, 28 W ? MHz 1400 MHz Intel Core i7-1260P 12 x 1500 MHz, 28 W ? MHz 1400 MHz Intel Core i7-1265U 10 x 1300 MHz, 15 W ? MHz 1250 MHz Intel Core i7-11390H 4 x 3400 MHz, 35 W 400 MHz 1400 MHz Intel Core i7-11375H 4 x 3300 MHz, 35 W 400 MHz 1350 MHz Intel Core i7-1195G7 4 x 2900 MHz, 28 W 400 MHz 1400 MHz Intel Core i7-11370H 4 x 3300 MHz, 35 W 400 MHz 1350 MHz Intel Core i7-1255U 10 x 1200 MHz, 15 W ? MHz 1250 MHz Intel Core i7-1185G7 4 x 3000 MHz, 28 W 400 MHz 1350 MHz Intel Core i7-1165G7 4 x 2800 MHz, 28 W 400 MHz 1300 MHz Intel Core i5-11320H 4 x 3200 MHz, 35 W 400 MHz 1350 MHz Intel Core i7-1260U 10 x 800 MHz, 9 W ? MHz 950 MHz Intel Core i7-1250U 10 x 800 MHz, 9 W ? MHz 950 MHz Intel Core i7-1180G7 4 x 2200 MHz, 9 W 400 MHz 1100 MHz Intel Core i7-1160G7 4 x 2100 MHz, 15 W 400 MHz 1100 MHz min. - max. 400 MHz 950 - 1450 MHz
Benchmarks Performance Rating - 3DMark 11 + Fire Strike + Time Spy
10.2 pt (11%)
...
Intel Iris Pro Graphics 580 -2%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon RX Vega 7 5%
...
3DMark - 3DMark Time Spy Score
min: 789 de promedio: 1621 mediana: 1672.5 (9%) max: 2095 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 91% 100% 98% 74%
...
NVIDIA Quadro P600 -19%
AMD Radeon Pro 460 -15%
AMD Radeon Pro 560 -6%
NVIDIA Quadro P620 -2%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon 660M 7%
NVIDIA GeForce GTX 1050 Max-Q 8%
AMD Radeon Pro 560X 10%
AMD Radeon RX 560X (Laptop) 19%
...
3DMark - 3DMark Time Spy Graphics
min: 707 de promedio: 1458 mediana: 1512 (7%) max: 1830 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 90% 100% 97% 72%
...
NVIDIA Quadro P600 -20%
AMD Radeon Pro 560 -6%
NVIDIA Quadro P620 -5%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon 660M 9%
AMD Radeon Pro 560X 11%
NVIDIA GeForce GTX 1050 Max-Q 11%
AMD Radeon RX 560X (Laptop) 23%
...
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 180392 de promedio: 201870 mediana: 203857 (27%) max: 241349 Points
...
Intel Iris Pro Graphics 580 -8%
AMD Radeon RX Vega 7 -6%
AMD Radeon RX 560X (Laptop) -6%
AMD Radeon Pro 560 -1%
AMD Radeon Pro 450 -1%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon Pro 555 8%
AMD Radeon Pro 455 13%
...
3DMark - 3DMark Ice Storm Extreme Graphics
min: 45789 de promedio: 63611 mediana: 55351.5 (8%) max: 88727 Points
...
NVIDIA Quadro P520 -3%
Intel Iris Xe Graphics G7 96EUs
AMD FirePro W5130M 1%
NVIDIA Quadro M600M 4%
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 6%
AMD Radeon RX Vega 9 11%
...
NVIDIA GeForce RTX 3080 Laptop GPU 553%
3DMark - 3DMark Cloud Gate Score
min: 9231 de promedio: 18085 mediana: 18073.5 (22%) max: 26837 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 93% 95% 100% 88%
...
AMD Radeon Pro 460 -7%
Intel UHD Graphics 770 (Alder Lake) -4%
NVIDIA GeForce GTX 1050 Max-Q -3%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon Pro 560X 1%
AMD Radeon RX Vega 7 1%
...
3DMark - 3DMark Cloud Gate Graphics
min: 13162 de promedio: 26154 mediana: 26752 (11%) max: 38040 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 87% 100% 92% 75%
...
AMD Radeon Pro 455 -10%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon Pro 460 3%
NVIDIA Quadro P2000 Max-Q 10%
...
3DMark - 3DMark Fire Strike Standard Score
min: 2096 de promedio: 4315 mediana: 4450 (11%) max: 5675 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 86% 100% 98% 65%
...
AMD Radeon RX 480 (Laptop) -6%
AMD Radeon Pro 460 -5%
AMD Radeon 660M -5%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P620 3%
AMD Radeon RX 560 (Laptop) 13%
...
3DMark - 3DMark Fire Strike Standard Graphics
min: 2286 de promedio: 4815 mediana: 5092 (10%) max: 5955 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 86% 100% 95% 66%
...
