NVIDIA GeForce RTX 3060

La Nvidia GeForce RTX 3060 es una tarjeta gráfica de sobremesa de alto rendimiento. Se basa en el chip GA106 Ampere y ofrece 12 GB de memoria gráfica GDDR6 con un bus de memoria de 192 bits. Cuenta con 3.584 núcleos y es compatible con PCIe 4.0.
Su rendimiento es similar al de la anterior GeForce RTX 2070 y, por lo tanto, resulta ideal para jugar a juegos modernos y exigentes a 1080p con ajustes altos (en 2021).
El chip GA106 ofrece 3.840 ALU FP32, de las cuales la mitad también puede ejecutar instrucciones INT32 (es decir, 1.920 ALU INT32). Con Turing, todos los shaders aún podían ejecutar instrucciones FP32 o INT32. Según Nvidia, también se han mejorado los núcleos de trazado de rayos y los núcleos tensor del chip. Los chips Ampere incluyen además un codificador de vídeo mejorado de 5.ª generación (NVENC para H.264 y H.265) y un decodificador de 7.ª generación (para diversos formatos, entre los que ahora se incluye AV1).
El chip GA106 está fabricado por Samsung en 8 nm (8N), lo que no llega a estar a la altura del nodo de 7 nm de TSMC (utilizado, por ejemplo, por AMD y también para el chip profesional GA100 Ampere). El TDP de la RTX 3060 se especifica en 170 vatios y, por lo tanto, es ligeramente superior al de la anterior RTX 2060 (160 vatios).
GeForce RTX 3000 Serie
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Nombre Código | Ampere GA106 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Arquitectura | Ampere | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Pipelines | 3584 - unificado | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TMUs | 112 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ROPs | 48 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Raytracing Cores | 28 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tensor / AI Cores | 112 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Velocidad del núcleo | 1320 - 1777 (Boost) MHz | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Velocidad de Memoria | 15000 effective = 1875 MHz | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Ancho de Bus de Memoria | 192 Bit | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tipo de Memoria | GDDR6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Max. Cantidad de Memoria | 12 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Memoria Compartida | no | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Memory Bandwidth | 360 GB/s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| API | DirectX 12_2, Shader 6.6, OpenGL 4.6 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Consumo de corriente | 170 Watt | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Conteo de Transistores | 12 Billion | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tamaño del troquel | 13250 mm² | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| tecnología | 8 nm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| PCIe | 4.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Displays | HDMI 2.1, DisplayPort 1.4a | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Características | NVIDIA DLSS, NVIDIA Reflex, Resizable BAR, NVIDIA Broadcast, NVIDIA Ansel, NVIDIA ShadowPlay®, NVIDIA G-SYNC®, VR-ready, Nvidia Omniverse | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Fecha de Anuncio | 12.01.2021 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Link a la Página del Fabricante | www.nvidia.com | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Benchmarks
3DM Vant. Perf. total +
specvp12 sw-03 +
Cinebench R15 OpenGL 64 Bit +
* A menor número, mayor rendimiento
Pruebas de juegos
