ATI Mobility FireGL V5700

ATI Mobility FireGL V5700

La ATI Mobility FireGL V5700 es un adaptador gráfico profesional para portátiles / estaciones de trabajo móviles. Está basada en el chip Mobility Radeon HD 3650 pero tiene controladores profesionales y certificados. Además, algunas características solo están activadas en la gama FireGL (como líneas AA). Debido a las optimizaciones para OpenGL, incluso las tarjetas FireGL de gama baja pueden vencer a tarjetas gráficas de consumo de gama alta en algunas pruebas / aplicaciones.
La FireGL V5700 está construida en 55nm y consiste en 378 transistores Mio. Debido a los 120 shaders unificados y el bus de memoria de 128 bits, el rendimiento puede situarse en la clase media.
Debido al motor de video Avivo, la GPU es capaz de acelerar la decodificación de videos HD.

Mobility FireGL V5000 Serie
Mobility FireGL V5725 120 @ 0.68 GHz128 Bit @ 800 MHz
Mobility FireGL V5700 120 @ 0.6 GHz128 Bit @ 700 MHz
Nombre CódigoM86-GL
ArquitecturaRV6xx
Pipelines120 - unificado
Velocidad del núcleo600 MHz
Velocidad de Memoria700 MHz
Ancho de Bus de Memoria128 Bit
Tipo de MemoriaDDR2/GDDR3/GDDR4
Memoria Compartidano
APIDirectX 10.1, Shader 4.1
Conteo de Transistores378 Millón
tecnología55 nm
Características Powerplay 7.0, PCI-E 2.0, 2 dual-link-fähige DVI Ausgänge (HDCP fähig), integrierter DisplayPort Ausgänge. bis 2560x1600
Tamaño de la portátilde tamaño mediano
Fecha de Anuncio07.01.2008
Link a la Página del Fabricantehttp://ati.amd.com/de/products/mobilityr...

Benchmarks

3DMark Vantage
3DM Vant. Perf. total +
3DM Vant. Perf. GPU no PhysX +
3DMark 05 - 3DMark 05 - Standard
min: 8530     de promedio: 8577     mediana: 8577 (10%)     max: 8624 Points
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06 - Standard 1280x1024 +
Cinebench R10 Cinebench R10 Shading (32bit) +
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance

Para ver más juegos jugables y una lista de todos los juegos y tarjetas gráficas visita nuestroListado de juegos
