NVIDIA Quadro FX 1700M

NVIDIA Quadro FX 1700M

La Nvidia Quadro FX 1700M es un adaptador gráfico profesional para aplicaciones CAD y 3D. Está basado en el núcleo G96 (GeForce 9650M p.e.) pero con diferentes controladores que están optimizados para aplicaciones profesionales y OpenGL. Los controladores están certificados para funcionar bien con diferentes aplicaciones.
Comparada con la Quadro FX 1600M, la GPU FX 1700 M soporta Powermizer 8.0.

Quadro FX Serie

Quadro FX 3800M 128 @ 0.68 GHz256 Bit @ 1000 MHz
Quadro FX 3700M 128 @ 0.55 GHz256 Bit @ 800 MHz
Quadro FX 2800M 96 @ 0.6 GHz256 Bit @ 1000 MHz
Quadro FX 3600M 96 @ 0.5 GHz256 Bit @ 800 MHz
Quadro FX 1800M 72 @ 0.56 GHz128 Bit @ 1100 MHz
Quadro FX 2700M 48 @ 0.53 GHz256 Bit @ 800 MHz
Quadro FX 880M 48 @ 0.55 GHz128 Bit @ 790 MHz
Quadro FX 3500M 24/8 cores @ 0.58 GHz256 Bit @ 700 MHz
Quadro FX 2500M 24/8 cores @ 0.5 GHz256 Bit @ 600 MHz
Quadro FX 1700M 32 @ 0.63 GHz128 Bit @ 800 MHz
Quadro FX 1600M 32 @ 0.63 GHz128 Bit @ 800 MHz
Quadro FX 1500M 20/7 cores @ 0.38 GHz256 Bit @ 500 MHz
Quadro FX 770M 32 @ 0.5 GHz128 Bit @ 800 MHz
Quadro FX 570M 32 @ 0.48 GHz128 Bit @ 700 MHz
Quadro FX 380M 16 @ 0.63 GHz64 Bit @ 800 MHz
Quadro FX 370M 8 @ 0.58 GHz64 Bit @ 700 MHz
Quadro FX 360M 16 @ 0.4 GHz64 Bit @ 600 MHz
Quadro FX 350M 4/3 cores @ 0.45 GHz64 Bit @ 350 MHz
Nombre CódigoNB9P-GLM
ArquitecturaG9x
Pipelines32 - unificado
Velocidad del núcleo625 MHz
Velocidad de Shader1250 MHz
Velocidad de Memoria800 MHz
Ancho de Bus de Memoria128 Bit
Tipo de MemoriaGDDR3
Max. Cantidad de Memoria256 MB
Memoria Compartidano
APIDirectX 10, Shader 4.0
Consumo de corriente50 Watt
Conteo de Transistores289 Millón
tecnología65 nm
CaracterísticasOpenGL 2.1, PureVideo HD, Powermizer 8.0, mögliche Schnittstellen: LVDS, DVI, VGA, HDTV, HDCP, HDMI
Tamaño de la portátilgrande
Fecha de Anuncio01.10.2008
InformaciónCG Shading Hochsprache, 32 Bit Gleitkommapräzision, 12 Bit Subpixel Präzision, 128 Bit Genauigkeit der Grafikpipeline, Vertex und Pixelshader Programmierbarkeit, PCI-E Interface, FSAA mit gedrehtem Raster, nView Multidisplay Support, High-Precision Dynamic-Range (HPDR) Technologie, Hardware 3D Clipping nach Fensterkennung, Vollbild Antialiasing
Link a la Página del Fabricantehttp://www.nvidia.com/object/product_qua...

Benchmarks

3DMark 2001SE - 3DMark 2001 - Standard
35734 Points (37%)
+ 1 mas detalles   + Mostrar tabla de comparación
3DMark 03 - 3DMark 03 - Standard
18212 Points (10%)
+ 1 mas detalles   + Mostrar tabla de comparación
3DMark 05 - 3DMark 05 - Standard
11550 Points (13%)
+ 1 mas detalles   - Ocultar tabla de comparación
3DMark 06 3DMark 06 - Standard 1280x800 +
3DMark 06
6302 Points (9%)
+ 1 mas detalles   + Mostrar tabla de comparación
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
6159 puntos (4%)
+ 1 mas detalles   + Mostrar tabla de comparación
- Gama de valores de las pruebas para esta tarjeta gráfica
- Valores medios de las pruebas para esta tarjeta gráfica
* Smaller numbers mean a higher performance

Pruebas de juegos

Los siguientes benchmarks se derivan de nuestros benchmarks de los portátiles de análisis. El rendimiento depende de la memoria gráfica utilizada, velocidad de reloj, procesador, configuración del sistema, controladores y sistemas operativos. Así que los resultados no tienen que ser representativos de todos los portátiles con esta GPU. Para información más detallada sobre los resultados del benchmark, haga clic en el número de fps.

Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
medio 1024x768
33.3  fps    + Comparar
alto 1024x768
19.1  fps    + Comparar
» No jugable la mayor parte de los portátiles probados.
Additional Benchmarks
Medium 0xAF 0xAA 1280x800
27
Medium 0xAF 0xAA 1440x900
23
High 1280x800
15.3
High 1440x900
12.7
High 800x600
26.1
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
medio 1024x768
29.3  fps    + Comparar
alto 1024x768
17.1  fps    + Comparar
» No jugable la mayor parte de los portátiles probados.
Additional Benchmarks
Medium 0xAF 0xAA 1280x800
24.4
Medium 0xAF 0xAA 1440x900
20.8
High 1440x900
11.8
High 0xAF 0xAA 1280x800
14
High 0xAF 0xAA 800x600
23.4
F.E.A.R.

F.E.A.R.

2005
bajo 640x480
378  fps    + Comparar
medio 800x600
152  fps    + Comparar
alto 1024x768
59  fps    + Comparar
» Jugable con todos los portátiles probados en ajustes de detalle alto.
Quake 3 Arena - Timedemo

Quake 3 Arena - Timedemo

1999
alto 1024x768
610  fps    + Comparar
» Jugable con todos los portátiles probados en ajustes de detalle alto.

Para ver más juegos jugables y una lista de todos los juegos y tarjetas gráficas visita nuestroListado de juegos