AMD Radeon 660M -7%
AMD Radeon Pro 460 -5%
NVIDIA Quadro P620 -3%
Intel Iris Xe Graphics G7 96EUs
NVIDIA GeForce GTX 1050 Max-Q 18%
...
3DMark - 3DMark Ice Storm Graphics
min: 60011 de promedio: 85859 mediana: 78976.5 (11%) max: 119768 Points
...
AMD FirePro W5130M -5%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 7%
...
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited
16789 Points (100%)
Intel HD Graphics (Cherry Trail) -91%
Apple M1 8-Core GPU -37%
Intel Iris Xe Graphics G7 96EUs
3DMark - 3DMark Sling Shot (ES 3.0) Unlimited Graphics
28890 Points (68%)
Intel HD Graphics (Cherry Trail) -94%
Intel Iris Xe Graphics G7 96EUs
Apple M1 8-Core GPU 36%
3DMark - 3DMark Wild Life Extreme Unlimited
min: 2054 de promedio: 3318 mediana: 3468.5 (7%) max: 4130 Points
...
Intel UHD Graphics G1 (Ice Lake 32 EU) -73%
AMD Radeon RX Vega 7 -46%
Intel UHD Graphics Xe G4 48EUs -46%
Intel UHD Graphics 770 (Alder Lake) -43%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon RX 560X (Laptop) 9%
AMD Radeon 680M 14%
Apple M1 7-Core GPU 36%
Apple M1 8-Core GPU 42%
Apple M2 8-Core GPU 71%
Apple M2 10-Core GPU 106%
...
3DMark - 3DMark Night Raid
min: 10094 de promedio: 14033 mediana: 13551 (16%) max: 17552 Points
...
Intel Iris Plus Graphics G4 (Ice Lake 48 EU) -41%
AMD Radeon RX Vega 7 -12%
Intel UHD Graphics 770 (Alder Lake) -9%
Intel Iris Xe Graphics G7 96EUs
NVIDIA GeForce RTX 3050 Laptop GPU 115%
...
NVIDIA GeForce RTX 3070 Laptop GPU 271%
3DMark - 3DMark Night Raid Graphics Score
min: 11724 de promedio: 17299 mediana: 17700 (10%) max: 21795 Points
...
Intel UHD Graphics Xe G4 48EUs -38%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H) -34%
Intel UHD Graphics 770 (Alder Lake) -30%
AMD Radeon RX Vega 7 -22%
Intel Iris Xe Graphics G7 96EUs
NVIDIA GeForce RTX 3050 Laptop GPU 151%
...
3DMark 11 - 3DM11 Performance Score
min: 2897 de promedio: 6591 mediana: 6851 (14%) max: 7917 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 89% 100% 98% 83%
...
NVIDIA GeForce GTX 775M -7%
NVIDIA Quadro P620 -1%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon 660M 5%
AMD Radeon Pro 460 6%
AMD Radeon RX 560 (Laptop) 8%
...
3DMark 11 - 3DM11 Performance GPU
min: 2867 de promedio: 6338 mediana: 6602 (10%) max: 7134 Points
GPU TDP ? TDP 8 W TDP 12 W TDP 13 W 91% 100% 97% 87%
...
NVIDIA Quadro P620 -6%
NVIDIA GeForce GTX 775M -4%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon 660M 4%
AMD Radeon Pro 460 6%
...
3DMark Vantage 3DM Vant. Perf. total + 3DMark Vantage - 3DM Vant. Perf. total
min: 17234 de promedio: 21043 mediana: 21478.5 (6%) max: 23981 Points
...
AMD Radeon Pro 460 -9%
AMD Radeon RX 560X (Laptop) -6%
Intel Iris Xe Graphics G7 96EUs
...
3DM Vant. Perf. GPU no PhysX + 3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 16531 de promedio: 20146 mediana: 20050.5 (15%) max: 23952 Points
...
AMD Radeon Pro 560 -12%
AMD Radeon RX 560X (Laptop) -2%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P620 8%
...
3DMark 05 - 3DMark 05 - Standard
min: 23832 de promedio: 30375 mediana: 30375 (42%) max: 36918 Points
...
Intel Iris Xe Graphics G7 96EUs
NVIDIA GeForce RTX 3070 Laptop GPU 52%
...
NVIDIA GeForce RTX 3060 Laptop GPU 61%
3DMark 06 3DMark 06 - Score Unknown Settings +
24558 puntos (37%)
...
AMD FirePro M8900 -32%
Intel Iris Xe Graphics G7 96EUs
3DMark 06 - Standard 1280x1024 +
min: 19983 de promedio: 26129 mediana: 27110 (41%) max: 32422 Points
...
AMD Radeon Pro 455 -1%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon Pro 555 1%
...
Unigine Valley 1.0 - Unigine Valley 1.0 DX
min: 14.9 de promedio: 15.5 mediana: 15.5 (7%) max: 16 fps
Intel HD Graphics (Cherry Trail) -92%
...