Los siguientes benchmarks se derivan de nuestros benchmarks de los portátiles de análisis. El rendimiento depende de la memoria gráfica utilizada, velocidad de reloj, procesador, configuración del sistema, controladores y sistemas operativos. Así que los resultados no tienen que ser representativos de todos los portátiles con esta GPU. Para información más detallada sobre los resultados del benchmark, haga clic en el número de fps.

007 First Light
2026
Forza Horizon 6
2026
Pragmata
2026
Death Stranding 2
2026
Crimson Desert
2026
Anno 117: Pax Romana
2025
ARC Raiders
2025
The Outer Worlds 2
2025
Battlefield 6
2025
Borderlands 4
2025
F1 25
2025
Doom: The Dark Ages
2025
Civilization 7
2025
Monster Hunter Wilds
2025
Stalker 2
2024
Until Dawn
2024
God of War Ragnarök
2024
Final Fantasy XVI
2024
Space Marine 2
2024
Star Wars Outlaws
2024
Black Myth: Wukong
2024
Once Human
2024
The First Descendant
2024
F1 24
2024
Alan Wake 2
2023
Cyberpunk 2077
2023
Baldur's Gate 3
2023
Hogwarts Legacy
2023
The Witcher 3 v4
2023
Vampire Bloodhunt
2022
Ghostwire Tokyo
2022
Cyberpunk 2077 1.6
2022
Elex 2
2022
GRID Legends
2022
Elden Ring
2022
Dying Light 2
2022
God of War
2022
Halo Infinite
2021
Farming Simulator 22
2021
Battlefield 2042
2021
Forza Horizon 5
2021
Riders Republic
2021
Back 4 Blood
2021
Far Cry 6
2021
Alan Wake Remastered
2021
FIFA 22
2021
New World
2021
Deathloop
2021
F1 2021
2021
Days Gone
2021
Outriders
2021
Cyberpunk 2077 1.0
2020
Yakuza Like a Dragon
2020
Dirt 5
2020
Watch Dogs Legion
2020
Star Wars Squadrons
2020
Crysis Remastered
2020
Horizon Zero Dawn
2020
Death Stranding
2020
F1 2020
2020
Borderlands 3
2019
Control
2019
Anno 1800
2019
The Division 2
2019
Far Cry New Dawn
2019
Metro Exodus
2019
Far Cry 5
2018
X-Plane 11.11
2018
Dota 2 Reborn
2015
The Witcher 3
2015
GTA V
2015| bajo | medio | alto | ultra | QHD | 4K | |
|---|---|---|---|---|---|---|
| 007 First Light | 58.2 | 55.3 | 48 | 45.9 | 30.1 | 11.8 |
| Forza Horizon 6 | 176 | 99 | 58 | 30 | 21 | 10 |
| Pragmata | 109.2 | 78.9 | 64.1 | 46.1 | 25.4 | |
| Death Stranding 2 | 60.6 | 52.3 | 47.9 | 36.9 | 29.3 | 18.2 |
| Crimson Desert | 98 | 55.2 | 53.7 | 46 | 33.1 | 20 |
| Resident Evil Requiem | 104 | 71.5 | 66.3 | 35 | 22.6 | 11.3 |
| Call of Duty Black Ops 7 | 146 | 115 | 50 | 35 | ||
| Anno 117: Pax Romana | 95 | 72.8 | 53 | 28.8 | 20.3 | |
| ARC Raiders | 172.1 | 103.4 | 81.5 | 46.3 | 33.4 | |
| The Outer Worlds 2 | 93.7 | 76.4 | 60 | 32.8 | 21.3 | |
| Battlefield 6 | 102.9 | 94.7 | 80.5 | 57.9 | 40.6 | 21.2 |
| Borderlands 4 | 52 | 43 | 35 | 23.5 | 18 | |
| F1 25 | 228 | 183 | 138 | 12 | 7 | 3 |
| Doom: The Dark Ages | 61.7 | 54.1 | 49.8 | 47.9 | 32 | |
| The Elder Scrolls IV Oblivion Remastered | 107.8 | 70.1 | 47 | 26.6 | 18 | |
| Assassin's Creed Shadows | 47 | 40 | 32 | 23 | 19 | |
| Civilization 7 | 274 | 192.8 | 116.6 | 69.8 | 32.9 | |
| Monster Hunter Wilds | 61.7 | 50.5 | 38.4 | 29.3 | 17.3 | |
| Kingdom Come Deliverance 2 | 111.2 | 82 | 67 | 48 | 34.4 | 19.5 |
| Indiana Jones and the Great Circle | 97 | 67 | 60 | 46 | 27 | |
| Stalker 2 | 64 | 56 | 47 | 39 | 28 | 16 |
| Call of Duty Black Ops 6 | 114 | 104 | 69 | 65 | 48 | 30 |
| Until Dawn | 119 | 78 | 52 | 37 | 26 | 15 |
| God of War Ragnarök | 127 | 102 | 88 | 82 | 61 | 34 |
| Final Fantasy XVI | 65 | 64 | 54 | 49 | 33 | 18 |
| Space Marine 2 | 96 | 78 | 75 | 67 | 46 | 24 |
| Star Wars Outlaws | 49 | 45 | 39 | 32 | 22 | 13 |
| Black Myth: Wukong | 75 | 56 | 42 | 22 | 17 | 9 |
| Once Human | 202 | 122 | 105.1 | 88 | 56 | 28 |
| The First Descendant | 153 | 99 | 81 | 68 | 43 | 23 |
| F1 24 | 283 | 248 | 179 | 57 | 37 | 18 |
| Alan Wake 2 | 54.1 | 36.2 | 18 | |||
| Cyberpunk 2077 | 128 | 98 | 83 | 72 | 42 | 18 |