AMD Radeon RX Vega 7 -38%
AMD Radeon Pro WX 3100 -35%
Intel UHD Graphics 770 (Alder Lake) -29%
NVIDIA Quadro P500 -23%
AMD Radeon RX 550X (Laptop) -20%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon Pro 555 4%
AMD Radeon Pro 455 6%
AMD Radeon Pro 560 18%
...
NVIDIA GeForce RTX 3070 Laptop GPU 752%
Unigine Heaven 2.1 - Heaven 2.1 high
23.1 fps (4%)
...
AMD Radeon R7 M340 -14%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon RX Vega 8 (Ryzen 2000/3000) 8%
...
SPECviewperf 12 specvp12 sw-03 + SPECviewperf 12 - specvp12 sw-03
37.3 fps (16%)
...
AMD FirePro W5130M -14%
NVIDIA Quadro P500 -7%
NVIDIA GeForce GTX 1050 Ti Mobile -7%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P520 11%
...
specvp12 snx-02 + SPECviewperf 12 - specvp12 snx-02
3.4 fps (1%)
...
Intel Iris Xe Graphics G7 96EUs
NVIDIA GeForce GTX 1050 Ti Mobile 45%
...
specvp12 showcase-01 + SPECviewperf 12 - specvp12 showcase-01
18.4 fps (7%)
...
NVIDIA Quadro M600M -7%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon Pro 555 8%
NVIDIA Quadro P600 9%
AMD Radeon Pro 455 10%
...
specvp12 mediacal-01 + SPECviewperf 12 - specvp12 mediacal-01
11.1 fps (7%)
...
AMD Radeon Pro 555 -18%
NVIDIA Quadro P500 -16%
AMD Radeon Pro 455 -3%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P520 4%
AMD Radeon RX Vega 10 9%
NVIDIA Quadro P600 14%
...
specvp12 maya-04 + SPECviewperf 12 - specvp12 maya-04
39.2 fps (14%)
...
NVIDIA Quadro P600 -5%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P620 4%
AMD Radeon Pro WX Vega M GL 9%
...
specvp12 energy-01 + SPECviewperf 12 - specvp12 energy-01
0.4 fps (1%)
...
AMD FirePro W4190M -13%
AMD FirePro W5130M -12%
NVIDIA Quadro P500 -3%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro M600M 16%
...
specvp12 creo-01 + SPECviewperf 12 - specvp12 creo-01
8.4 fps (4%)
...
Intel Iris Xe Graphics G7 96EUs
...
specvp12 catia-04 + SPECviewperf 12 - specvp12 catia-04
37.1 fps (13%)
...
NVIDIA Quadro P520 -25%
AMD Radeon Pro 555 -17%
AMD Radeon Pro 455 -16%
NVIDIA GeForce GTX 1050 Ti Mobile -16%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P600 7%
...
specvp12 3dsmax-05 + SPECviewperf 12 - specvp12 3dsmax-05
38.8 fps (10%)
...
NVIDIA Quadro P520 -36%
AMD Radeon Pro 455 -32%
AMD Radeon Pro 555 -31%
AMD Radeon Pro WX 3100 -19%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P620 48%
...
NVIDIA GeForce RTX 3070 Laptop GPU 501%
SPECviewperf 13 specvp13 sw-04 + SPECviewperf 13 - specvp13 sw-04
min: 11.66 de promedio: 30.7 mediana: 30.7 (14%) max: 49.7 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -77%
AMD Radeon RX Vega 10 -45%
Intel Iris Xe Graphics G7 96EUs
...
specvp13 snx-03 + SPECviewperf 13 - specvp13 snx-03
min: 5.29 de promedio: 5.7 mediana: 5.7 (1%) max: 6.19 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -51%
Intel Iris Xe Graphics G7 96EUs
...
specvp13 showcase-02 + SPECviewperf 13 - specvp13 showcase-02
min: 18.4 de promedio: 20.1 mediana: 20.1 (8%) max: 21.71 fps
...
NVIDIA Quadro P600 -4%
Intel Iris Xe Graphics G7 96EUs
NVIDIA Quadro P620 29%
NVIDIA Quadro P2000 Max-Q 49%
...
specvp13 medical-02 + SPECviewperf 13 - specvp13 medical-02
min: 8.47 de promedio: 10.8 mediana: 10.8 (6%) max: 13.1 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -60%
AMD Radeon RX Vega 10 -32%
NVIDIA Quadro P600 0%
Intel Iris Xe Graphics G7 96EUs
AMD Radeon Pro Vega 16 36%
NVIDIA Quadro P520 44%
AMD Radeon RX Vega 7 47%
...
specvp13 maya-05 + SPECviewperf 13 - specvp13 maya-05
min: 39.3 de promedio: 39.9 mediana: 39.9 (7%) max: 40.42 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -50%
...
Intel Iris Plus Graphics G7 (Ice Lake 64 EU) -50%
AMD Radeon RX Vega 10 -40%
NVIDIA Quadro P520 -2%
Intel Iris Xe Graphics G7 96EUs