| Baldur's Gate 3 | 131 | 100 | 86.7 | 85 | 59 | 31 |
| Hogwarts Legacy | 56.4 | 39.7 | 22 | |||
| The Witcher 3 v4 | 211 | 168.8 | 136.4 | 107.5 | 78.1 | 44.8 |
| Vampire Bloodhunt | 341 | 185 | 175.9 | 170.7 | 110.8 | 56.4 |
| Ghostwire Tokyo | 139.4 | 127.3 | 129.3 | 127.6 | 80.6 | 39 |
| Tiny Tina's Wonderlands | 165.7 | 134.5 | 92.8 | 72.4 | 52.9 | 28.4 |
| Cyberpunk 2077 1.6 | 79.1 | 78.1 | 74.8 | 64.2 | 39.1 | 17.7 |
| Elex 2 | 95.6 | 89.7 | 79.9 | 72.8 | 53.4 | 30.5 |
| GRID Legends | 198.9 | 160.2 | 134.2 | 97.9 | 79.1 | 51.2 |
| Elden Ring | 60 | 60 | 60 | 59.9 | 56.8 | 35.2 |
| Dying Light 2 | 86 | 68.9 | 59.8 | 42.3 | 22.5 | |
| Rainbow Six Extraction | 195 | 162 | 157 | 129 | 85 | 44 |
| God of War | 142 | 116 | 93 | 63 | 54 | 39 |
| Halo Infinite | 104 | 87.7 | 82.5 | 69.7 | 67.2 | |
| Farming Simulator 22 | 269 | 199 | 151 | 125 | 97.7 | 61.5 |
| Battlefield 2042 | 144 | 116 | 96.5 | 84.5 | 64.3 | 38.7 |
| Forza Horizon 5 | 192 | 124 | 110 | 66 | 57 | 41 |
| Call of Duty Vanguard | 102 | 113 | 96.3 | 86.8 | 62.2 | 35.6 |
| Riders Republic | 198 | 124 | 102 | 79 | 64 | 36 |
| Guardians of the Galaxy | 140 | 132 | 131 | 127 | 87 | 47 |
| Back 4 Blood | 214 | 191 | 178 | 115 | 57.4 | |
| Far Cry 6 | 156 | 120 | 105 | 93 | 70 | 39 |
| Alan Wake Remastered | 96.1 | 91.6 | 91.4 | 87 | ||
| FIFA 22 | 282 | 311 | 306 | 299 | 282 | 201 |
| New World | 161 | 112 | 105 | 95.9 | 65.3 | 33.7 |
| Deathloop | 120 | 102 | 87.3 | 72 | 51.9 | 28 |
| F1 2021 | 356 | 239 | 192 | 96 | 75 | 43 |
| Monster Hunter Stories 2 | 144 | 144 | 144 | 144 | 125 | |
| Days Gone | 203 | 137 | 122 | 89.8 | 64.8 | 36.5 |
| Mass Effect Legendary Edition | 117 | 112 | 114 | 78.8 | ||
| Resident Evil Village | 341 | 176 | 164 | 138 | 91.1 | 47.6 |
| Outriders | 122 | 146 | 125 | 104 | 70.2 | 36.9 |
| Cyberpunk 2077 1.0 | 75.7 | 74.9 | 69.5 | 56.3 | 35.5 | 16.4 |
| Immortals Fenyx Rising | 142 | 100 | 99 | 91 | 71 | 45 |
| Yakuza Like a Dragon | 134 | 120 | 116 | 101 | 67.6 | 34.4 |
| Call of Duty Black Ops Cold War | 229 | 119 | 106 | 95.2 | 66.5 | 36.6 |
| Assassin´s Creed Valhalla | 118 | 102 | 85 | 75 | 60 | 38 |
| Dirt 5 | 270 | 136 | 105 | 81 | 65 | 43 |
| Watch Dogs Legion | 123 | 108 | 94.7 | 59.1 | 45.1 | 26.8 |
| Star Wars Squadrons | 473 | 274 | 243 | 230 | 160 | 90.2 |
| Mafia Definitive Edition | 199 | 113 | 103 | 70.3 | 37 | |
| Crysis Remastered | 281 | 123 | 77.9 | 57.5 | 37.4 | 22.7 |
| Horizon Zero Dawn | 198 | 142 | 118 | 100 | 77 | 42 |
| Death Stranding | 213 | 144 | 134 | 130 | 92.9 | 51.3 |
| F1 2020 | 315 | 223 | 187 | 130 | 106 | 60 |
| Borderlands 3 | 150 | 131 | 101 | 79 | 60 | 32 |
| Control | 240 | 115 | 84.1 | 54.2 | 26.3 | |
| Anno 1800 | 151 | 149 | 105 | 50.7 | 41.5 | 22.8 |
| The Division 2 | 264 | 160 | 125 | 92 | 63 | 34 |
| Far Cry New Dawn | 136 | 114 | 109 | 97 | 87 | 50 |
| Metro Exodus | 177 | 99 | 74 | 56 | 50 | 32 |
| Shadow of the Tomb Raider | 175 | 133 | 125 | 116 | 80 | 43 |
| Strange Brigade | 432 | 214 | 171 | 149 | 115 | 67 |
| Far Cry 5 | 174 | 137 | 128 | 120 | 93 | 48 |
| X-Plane 11.11 | 157 | 141 | 114 | 97 | ||
| Final Fantasy XV Benchmark | 194 | 121 | 88 | 66 | 39 | |
| Rise of the Tomb Raider | 435 | 267 | 150 | 128 | 56.8 | |
| Dota 2 Reborn | 212 | 191 | 181 | 168 | 118 | |
| The Witcher 3 | 405 | 274 | 163 | 80 | 72 | 69 |
| GTA V | 180 | 176 | 165 | 97 | 81 | 82 |
| bajo | medio | alto | ultra | QHD | 4K | < 30 fps < 60 fps < 120 fps ≥ 120 fps | 4 26 57 | 10 37 42 | 16 47 27 | 6 24 38 15 | 14 33 40 3 | 32 40 11 2 |
Para ver más juegos jugables y una lista de todos los juegos y tarjetas gráficas visita nuestroListado de juegos
